Step 2. Power-On PRC2402M Router unit (blue-top-casing or the immediate unit
connected to the main internet source).
Step 3. Wait for the Router unit to fully bootup and LED becomes Solid Blue.
Step 4. Power-On the node units
How to pair new PRC2402M single pack unit into existing running PRC2402M
mesh?
Ans. Follow below steps;
Step 1. Power-On the new PRC2402M unit near the existing PRC2402M router unit
Step 2. Wait for the new unit to finish booting up (indicating by blinking red)
Step 3. On PRC2402M Router unit > Press & Hold Pair button for 2 secs then release,
the LED will become Blue Blinking
Step 4. On new PRC2402M unit > Press & Hold Pair button for 2 secs then release, the
LED will become Blue Blinking
Step 5. Wait until the pairing process completed (indicated by all unit showing Blue Solid
LED); pairing takes approximately 2 min 30 secs.
Step 6. Power-Off the newly paired PRC2402M unit and move to a location in-between
existing PRC2402M unit and Wi-Fi dead spot location
Step 7. Power-On the newly paired PRC2402M
How to set the PRC2402M to support Wired-Backhaul?
Ans. Follow below steps;
Step 1. Ensure all node units are paired.
a. For Twin pack, node unit is already pre-paired to the router unit
b. For Single pack or any new unit, Pairing can only be done via Pair button between
the node unit and the router unit.
Step 2. Ensure that LAN cable is connected between from PRC2402M Router LAN port
to Node unit’s WAN port.
Step 3. Power-On the Node unit
Where should I place my node unit after pairing successful?
Ans. General guideline is maximum of 2 room distance between the main router and the node.
Or maximum of 2 room distance between existing node and the new node. It is highly
recommended to place the unit on an open space or unobstructed space. Please do take note
of below placement examples to avoid:
