USERS MANUAL

TX-168PHB

DECLARATION OF NETWORKCOMPATIBILITY

The Profoon TX-168PHB is designed for use on the ‘public switched telephone

networks (analogue single-line)’ of telephone- and cable-companies inside the

Benelux.

Each country and/or provider might require a different telephoneplug.

The Profoon TX-168PHB complies with the essential requirements and provi-

sions as described in the European Directive 1999/5/EC.

The function Caller-ID is based on both the DTMF and the FSK system (automa-

tic detection). It might be possible that you have to subscribe to this feature.

DECLARATION OF CONFORMITY

The declaration of conformity is available on the website WWW.PROFOON.COM

INTRODUCTION

The Profoon TX-168PHB is a telephone with built-in Caller-ID: the name (when

supported by the provider or when stored in the memory) and the number of the

person who is calling to you, comes on the display of your telephone.

The Caller-ID memory has a capacity of 30 calls, including the time and date of

the call.

The Caller-ID is linked with the dialer of the telephone. Any incoming call can be

called black.

The TX-168PHB has a phonebook memory of 35 numbers with names and the

numbers can be dialed handsfree.

INSTALLATION

Power supply:

The TX-168PHB needs power to operate. Use the included power adaptor or

install 4x 1,5 Volt battery, size AAA.

Power adaptor: One power adaptor is included. Use this one or a version with the

following specifications:

input: 230 Volt, 50, Hz AC

output: 6 - 9 Volt DC, 200mA,

Batteries: open the battery compartment (direct below the handset) and install 4

pcs 1.5V AAA batteries. Mind the polarity. Batteries are not included.

Attention: always disconnect the telephone form the telephone outlet when

batteries are to be installed or replaced. See also page 11.

Telephonecord & handsetcord:

1. connect the supplied handsetcord between the handset and base

2. connect the telephonecord to the backside of the telephone; push the

connectors till you hear a click

3. plug the telephone plug into your telephone outlet

Wall mount:

1. drill two holes in the wall with a distance of 9cm and insert two screws; let

the heads of the screws stick out a few millimeters of the wall

2. remove the handsetholder, rotate it 180° and replace it; this holder will hold

the handset when wall mounted

3. hang the unit on the wall and fixate the telephone wire by means of

cable-clips

Once the power adaptor is plugged into a 230V mains outlet and / or the batte-

ries have been installed, the telephone is ready for use.

ADJUSTING

Language:

1. press MENU 4 times, the display indicates “TAAL” (= language)

2. press YES, the display gives “NEDERLANDS” (= Dutch)

3. use or to select “ENGLISH”

4. press YES

Time:

1. press MENU 2 times, the display indicates “CLOCK”

2. press YES, the hour indication starts to blink

3. use and to adjust the hours and press YES, the minute indication

starts to blink

4. repeat this procedure for the month and the date

5. press BACK to finish the adjusting

Contrast:

1. press MENU 3 times, the display indicates “CONTRAST”

2. use and to select the required contrast (position 0 is minimum

contrast, position 7 is the maximum contrast)

3. press BACK to finish the setting

HOW TO USE

Incoming call:

Adjust the ringer volume with the ringer switch on the backside of the telephone.

Lift the handset and start the conversation.

Outgoing call:

Lift the handset.Wait for the dial tone and key-in the desired telephone number.

Handsfree dialing:

1. press the button HANDSFREE to switch-ON the handsfree mode; the

dialtone is heard through the built-in loudspeaker and can be controlled

by the slider on the right side

2. key-in the desired telephonenumber

3. as soon as the called party answers the call, lift the handset to start the

conversation

Last number memory:

The TX-168PHB keeps track of the 9 last dialed numbers:

1. press REDIAL/P and the last dialed number will come on the display

2. press to see the last but one dialed number

3. use and to step through the last number memory

4. as soon as the required number is on the display, lift the handset or press

the speakerbutton to AUTOMATICALLYdial the number

Remarks:

* Only with the handset on the cradle, you can step through the last number

memory (press button BACK to return to the idle state).

* In case you press button REDIAL/P when the handset is lifted, the last

dialed number will be redialed.

* In case a number, which is for example the 5th number in the last-redial-list,

will be redialed, this number will now move to the last position.

Pause:

In case you are connected through a PABX, a waiting time must be inserted

direct after the prefix number. Press the REDIAL/P button to insert a pausetime.

Call transfer and network-services:

Use the FLASH key to activate special services from your telephone-company or

to transfer a call in case you are connected through a PABX. The FLASH time of

the TX-168PHB is 100mS.

Teleservices:

Buttons and # are functionbuttons, needed for divers telecom-services (teles-

hopping, telebanking, etc) or to control divers telecom devices (PABX, answering

machines, etc). Refer to the concerning manual.

Calltimer:

As soon as the handset is lifted or the speakerbutton is pressed, the calltimer

keeps track of the call time.

MEMORY

The TX-168PHB has a memory capacity of 37 names and numbers:

* Each name can be as long as 15 characters.

* Each number can be as long as 16 digits.

* 2 Memory locations are one-touch memories; use them for emergency

numbers.

* The remaining 35 memory locations are accessible through the phonebook-

menu.

* See chapter Pause on page 4 in case a dialpause is required.

* It is possible to copy numbers, received by the TX-168PHB’s Caller-ID, into

the dialmemory. In case the system also sends the name, this name will be

copied too.

Programming M1 & M2:

1. leave the handset on the telephone

2. press M1 or M2; in case already a name and number was programmed, the

display shows this number else only the time and date is displayed

3. press PROG, the upper-left segment will be selected (blinking stripe)

4. key-in the name (see further on) and press YES

5. key-in the telephone number and press YES

Programming phonebook memories:

1. leave the handset on the telephone

2. press MENU; the display indicates “PHONE BOOK”

3. press PROG; the display gives “XX ENTRIES”; xx stands for the number of

memories which are already stored

4. press YES, the upper-left segment will be selected (blinking stripe)

5. key-in the name (see further on) and press YES

6. key-in the telephone number and press YES

Programming of the name:

Use the dialbuttons to compose the name. Example: press 2x button 3 to get the

E, press 3x button 5 to get the L, etc.

- use button to move the cursor to the right or to insert a space

- use button to move the cursor to the left

- use button CLEAR to erase the selected character

Dialing M1 or M2:

1. lift the handset or switch to handsfree dialing and wait for the dialtone

2. press M1 or M2

3. the number will be dialed

Dialing phonebook memories:

1. leave the handset on the telephone

2. press MENU, the display indicates “PHONE BOOK”

3. press YES, the display gives “NAME ?”

4. use and to step through the phonebook

5. press, when he required name is on the display, the speakerbutton to dial

the number

6. as soon as the called party answers the call, you have to lift the handset

to start the conversation

Attention: the dialing of a phonebook entry can only be done in handsfree mode

(see above instruction 5). Only after the dialing of the number has began, you

may lift the handset.

Correction:

1. press MENU, the display indicates “PHONE BOOK”

2. press YES and look for the name/number, using the buttons and

3. press PROG, the first character of the selected name blinks

4. press repeatedly CLEAR to erase the name and key-in the new name and

press YES

5. use CLEAR to erase the number, key-in the new number and press YES

to store the new entry

Erase:

1. press MENU, the display indicates “PHONE BOOK”

2. press YES and look for the name/number, using the buttons and

3. press CLEAR, the display indicates “DELETE ?”

4. press YES to delete the selected name/number or press BACK to return

to the idle state

CALLER-ID

Functioning:

Together with the first ring, the Telephone Company sends the telephonenumber

of the person who is calling to you.This can also be the telephonenumber of a

fax or of a mobile phone.

On receipt of this information, the display of the TX-168PHB shows this number

and stores it into its memory.

Because the numbers are stored in memory, at any time you can see who called

you and at what time and day.The display indicates how many calls are in

memory and how many calls are received after the last time you viewed the

numbers.

Please note that you must subscribe yourself for Caller-ID. Contact your provider.

Memory:

The memory can hold 30 incoming calls (numbers + names).When the memory

is full, each new incoming call will overwrite the oldest call. Please make sure to

regular read the memory and to delete it contents.The display indicates how

many calls are in memory (TOTAL) and how many of them have not been read

yet (NEW).

Name:

In case you receive a call from someone which name and number you have sto-

red in the phonebook memory of the TX-168PHB, then the name you program-

med in your telephone will come on the display. Else the name which is transmit-

ted from the provider will be displayed. In case the provider only sends the num-

ber and you have not stored this number in your telephone, than only the number

will come on the display.

Repeated call:

A repeated call will be displayed as "RPT" in the display.The information concer-

ning the first call will be lost, only the time and date of the last call will be memo-

rized.

Time/date:

The time and date of each call are memorized too. In case your provider uses

the FSK Caller-ID system, the network provides the time/date information. In

case your provider uses the DTMF system, the time/date of the internal clock of

the TX-168PHB will be used.

Read the memory:

Press or to start reading.

Use buttons or to step through the memory. Next to “CALL#”, the rotation

number of that call is displayed.The lower part of the display gives the time and

date of that call.

Call back:

1. leave the handset on the cradle and use or to look for the number to

be dialed

2. as soon as the required number is on the display, press YES; the number

will be dialed

3. you may now lift the handset to start the conversation

Erase specific numbers:

1. leave the handset on the cradle and press or to look for the call to

be deleted

2. press CLEAR, the display indicates “DELETE ?”

3. press YES to erase the selected call or press BACK to return to the idle

state

Erase all:

1. leave the handset on the cradle and press or to start reading the

memory

2. press CLEAR and keep this button depressed until the display indicates

“DELETE ALL ?”

3. press YES to erase all calls or press BACK to return to the idle state

Store received numbers into the phonebook:

1. leave the handset on the cradle and look for the number, using and

2. press PROG

3. press M1 or M2 to store the number in one of the one-touch memories or

press YES to store the number in the phonebook

Table des matières

Autres manuels Profoon Téléphone

Profoon

Profoon TX280 Manuel utilisateur

Profoon

Profoon DECT Series Manuel utilisateur

Profoon

Profoon TX-325 Manuel utilisateur

Profoon

Profoon TX 270 Manuel utilisateur

Profoon

Profoon PDX-2808 Manuel utilisateur

Profoon

Profoon TX-310 Manuel utilisateur

Profoon

Profoon TX-250(CW) Manuel utilisateur

Profoon

Profoon TX-560 Manuel utilisateur

Profoon

Profoon TX-555 Manuel utilisateur

Profoon

Profoon PDX-5200 series Manuel utilisateur

Profoon

Profoon TX-230 Manuel utilisateur

Profoon

Profoon TX-537 Manuel utilisateur

Profoon

Profoon TX-119 Manuel utilisateur

Profoon

Profoon TX-105 Manuel utilisateur

Profoon

Profoon TX-106 Manuel utilisateur

Profoon

Profoon TX-112 Manuel utilisateur

Profoon

Profoon DECT Series Manuel utilisateur

Profoon

Profoon TX-180 Manuel utilisateur

Profoon

Profoon TX-117(B) Manuel utilisateur

Profoon

Profoon TX-550vm Manuel utilisateur

Profoon

Profoon TX-129vm Manuel utilisateur

Profoon

Profoon TX-160 Manuel utilisateur

Profoon

Profoon Profoon TX-117 Manuel utilisateur

Profoon

Profoon TX-525 Manuel utilisateur

Manuels Téléphone populaires d'autres marques

GE 2-9480 Manuel utilisateur

Geemarc

Geemarc PHOTOPHONE 155 Manuel utilisateur

D-Link

D-Link DWR-720/PW Manuel utilisateur

Interquartz

Interquartz Gemini IQ333 Manuel utilisateur

SSS Siedle

SSS Siedle HT 840-0 Manuel utilisateur

Motorola

Motorola TITANIUM Manuel utilisateur

Panasonic

Panasonic ICX Manuel utilisateur

LG H870DS Manuel utilisateur

Samsung

Samsung GT-I9500 Manuel utilisateur

AT&T

AT&T Trimline 205 Manuel utilisateur

Selta

Selta zenyth 600 Manuel utilisateur

Doro

Doro AFTI 20 Manuel utilisateur

UNIQCELL

UNIQCELL A1 Manuel utilisateur

Panasonic

Panasonic KX Series Manuel utilisateur

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manuel utilisateur

BT Decor 425 Manuel utilisateur

NEC

NEC SV8500 Manuel utilisateur

Teledex

Teledex PEARL Manuel utilisateur
