Profile Design A3a Manuel utilisateur

A3 Risers

A3 RISERS

REVISION 01-02-24-2023

A3 Risers

INTRODUCTION

Thank you for purchasing these Profile Design Risers. These instructions apply to the A3aand A3criser kits.

Please read these instructions thoroughly before attempting to install this item. Proper installation is required for compliance with Profile Design's

warranty policy. If you are not familiar with installation of Aerobars or their accessories, please seek the assistance of your local Profile design dealer

by logging on to www.profile-design.com and using "dealer search" or by calling Profile Design's customer service number p.# 888.800.5999.

Note to Dealers: If you install this product for the consumer, please provide him/her with this owner’s manual after installation.

Tools and materials required:

• 5mm Hex Wrench

• Torque Wrench with a 5mm Hex fitting

• Grease such as Finishline Premium Grease

Your Riser kit should contain:

• Aluminium riser pairs (sized according to the kit you have purchased)

• Stainless steel bolts (sized according to the kit you have purchased)

• An Aluminum bridge if you purchased the A3A High Riser kit

• An integrated carbon bridge if you purchased the A3C High Riser kit

A3 Risers

WARNING: Periodically check the Aerobar for damage, particularly for scratches through the anodised coating (aluminium parts) or clearcoat (carbon

parts) that could lead to degradation and weakening of the base material. Replace your Aerobar if you notice any damage from use or accident.

If anything is missing from the Riser kit please contact your dealer.

Please note that threaded areas have been pre-treated by Profile Design during production with a special blue thread locking compound. This special

compound is easy to detect on the threads of all bolts provided. If you cannot detect this thread locking compound or you are re-installing the bolt,

re-apply a suitable thread locking compound as available from Loctite® or another company before assembly.

Products compatible with these risers

• Profile Design Wing Ultimate bar

• Profile Design Wing20C+ bar

• Profile Design Aeria Ultimate bar (A2-A3 adaptor required, available separately)

• Profile Design A2 Standard and Race brackets

A3 Risers

QTY.

Req.

Part.#Ref.# Part Description

1293151 Riser - Aeria 3 BK 5mm

2293152 Riser - Aeria 3 BK 10mm

293153 Riser - Aeria 3 BK 20mm2

QTY.

Req.

Part.#Ref.# Part Description

4293154Riser - Aeria 3 BK 40mm2

5683188Bridge - Aeria Ult BK 5mm1

293151Riser - Aeria 3 BK 5mm

293152Riser - Aeria 3 BK 10mm

293153Riser - Aeria 3 BK 20mm

COMPONENT LIST

QTY.

Req.

Part.#Ref.# Part Description

293151Riser - Aeria 3 BK 5mm

293152Riser - Aeria 3 BK 10mm

293155Bridge - Aeria 3 Carbon UD Black 40mm

a3aLOW A3aHIGH A3cHIGH

A3 Risers

PART DRAWINGS

135

153

135

153

A3 Risers

PRODUCT SPECIFIC SETUP LIMITATIONS

WING ULT

WING/20c+

A3ALOW

A3AHIGH / A3CHIGH

Bolt

(mm)

Riser

(mm)

Front

Rear

Bolt

(mm)

Riser

(mm)

100

85 90 95 100

> Bridge included in stack >

＊These bolt lengths refer to the ﬂat (0 degree) position, tilting the bars may requiring altering the bolt lengths.

A3 Risers

Adapter 10mm

Riser 5mm Riser 10mm

Adapter 10mm

01 02 03 04 05 06 07 08

Adapter 10mm

Riser 5mm

Riser 10mm

Adapter 10mm

Riser 20mm

Adapter 10mm

Riser 5mm

Adapter 10mm

Riser 20mm

Riser 10mm

Adapter 10mm

Riser 20mm

Riser 5mm

Riser 10mm

Adapter 10mm

Riser 20mm

ASSEMBLY DIAGRAMS AND TORQUE SETTINGS

6Nm (53 inlbf)

M6x40mm

M6x45mm2

Bracket mount

M6x50mm

4M6x55mm

5M6x60mm

6M6x65mm

7M6x70mm

8M6x75mm

Ref.#

A3ALOW Basebar: Wing 20c+

Location Bolt Size Torque

Wing 20c+

A3 Risers

Adapter 10mm

Riser 5mm Riser 10mm

Adapter 10mm

01 02 03 04 05 06 07 08

Adapter 10mm

Riser 5mm

Riser 10mm

Adapter 10mm

Riser 20mm

Adapter 10mm

Riser 5mm

Adapter 10mm

Riser 20mm

Riser 10mm

Adapter 10mm

Riser 20mm

Riser 5mm

Riser 10mm

Adapter 10mm

Riser 20mm

ASSEMBLY DIAGRAMS AND TORQUE SETTINGS

Bracket mount

Ref.# Location Rear - Bolt Size

M6x35mm

M6x40mm

M6x45mm

M6x50mm

M6x55mm

M6x60mm

M6x65mm

M6x70mm

Front - Bolt Size Torque

A3ALOW Basebar: Wing Ult

6Nm (53 inlbf)

M6x40mm

M6x45mm

M6x50mm

M6x55mm

M6x60mm

M6x65mm

M6x70mm

M6x75mm

Wing Ult

A3 Risers

Adapter 10mm

Riser 5mm

Riser 10mm

Bridge 5mm

Riser 20mm

Adapter 10mm

Bridge 5mm

Riser 40mm

Riser 5mm

Riser 40mm

Adapter 10mm

Bridge 5mm

Riser 10mm

Riser 40mm

Adapter 10mm

Bridge 5mm

Riser 10mm

Riser 5mm

Riser 40mm

Adapter 10mm

Bridge 5mm

ASSEMBLY DIAGRAMS AND TORQUE SETTINGS

1M6x80mm

M6x85mm2

3Bracket mount M6x90mm

4M6x95mm

5M6x100mm

Ref.#

HIGH

Basebar: Wing 20c+

Location Bolt Size Torque

6Nm (53 inlbf)

Wing 20c+

A3 Risers

Adapter 10mm

Riser 5mm

Riser 10mm

Bridge 5mm

Riser 20mm

Adapter 10mm

Bridge 5mm

Riser 40mm

Riser 5mm

Riser 40mm

Adapter 10mm

Bridge 5mm

Riser 10mm

Riser 40mm

Adapter 10mm

Bridge 5mm

Riser 10mm

Riser 5mm

Riser 40mm

Adapter 10mm

Bridge 5mm

ASSEMBLY DIAGRAMS AND TORQUE SETTINGS

3Bracket mount

Ref.# Location Rear - Bolt Size

M6x75mm

M6x80mm

M6x85mm

M6x90mm

M6x95mm

Front - Bolt Size Torque

HIGH

Basebar: Wing Ult

M6x80mm

M6x85mm

M6x90mm

M6x95mm

M6x100mm

6Nm (53 inlbf)

Wing Ult
