PROAIM CINEMA Series Manuel utilisateur

1

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

Mitchell Twin Tube Paddle Mount (P-TTPM-01)

All rights reserved.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Assembly Manua l

Male Twin Tube Paddle Mount Female Twin Tube Paddle Mount

Castle Nut Wrench 5/12 Ss Allen Bolt

2

Twin Tube Mount Setup

 Loosen the castle ring from the male twin

tube paddle mount and aach the male

mount on the Mitchell tripod stand.

Note: You can also mount the male twin tube

paddle mount on the Mitchell tripod or the

gravity tripod.

 Aer mounng it on the Mitchell stand,

secure it with the castle ring and insert the

speed rail.

 Secure the speed rail correctly with the help

of the knob, as shown in the image.

 Place the female twin tube mount on the

speed rail and ghten the 5/12s allen bolt

with the help of an allen key.

Note: you can mount your complete lm-

making setup with the heaviest gimbals on the

female Mitchell mount.

 You can slide the female twin tube paddle

mount on the speed rail according to your

setup.

Note: Proaim twin tube paddle mount delivers

360° rotaonal lockable shots.

 Aach the uid head to the female twin tube

mount, as shown in the images.

3

YOUR PROAIM MITCHELL TWIN TUBE PADDLE MOUNT

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of

me, we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor

does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to

inspecon and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our

company.

Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our

utmost support and care unl you use our product.

 Once the uid head is mounted, secure it with

a castle ring and mount the camera on it.

 Put the sandbag on the speed rail to balance

according to your camera setup, as shown in

the images.
