Operation ManualOperation Manual

U.S. Registered Trademark. Patents pending

T771

Pro1 Technologies

P.O. Box 3377

Springeld, MO 65808-3377

Toll Free : 888-776-1427

Web: www.pro1iaq.com

Hours of Operation: M-F 9AM - 6PM Eastern

Table of Contents

Thermostat Operation

Thermostat Quick Reference

Thermostat Warranty Information

Page

2-3

4-6

Una version en español de este

manual se puede descargar en la

pagina web de la compañia.

Equipment damage hazard.

Do not operate the cooling

system if the outdoor

temperature is below 50 ˚F

(10 ˚C) to prevent possible

compressor damage.

Caution

Rev. 1823

Thermostat OperationThermostat Operation

LCD Display

Glow in the dark light button

Fan Switch

System Switch

Easy change battery door

Temperature Setpoint Buttons

LCD Display

Glow in the dark light button

Fan Switch

System Switch

Temperature Setpoint Buttons

See page 6 for details about

this display read out.

The glow in the dark light

button will self illuminate

for several hours after

exposure to ambient light.

This button turns on the

display light when pressed.

Select ON or AUTO. ON will

run the fan continuously.

AUTO will cycle the fan on

only when the heating or

cooling system is on.

Selects the operation mode of

your HVAC system. Selecting

ON turns on either the

heating or cooling. Selecting

OFF turns o heating or

cooling. Your thermostat is

congured for either heat

or cool.

Press the + or - buttons to

select the desired room

temperature.

Easy Change Battery Door

See page 4 for details.

Thermostat Quick Reference

The low battery icon is displayed when the AA battery power is

low. Whenever the thermostat detects low battery voltage from

the AA batteries, the low battery icon will begin ashing on the

screen for 21 days (if the batteries are not changed). If the bat-

teries are not changed 22 days after the thermostat detects low

battery voltage, the thermostat screen will only show the ash-

ing battery icon until buttons are pressed. If the batteries are

not changed 43 days after the thermostat detects low battery

voltage, the thermostat screen will only show the ashing bat-

tery icon until buttons are pressed and the set points will oset

to 85°F/29°C in cooling and 55°F/13°C in heating. At this stage,

set point changes can be made temporarily but, the set points

will change back to defaulted values after a 4-hour period. The

thermostat will continue to perform this low battery ashing,

temperature oset condition until the internal voltage threshold

is reached. When the thermostat internal voltage threshold is

reached, all relays will be opened and the thermostat will be-

come inoperable until new batteries are installed.

Important:

Battery Door Information

Use the nger bevel on

the lower portion of the

thermostat to open the

easy access battery door.

Replace with

2 AA Alkaline

Batteries. High

quality Alkaline

batteries are

recommended.

Simple operating instructions are

found on the back of the battery door.

When the battery icon appears replace your AA

batteries immediately. Failure to do so may result in your

heating & cooling system becoming inoperable.

Freezing or overheating can occur.

Caution:

Thermostat Quick Reference

LOW

Warranty Information

Warranty Registration

Your new thermostat has a 5 year limited warranty. You must register

your thermostat within 60 days of installation. Without this

registration the warranty period will begin on date of manufacture.

For warranty issues please contact the HVAC professional that

installed this product. You can register your new thermostat in 2 ways:

Go to the company website, select warranty registration and

ll out a short registration form.

Complete the form below and mail it to the address shown.

Warranty Registration

Thermostat Quick Reference

Online

Mail

Name:

Address:

City:

State:

Zip:

Thermostat Model:

Date Installed:

Complete form and mail to:

Thermostat Warranty Registration

Pro1iaq

P.O. Box 3377

Springeld, MO 65808-3377

NOTE: The compressor

delay feature is active if

these icons are ashing.

The compressor will not

turn on until the 5 minute

delay has elapsed.

Room Temperature

Set At

COOL ON

HEAT ON

LOW

Setpoint Temperature:

Displays the selected

setpoint temperature.

System Operation

Indicators:

The COOL ON, HEAT ON

or icon will display

when the COOL, HEAT

or (fan) is on.

Low Battery

Indicator:

Replace batteries

when indicator is

shown.

Room Temperature:

Indicates the current

room temperature.

www.pro1iaq.com

Cut Out For

Warranty Registration
