Prestigio GV7790 Manuel utilisateur
Inside your package
В комплекте
Device overview
Обзор устройства
2014/11/3 12:21:51
RESET
+/-
5
GV7795 Navitel 9.2 QSG_Book.indb
1
Nano SIM
Micro SIM
Standard SIM
Getting started Начало работы
2
2014/11/3 12:21:52
3
GV7795 Navitel 9.2 QSG_Book.indb
Quick Start Guide
EN
1. Open maps
Open existing maps
2014/11/3 12:21:52
GV7795 Navitel 9.2 QSG_Book.indb
1.1 Make sure SD card is inserted, then step by step
to activate navitel ;
1.2 Click “open existing maps” ;
1.3 Add atlas ;
1.4 Create atlas , select storage > sdcard1 >
NavitelContent ;
EN
Quick Start Guide
1.5 Atlas creation ;
2014/11/3 12:21:52
GV7795 Navitel 9.2 QSG_Book.indb
1.6 Map display ;
Quick Start Guide
Presgio GPS
EN
2. Program interface
2
4
5
6
8
11
12
14
15
7
3
10
116 13
9
№Name Funcon
1Sound Tapping on the buon opens the sound
menu.
2Compass Tapping on the buon opens the context
menu, which controls opons of map
orientaon ("North up" – the map will
always be oriented northwards, "Track
up" – the map will always be oriented
in the direcon of movement along the
route), type of map view (Plain view "2D",
Panoramic view "3D") and skins ("Night
skin", "Day skin", "Auto").
3 Road lanes The sign displays road lanes with possible
maneuvers.
4Informaon
panel
The sign shows the upcoming maneuver
(for example, turning) and distance to
the maneuver. Tapping on the sign opens
the menu containing route opons, for
instance an opon which allows stopping
route guidance.
5Route Visualizaon of a current route.
6Informaon
panel
The panel shows current speed, the
remaining me to the desnaon point,
distance to the desnaon point, and
esmated arrival me.
7GPS-cursor Indicaon of a current posion on the
map, when the GPS receiver is switched
on.
8 Menu Tapping on the buon opens the main
program menu.
9Informaon
panel
The panel shows the name of the street
you are currently driving along. The
informaon is available only if GPS/
GLONASS connecon is established and
the map contains such informaon. If
there is no street name, the direcon will
be displayed.
2014/11/3 12:21:52
GV7795 Navitel 9.2 QSG_Book.indb
EN
Quick Start Guide
Prestigio GPS
18
17
20
22
23
24 21
19
№Name Function
17 "Cursor"
button
Tapping on the button shows the menu
for operations with the point marked on
the map (making it a destination point by
pressing "Go!" button or proceeding to
the properties screen.
18 "Save WP"
button
Saves the point marked on the map as a
waypoint.
19 2D/3D Switching between the plain 2D and the
panoramic 3D map formats.
20 Point on
the map
Short tap on the map marks the point
for further operations with it: saving as a
waypoint, adding to the route or viewing
the object’s data, and others.
10 Scale
button
Zoom out button.
11 Scale
button
Zoom in button.
12 "Navitel.
Events"*
Button for controlling the “Navitel.
Events” service.
13 Route
progress
bar
The progress bar displays the remaining
route, waypoints (if any) and traffic
density on the route marked by color.
14 Battery The icon indicates the level of battery
charge.Tapping on the icon shows free
device memory.
15 GPS GPS-connection indicator. Grey indicator
– GPS/GLONASS-receiver is off; red –
receiver is turned on, but there is no
connection with satellites; yellow –
bad connection; green – connection
is established. The number in the icon
indicates the number of satellites.
16 "Navitel.
Friends"*
The icon of the “Navitel.Friends” service,
tapping on which opens its menu. The
service is intended for adding friends,
viewing their location and exchanging
messages with them.
2014/11/3 12:21:52
GV7795 Navitel 9.2 QSG_Book.indb
Quick Start Guide
Prestigio GPS
EN
№Name Function
25 "Go!" Tapping on the button gives a command
to the program to calculate a route from
the current position or the set initial point
to the selected point.
26 "Set start" Tapping on the button determines the
selected point as a starting point of the
route (GPS-receiver must be switched
off).
27 "Set finish" The button is active only when there is an
existing route. Pressing the button
continues the route up to the selected
point making it the destination point of
the route.
28 "Route
through"
The button is active only when there is
an existing route. Pressing the button
marks the selected point as a point to
be included in the route. The last added
point becomes the first one in the route
after the starting point.
29 Map Back to map.
* – functionality is available only for devices, having access to
the Internet.
21 Updates * Provides access to the program and map
update menu screen.
22 Track
recording
Button for track recording: red dot–
recording is on, grey dot – recording is
stopped.
23 Navitel.
Traffic*
The icon displays general traffic intensity
on ten-point scale. Tapping on the button
shows the menu for controlling the
“Navitel.Traffic” service.
24 Navitel.
SMS*
The icon allows reading/sending messages
and using coordinates in them. It also
shows the number of unread messages.
25
28
26 27
29
2014/11/3 12:21:52
GV7795 Navitel 9.2 QSG_Book.indb
Quick Start Guide
EN
4. Technical specifications
Processor Dual Core, 1.3 GHz
Navitel
Memory RAM 512 MB + 4 GB Flash
Micro SDHC/SDXC, up to 32 GB
OS Android™ 4.4, KitKat®
Display 7” TN, 16:9, 1024*600
Camera Front 0.3 MP
Band WCDMA: 900/2100 MHz
GSM: 850/900/1800/1900 MHz
Wi-Fi (802.11 b/g/n), 3G, Bluetooth 4.0
Interfaces Micro USB 2.0, micro SD
2500 mAh
Power source
Dimension 188*109*12.5 mm (H*W*D)
Weight 279 g (approx.)
3. Connect to the Internet
Connect to the Internet either via a Wi-Fi network or your
3.1 Connect to a wireless network
a. Tap on the home screen or list menu , and
turn on Wi-Fi.
b. Any detected Wi-Fi networks will be listed. Tap to select
the desired Wi-Fi network.
c. Tap Connect. Enter the network password if required.
3.2 Turn on data connection
a. Tap > More... > Mobile networks > Data enabled.
b.
2014/11/3 12:21:53
GV7795 Navitel 9.2 QSG_Book.indb
EN
EN
Quick Start Guide
5. Disclaimer
presented in this quick start guide.
conformity is available at:
to:
2014/11/3 12:21:53
GV7795 Navitel 9.2 QSG_Book.indb
EN
Quick Start Guide
RU
1. Как открыть карты
Открытие установленных карт
2014/11/3 12:21:52
GV7795 Navitel 9.2 QSG_Book.indb
1.1 Убедитесь, что SD-карта установлена, а
затем выполните следующие шаги для
активации Навител;
;
1.2 Нажмите “открыть установленные карты”;
1.3 Добавьте атлас；
1.4 Создайте атлас, выберите Память >
sdcard1 > NavitelContent;
