Prestige APS-901E Manuel utilisateur

128-9299

1 of 4

Model APS-901E

Owner’s Manual

PATENTED: www.voxxintl.com/company/patents

FEATURES:

2 Programmable RF Transmitter

Single Channel Receiver (capable of accepting 4 transmitters)

External Receiver Antenna w/Push Button Switch & LED

On-Board Start Relay

On-Board Accessory Relay

On-Board Ignition 1 Relay

On-Board Ignition 2 Relay

Ignition 2 Relay Selectable On or Off During Cranking

On-Board Parking Light Relay

Ignition 3 / Shock By-Pass / GM VAT Output (relay required)

Tach Signal Learning Circuit

Two ( + ) and Two ( - ) Safety Shutdown Circuits

Alarm By-Pass Output

Accessory Outputs

(Pulse Before & After Start, During Crank & After Shut Down)

Selectable Steady or Flashing Parking Lights for Run Indication

Selectable 5, 10, 15, 20, 45, and 60 Minute Run Time

Car Finder Mode

Optional Door Unlock Feature For Vehicles Equipped With Power Doors

(Only operational while running under control of the remote start unit.)

Single Channel Remote Car Starter

128-9299

2 of 4

PRESTIGE

REMOTE STARTING THE VEHICLE

The vehicle will not start if any one of the following situations exists:

• The vehicle's hood lid is opened.

• The gear shift selector is not in Park.

• The brake pedal is depressed.

• The safety control switch is in the Off position.

1) To start the vehicle, press and release the transmitter button two

times within 2 seconds. The vehicle will start and remain running

for the pre-programmed run cycle. As a visual indication, the

parking lights will ash or remain on depending on the setting by

your installation center.

2) When you arrive at the vehicle, turn the ignition key to the ON

position (not the spring loaded start position), then step on the

brake pedal to disengage the remote starter. The vehicle will

continue to run, but now on its own power.

NOTE: The engine will stop running before the pre-programmed run cycle has expired if

you perform any one of the following functions:

-Press the button on the key-chain transmitter two times within 2 seconds

-Depress the brake pedal

-Open the vehicle's hood

-Place the unit in the safety control disabled mode.

PUSH-BUTTON LED RECEIVER

VALET/OVERRIDE/SAFETY CONTROL SWITCH

The Push-Button LED switch located in the receiver allows you to temporarily

disable the remote starting function of the system. This recommended whenever

the vehicle is being serviced. To place the system in the service mode:

1) With the system disarmed/unlocked, and the ignition switch Off, Press and

Hold the Push-Button, found on the windshield receiver, in.

2) Turn the ignition switch On, Off, On, Off, On, Off.

3) The LED begins to ash two short ashes followed by one long ashes and

continues this pattern until returned to normal mode of operation.

This puts the unit into the R/S Override mode indicating that the remote start is in

the service mode and will not start from RF or any other input Posse or other-

wise.

To Exit R/S Override Mode

1) With the system disarmed, press and hold the Push-Button, found on the

windshield receiver, in.

2) Turn the ignition switch On, Off, On, Off, On, Off.

3) The LED turns Off indicating that the R/S unit is fully functional once again.

128-9299

3 of 4

UNLOCKING THE VEHICLE:

If you have electric door lock, and the Optional Unlock feature was added, with

the vehicle running under command of the remote start unit, press and hold the

transmitter button for 3 seconds until the doors unlock.

CAR FINDER MODE:

Anytime the vehicle is not running under control of the remote start unit, within

operating range of the vehicle, press and hold the push-button of the hand held

transmitter for 4 seconds to activate the car nder mode. The vehicle lights will

ash for 30 seconds or until the push-button is again pressed and released.

TELEMATIC UPGRADE:

This system has the ability to have a telematic upgrade module connected to it.

This is an upgrade that can give you control of certain functions of your vehicle

from a telephone, or in some cases a computer interface. Please check with your

installation center for most recent Telematic Upgrades. If you had a Telematic

Upgrade installed, the manual supplied with the upgrade unit will provide an

operator's manual advising of the features of the system and means available to

control these features of your vehicle.

PROGRAMMING NEW OR REPLACEMENT TRANSMITTERS (BANK 1)

Transmitter Model Name, 141BP Is Also Found On Back Of

Transmitter Case. Use Battery CR2032

The following steps are used to programs the Start button for the one button start

systems.

1) Turn the ignition key to the on position.

2) Press and release the valet/programming switch 3 times (Siren Chirps).

3) Press the Button of each transmitter you want programmed until you hear

a chirp from the horn or siren.

4) Turn the ignition switch Off.

Note: Some systems will not have a audible sound associated with programming,,,for these

systems the lights will ash.

128-9299

4 of 4

To purchase replacement transmitters

or to get additional product information go to:

www.prestigecarsecurity.com

FCC COMPLIANCE

This device complies with Part 15 of the FCC rules and with RSS-210 of Industry

Canada.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including any interference that

may cause undesired operation.

Warning!

Changes or modications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment

NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized

modications to this equipment. Such modications could void the user’s authority to operate

the equipment

Transmitter Battery Replacement

1) Locate and remove the "00" point Phillips head screw on the back of the transmitter

case.

2) Carefully separate the front case from the rear.

3) Slide the CR2032 battery out from under the battery clip and dispose of properly.

4) Install the new battery with the (+) side facing up away from the circuit board.

5) Close the case and reassemble in reverse of disassembly

FUNCTION SETTING CHART

To be completed by installer

Run Time 5 Min  10 Min  15 Min  20 Min  45 Min 60 Min

While Running Unlock Yes  No 

Lights Pulse Steady 
