Presentation Switchers PS100 Manuel utilisateur

Page 1PS100 Quick Start Guide

Getting to Know the PS100

Getting to Know the PS100

The graphic below points out key aƩributes of the PS100.

Front View

Back View

Connections

Connections

Inputs and Outputs. Using the graphic above, connect the source devices to the ports labeled,

“Connect Source Devices Here”, as a reference and the display at locaƟon, “Display Output”,

port. Connect audio, if applicable.

Power. Connect the DC power supply to the locaƟon, “DC/5V”, and the other end to a 110V/

VAC power socket. The system LED will illuminate just below and to the leŌof the DC/5V

locaƟon.

Front ViewFront View

Quick Start

Connect Sources Devices Here

IR (Infra-Red) Sensor

Source Selector Active Source Indicator

Back Vie

w

Back Vie

w

Source “Port”

Stereo Audio Output

Display Output

USB Firmware Update

EDID Resolution Select

Page 2 Presentation Switchers, Inc.

Selecting a New Source Device to Display

Selecting a New Source Device to Display

To display a new source, press the Source Selector buƩon on the Front of the PS100 repeatedly

unƟl the LED on the AcƟve Source Indicator corresponds to the desired Source Port SelecƟon.

The image should now be visible on the Display Output and can be heard on the Stereo Audio

Output connectors.

Note: SelecƟng an input for a source that is not physcially connected will cause the output

display to indicate that the signal has been lost or disconnected.

Selecting a New Source Device to Display

Selecting a New Source Device to Display

(Using IR Remote)

(Using IR Remote)

From the IR Remote controller, shown below, select the Right or LeŌbuƩons unƟl the desired

Source is selected. If the front panel is viewable, you will see the AcƟve Source Indicator change

when each buƩon is pressed.

(Hand - Not to Scale)
