Premium PFV1136MSS Manuel utilisateur

This product is for domestic use only

Use & care manual

Important safeguards

UPRIGHT FREEZER

PFV885MW

PFV886MSS

PFV887MB

PFV1135MW

PFV1136MSS

PFV1137MB

Note: Compartment design may change due to product improvement without any

prior notice.

Structure Illustration

1. Steel wire shelf

2. Steel wire guardrail

3. Waterspout

4. Circumgyrate steel wire shelf

5. Refrigerator door rack

6. Adjustable feet

compartment

Points of safety

For proper usage and safety, please read

the Manual before using it.

Please follow all items of Instruction for

safety while using it.

Cautions

Attentions

This symbol indicates the po sibility

of death or serious injury

This symbol indicates the possibility

of injury or damage to property.

The meaning of symbols in this book shown

in the following table

Never do this

NO removing

Must obey while use it

Pull out the plug while

maintenance

Connected to the earth

NO touching

Attention

Customer cannot change the plug and wire

without authorization. If the wire is destroyed,

it should be changed by the service department

of our company.

Own socket for its own use

Keep the plug and socket clean

Don't extrude the plug.

No damaging the power line

Dust and bad connection

might cause electric shock .

Short circuit caused by

damaged plug can make

fire.

Short circuit caused by

forcible bending,

stretching , twisting

packing , cutting the

wire might make fire.

The electric power

must be connected the

earth well . If the wire

is not long enough ,

the extension must be

according with the

demands.

If inflammable gas is leaked, open the

window to have fresh air, don t pull out plug

Cautions

No stretching the power line directly

Be sure to connet to earth well

Never use damaged wire, plug, socket

Shut off power while maintenance

Pull out plug in emergency

Do not install the unit in moist place

Please shut the power

off while handling the

plug , damaged wire

might make fire.

Make sure the appliance

is properly earthed.

It might cause electric shock ,

short circuit ,even fire.

Avoid using the appliance

in a damp moist place.

Unplug the socket

while cleaning.

Spark would be appeared

if the plug is pulled out

and it would make

burning, explosion or

fire.

Don't remove or repair it by yourself

Accident(short circuit)

may happen if it continues

to run.

to the

authorized service

personnel without delay.

Please contact

Please contact with the

Authorized

without delay.

Service Center

Remove the door gasket while abandon it

Remove the door gasket

in order to avoid that

children are trapped in-

side.

OK!

Cautions

Warnings

Please locate it and smooth

place, regulate by screwing the feet

on even

No stretching hand to the bottom

Don't store too much food. Shelf

may break.

To avoid frostbite, don't touch foods and

vessel in freezer with moist hands

Close the door with the handle

Turning over would

cause accidents.

Stretching hands to the

bottom might be hurt

by iron sheet.

Foods might fall down

and hurt people.

Don't put bottle into the freezer case

Glass might split by

frozen and hurt peo-

ple s hands while stor-

ing and getting foods.

Touching foods and

vessel in the freezer

with moist hands

would

cause frostbite

Closing the door with

hands on the upside,

downside or other sides

might make fingers

hurt.

Recycle foam, refrigerant, etc, according

to relevant national regulations.

Forbidden to throw away foam, refrigerant, etc. Especially when use refrigerant 600a, should

remove the foam tray, or cause to explode.

When place fridges, please remove

the foam tray

This appliance is not intended for use by people (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety. Children should be supervised to ensure that

they do not play with the appliance.

If the supply cord is damaged, it must be replaced by a special cord or assembly

avaible from the manufacturer or its service agent.

INSTALLATION

1 Placement

Keeping proper space

Earth line

Avoiding heat and moisture

Locating firmly and horizontally

Earth terminal (triangle plug)

! Attentions

A piece of wood should be placed first if the

refrigerator is located on the carpet etc.

Rotate the adjustable feet one round(let the

front feet hang in the air) and then firm the

refrigerator horizontally(to avoid vibration

and noise).

Heat, sunlight shining directly would influent

cooling seriously and waste the electric energy.

Many troubles are caused by moisture.

Too small space around it, putting goods on

the top or side, and pasting on the side might

prevent heat out, waste energy unnecessarily.

Contacting between back and wall might cause

vibration and noise.

Heat radiated from the refrigerator might scald

the wall or other things if space is too small.

! Cautions

The earth line should be connected if the refriger-

ator is located at the moist place such as toilet,

laundryroom, basement etc.

Please connect one side of the earth line to the

earth terminal.

Above 5cm

Adjustable

feet

6Pay more attention while moving.

Screw compressors are adopted inside. Inclination angle is no more than 45 degrees.

WARNING:

WARNING---keep ventilation opening, in the appliance enclosure or in the built-in structure, clear of

obstruction.

WARNING---do not use mechanical devices or other means to accelerate the defrosting process.

WARNING---do not use electrical appliances inside the food storage compartments of the appliance.

WARNING---d

If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

on't damage the refrigerant loop.

Tear down the tape

firming case

Turn on the power

cleaning with

wet cloth

Storing after turning on

power 4~5 hours

The smell of plastic will

disappear automatically a

period later.

In hot season freezing foods completely needs 24 hours.

check the cooling condition in the next day. Something such as

ice-cream should be frozen completely.

Knob is to be adjusted. Large numbers indicate higher temperature, smaller numbers

indicate lower temperature

OFF show stop.In winter, usually place the knob at 4~7.In summer ,usually

place the knob at 4~1.

1 Please follow the step of control;

2 Improper adjust may lead to lower temperature ,higher temperature or influence energy consumption.

Caution:

Temperature adjustment Usually in MID position

5 Using the waterspout

When defrosting, please pull out waterspout cover flatly so that

drainage can be done through the waterspout. Users shall prepare

the defrosting pan by themselves. When drainage finish, push the

waterspout cover back to the original position by hand.

OFF

Maintenance

Cleaning procedure

Cautions

Always disconnect

the power plug.

Wipe off any oil on the

surfaces.

Soak a soft cloth in warm

water or dish abluent.

Wipe off all abluent.

Back of refrigerator Inspection after cleaning

10 minutes

Adjust the regulate feet and let it hang in the

air, then moving it.

Clean the dust at back and ground .

Caution

Check power line and plug.

If the power line and plug damaged.

Dust on the plug.

Unusual heat of plug.

If the socket become flexible.

If the plug inserted .

If the power line and plug are damaged or

sticked dust ,it would cause electric shock or

fire.

incompletely

Attention

Do not stretch hands to the bottom.

Reconnect in the power

at least 10 minutes later.

Cleaning monthly

Common Phenomena Trouble Shooting

Instruction trouble shooting

The following cases are not malfunction. Please check according to below steps before asking for service

No current; abnormal voltage; fusing; put in the plug ineffectively, Check the plug and fuse.

Not efficient

The temperature adjustment knob is in the OFF poisition;

Space around the refrigerator is not enough;

The door has been opened too frequently and too long;

The refrigerator is exposed to the sunlight directly or placed near some ;

There is no space between foods;

There are hot foods inside the case.

Please read the points of attention, keep away from the , don t open the door frequently.

Put the hot foods in the case , adjust the knob to 4 or 6 position.

Foods frozen in the steel wire shelf or s rack.

The temperature knob is in 7 position;

Foods containing rich water and freezed easily are near the rear wall. Troubles of sensors or controls,

adjust the knob to 4 position.

Noises

The refrigerator is not located firmly;

The refrigerator has been struck to other objects;

The copper pipe has been struck each other in the mechanical room;

Locate the refrigerator at a firm base and separate the copper pipe from other objects in the

mechanical room.

Compressor can not stop working automatically

Store too much foods at one setting;

Open the door frequently or too long;

The temperature knob is in 7 position;

Foods should be stored in separate batches, don t store too much foods at one setting; Decrease the

frequence of opening the door and shorten the time of opening the door;

Compressor cannot start

Turning on the power .the refrigerator cannot work exceeding 30 seconds .pull the plug down at once.

Reinsert the plug, if the refrigerator still don t work , please contact with service department.

heat sources

heat source

after it is cooled down

compartment imple
