PR Lighting PRO-PAR D Manuel utilisateur

PRO-PAR D

PR-3040 D

This product manual contains important information about the safe installation and use of this

projector. Please read and follow these instructions carefully and keep this manual in a safe

place for future reference.

PR LIGHTING LTD.

Yingbin Road, Dashi Panyu, Guangzhou, 511430 China

http://www.pr-lighting.com

2/10 PRO-PAR D manual_Last Revision_en .doc

SAFE USAGE OF THE PROJECTOR 3

INSTALLING THE PROJECTOR 4

FITTING THE LAMP 5

CHANGING THE LENS 5

KEEPING THE PROJECTOR CLEAN 6

POWER CONNECTIONS 6

TECHNICAL SPECIFICATIONS 7

Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice. Whilst

every care is taken in the preparation of this manual we reserve the right to change specifications in the course of product improvement. The publishers

cannot be held responsible for the accuracy of the information herein, or any consequence arising from them.

Every apparatus has been tested completely and packed properly by the manufacturer. Please make sure the packing and / or the apparatus is in good

condition before your installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. But

any damage caused by improper use will not be assumed by the manufacturer and / or dealer.

THESE ITEMS ARE PACKED TOGETHER WITH THE PROJECTOR

Clear, flat lens (14° Round beam shape) (1 PCS) (Order code: 070050017)

Stipple lens (19° Round beam shape) (1 PCS) (Order code: 070050016)

Fewer facets lens (21° x 34° Oblong beam shape) (1 PCS) (Order code: 070050014)

Many facets lens (30° x 51° Oblong beam shape) (1 PCS) (Order code: 070050015)

Gel frame (For installing the paper filter colour) (1 PCS)

Barndoors (1 SET)

G-bracket (1 PCS)

Locking knob (1 PCS)

Tool for uninstalling the lens (1 PCS)

Safety cord (1 PCS)

This manual (1 PCS)

Thank you for purchasing the product PRO-PAR D, PR-3040 D.

This product manual contains important information about the safe installation and use of this projector. Please read

and follow these instructions carefully and keep this manual in a safe place for future reference.

The PRO-PAR D is an innovative projector with an elegant housing made of high quality aluminiun-alloy with an

insulating painting finish. The product complies to CE norms and standards. It can be hung easily and safely. The

angle of inclination for the projector-body is convenient to be adjusted. The light beam can reach a long distance and

there are various kinds of lenses for your choice to produce different light beam effects. You can also use colour filter

which is installed inside the gel frame to produce the desirable beam colour. The projector is suitable for use in stage,

disco, or artistic applications.

ACCESSORIES

INDEX

INTRODUCTION

3/10 PRO-PAR D manual_Last Revision_en .doc

The following points are important for safety as well as for the smooth installation and

performance of the unit.

When unpacking and before disposing of the package check there is no transportation damagebefore using the

projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus.

Keep the package well for your possible future transportation.

The projector is for indoor use only, IP20. Use only in dry locations. Keep this device away from rain and moisture,

excessive heat, humidity and dust. Do not allow contact with water or any other fluids, or metallic objects.

The projector is only intended for installation, operation and maintenance by qualified personnel.

The projector must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces.

Do not project the beam onto inflammable surfaces, minimum distance is 5m. 5m

Avoid direct exposure to the light from the lamp. The light is harmful to the eye.

Do not attempt to dismantle and / or modify the projector in any way.

Electrical connection must only be carried out by qualified personnel.

It is essential that each projector is correctly earthed and that electrical installation conforms to all relevant standards.

Hot housing surface! It can reach above 200℃! Do not touch the housing of the projector with your hand during

operation.

Make sure that the power-cord is never crimped or damaged by sharp edges. Never let the power-cordcomeintocontact

withother cables. Only handle the power-cord by the plug. Never pull out the plug by tugging the power-cord.

Keep the lamp and lens clean.

Do not touch the lamp-glass and lens with bare hand.

The lamp used in this projector is a Philips MSR575/2 discharge lamp. After switching off don’t attempt to restart the

projector until lamp has cooled, this will require approx 15 minutes. Switching the lamp on and off at short intervals will

reduce the life of both the lamp and the projector. But occasional breaks will prolong the life of the lamp and projector.

Always replace the lamp if it becomes damaged or deformed.

Always replace the lens if it becomes cracked or badly scratched.

Never run the projector without a lamp and a lens in place.

Always disconnect from the mains, when the device is not in use or before cleaning it or before

attempting any maintenance work.

If you have any questions, don’t hesitate to consult your dealer or manufacturer.

SAFE USAGE OF THE PROJECTOR

4/10 PRO-PAR D manual_Last Revision_en .doc

Fixing Holes Gel Frame

Barndoors

Handle

Locking Knob

Electric Box Projector

Ring

Handle

Locking Knob

Lens Rotation Ring

Handle

Safety Cable

MSR Lamp

Fixing Holes Bracket

Lamp Housing

With the Retaining Clip

in Locked Position

Gel Frame

Lens

Barndoors

Locking Screw

Main Power Cord

Projector's Power Cord

G-clamp Safety Cord

This unit has been designed to be hung. Please check that all accessories are found.

Beforehand mount the G-bracket, locking knob and lens in their positions. And mount the Gel Frame and Barndoors if

needed.

Hang the projector via the fixing holes of its bracket using M12 size bolts. Hang the electric box and fasten the locking

screw.

For safety the projector and the electric box should have secondary mounting respectively with a safety cord through

the two handles on the back of the projector and another through the ring on the electric box. Always ensure that the

projector is firmly positioned to avoid vibration and slipping, and always ensure that the structure to which you are

attaching the projector is secure and is able to support 10 times of the weight of each PRO-PAR D.

Connect the projector’s power cord to electric box before connecting the main power cord.

Loosen the locking knob to adjust the angle of the projector.

WARNING: The electric box MUST be lifted or carried by the HANDLE instead of G-clamp.

INSTALLING THE PROJECTOR

5/10 PRO-PAR D manual_Last Revision_en .doc

Important: Before installation the MSR lamp

verify that the MSR lamp you use is suitable for

the voltage at your facility.

Loosen the cover’s locking screw on the back of the

lamp housing and pull the rear cover straight out from

the back of the projector.

Remove the old MSR lamp from lampholder, holding it

by the base.

Push down on the lamp base until the new MSR lamp

is firmly seated. Make sure that the lamp is fully seated.

Reinstall the rear cover. Center it on the reflector and

the screw hole. Then tighten the locking screw to

secure the rear cover in place.

Notes: don’t touch the bulb of the new lamp with

bare hand so as not to influence the beam output.

WARNING: The MSR series are high-pressure

lamps with external igniters (). Care should

always be taken when handling these lamps.

Always read the manufacturers "Instructions for

use" enclosed with the lamp.

After the fitting is done, turn the projector on and 5

minutes later adjust 3 adjusting screws to focus for the

optimum light output.

REMOVING A LENS

Unplug the fixture and let the fixture cool sufficiently

before handling the lens.

Place the fixture on a flat, stable work surface. Do not

install or remove lens with the unit hanging.

It is easy to use the lens tool provided to remove the

lens. When uninstalling the lens, let the middle tooth of

the tool push down the spring clip and the other teeth

will lift the edge of the lens from the lens rotation ring.

INSTALLING A LENS

Hold the lens by the edge, and position the convex side

facing the front of the fixture.

Position the edge of the lens behind the tabs of the

lens-rotation-ring and gently push the lens inward until it snaps behind the spring clip.

FITTING THE LAMP

CHANGING THE LENS

Tool for Uninstall the Lens

Lens With the

Convex Side Out

Spring Clip

Lens Rotation

Ring

Adjusting Screws

Cover's Locking Screw

Rear Cover

Lampholder

Lamp

6/10 PRO-PAR D manual_Last Revision_en .doc

To ensure the reliability of the projector it should be kept clean. The lens and reflector should be always cleaned to

maintain an optimum light output.

Do NOT use any glass cleaner or any type of solvent on the reflector. Before cleaning the reflector remove the

lens so you can access the reflector from the front of the fixture. When cleaning the reflector use a damp, clean, soft,

lint-free cotton cloth with mild, soapy water solution and gently wipe the reflector, and then remove any soapy water

residue with a clean, soft, lint-free cotton cloth dampened with water. Do not use paper towels or harsh materials to

wipe the reflector.

Cleaning frequency depends on the environment in which the fixture operates: damp, smoke or particularly dirty

surroundings can cause greater accumulation of dirt on the unit’s optics. A soft cloth and typical glass cleaning

products should be used in cleaning. It is recommended to clean the lens at least once every 20 days and clean the

reflector at least once every 30 / 60 days.

Do not use any organic solvent, e.g. alcohol, to clean the housing of the projector.

The unit is supplied with a power cord. Should any other connections be required they must be carried out with the

following configuration: Earth = Green/Yellow cord.

KEEPING THE PROJECTOR CLEAN

POWER CONNECTIONS

7/10 PRO-PAR D manual_Last Revision_en .doc

Power supply: 230VAC 50Hz

Optional: 240, 220, 120, 100V AC 50/60Hz

Power consumption: 575W at 220V

Lamp: Type: Philips MSR 575/2 discharge lamp

Colour Temperature: 7200ºK

Socket: GX9.5, single end

Manufacturers Rated Lamp Life: 1000 Hours

NetWeight: Eu mode: 16kg (include electric box 11kg)

US mode: 20Kg (include electric box 15kg)

EU mode

US mode

TECHNICAL SPECIFICATIONS

8/10 PRO-PAR D manual_Last Revision_en .doc

0m 1m

02.2

6m 5m

6.6

15 20

4.4

10 8.8 11

25 13.3

Stipple lens：19°round beam

11500

Lux 2875 1277 700 310460

10.7x18.62.7x4.7

08.0x13.95.4x9.3 16.0x27.913.3x23.3

13m

25°

11m

10m

12m 13m

0 10 15

6m 5m

2m 3m

12m 11m

10m 9m

8m 7m

302520

30°x50°

2.8x5.3

Fewer facet lens：21°X34°retangle beam

3250 360810

0.7x1.3

155 10

1.4x2.6 2.1x3.9

4m 3m

130 90200

4.2x7.9

3025

3.5x6.6

8°x15°

Clear, flat lens：14°round beam

6m 7m

Many facet lens：30°X51°oblong beam

6750 7501680 270 180420

DIAMETER

DISTANCE

6m 7m

0m 1m

0m 2.2m

5m 4.5m

10m 6.6m

15m 8.8m

20m 11m

25m 13m

30m

15000 lux 3750 lux 1660lux 930 lux 600 lux 410 lux

Lux

DISTANCE

DIAMETER

DISTANCE

DIAMETER

DISTANCE

DIAMETER

9/10 PRO-PAR D manual_Last Revision_en .doc

10/10 PRO-PAR D manual_Last Revision_en .doc

PR LIGHTING LTD.

Add: Yingbin Road, Dashi, Panyu, Guangzhou, China

Post-Code：511430

TEL：（ 020）8478 1888

FAX：（ 020）8478 6023

P/N: 321010078

Last Revision: 24:02:2004

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels PR Lighting Projecteur

PR Lighting

PR Lighting XR 1400 Spot Manuel utilisateur

PR Lighting

PR Lighting PR5000 Manuel utilisateur

PR Lighting

PR Lighting PRO-PAR Manuel utilisateur

PR Lighting

PR Lighting XLED 590 Manuel utilisateur

PR Lighting

PR Lighting XRLED 700 Spot Manuel utilisateur

PR Lighting

PR Lighting XPar 360 PR-8955 Manuel utilisateur

PR Lighting

PR Lighting XLED 1037 PR-8120 Manuel utilisateur

PR Lighting

PR Lighting XS 1200 Beam Manuel utilisateur

PR Lighting

PR Lighting AQUA 580 Manuel utilisateur

PR Lighting

PR Lighting PR-3400D Manuel utilisateur

PR Lighting

PR Lighting XR380 BEAM Manuel utilisateur

PR Lighting

PR Lighting PRO STAGE PR-3051 Manuel utilisateur

PR Lighting

PR Lighting PR5000 Spot Manuel utilisateur

PR Lighting

PR Lighting XRLED 1800-W Framing Manuel utilisateur

PR Lighting

PR Lighting LSBAR 336 Manuel utilisateur

PR Lighting

PR Lighting XR 330 SPOT Manuel utilisateur

PR Lighting

PR Lighting XPar 360-W Manuel utilisateur

PR Lighting

PR Lighting PR-2720 Manuel utilisateur

PR Lighting

PR Lighting Solo 1200 Mode d’emploi

PR Lighting

PR Lighting XPar 1514 ZOOM Manuel utilisateur

PR Lighting

PR Lighting AQUA MARINE 580 BWS Manuel utilisateur

PR Lighting

PR Lighting XR330 Framing Manuel utilisateur

PR Lighting

PR Lighting XPar 336 Manuel utilisateur

PR Lighting

PR Lighting XRLED 500 SPOT Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
