PowerTech PW320 Manuel utilisateur
Flashing Light
Control box
Push Button
Gate 2
Gate 1
SWING GATE OPENERS
PW320/PW330 USER MANUAL
FOR RESIDENTIAL
24V DC GEAR MOTOR
Applicant: Powertech Electronics Inc.
Manufacturer: Timotion Technology Co., Ltd.
Address: Shiyong Minying Industrial Zone, Hengli Town, DongGuan City, GuangDong, China
Model: PW320; PW330; PR-1
1. Certificate of conformity of a product with the essential requirements art. 3.2 of the R&TTE Directive 1999/5/EC.
2. The above product has been tested with the listed standards and in compliance with the European Directive LVD
2006/95/EC.
3. The submitted sample of the above product has been tasted for CE marking according to the following European Directives:
2006/42/EC Machinery Directive.
Comply with the following Standards:
EN 301489-1 V1.8.1: 2008
EN 301489-3 V1.4.1: 2002
EN 300220-1 V2.1.1: 2006
EN 300220-2 V2.1.2: 2007
EN 60335-1: 2002+A11:2004+A1:2004+A12:2006+A2:2006+A13:2008
EN 60335-2-103: 2003
EN 62233: 2008
EN 12445: 2001
EN 12453: 2001
And also declare that the machinery may not be put into service until the machine, which will be integrated or become one of
the components, and announced to comply with the provisions as the required.
David Lan
(Deputy Managing Director)
Taiwan, October 31, 2013
Declaration of Conformity
INSTRUCTIONS PW320/PW330 1
Index
Warnings
1. Product Description and Applications
1.1 Applications
1.2 Description of The Automation
1.3 Description of Devices
1.3.1 PW320/PW330 Electromechanical
Gear Motors
1.3.2 PC170 Control Box
1.3.3 PH-2 Photocells
1.3.4 PR-1 Radio Transmitter
1.3.5 PF-1 Flashing Light
1.3.6 PKS-1 Key Selector
1.3.7 PPB-1 Push Button
1.3.8 PEL-1 Electric Latch and PS-1 Stopper
2. Installation
2.1 Notes of Motors in Operation
2.1.1 Tools in Installing
2.1.2 Motors, Components and Its Installation
in Illustration
2.2 Power Connection
2.2.1 Notes for Power Connection
2.3 Installation
2.3.1 Preparation for Motor Installation
2.3.2 Installation of The Gear Motors
2.3.3 PKS-1 Key Selector
2.3.4 PPB-1 Push Button
2.3.5 PF-1 Flashing Light
2.3.6 PH-2 Photocells
2.3.7 PEL-1 Electric Latch and PS-1 Stopper
3. Technical Characteristics
3.1 PW320
3.2 PW330
3.3 PH-2 Photocells
3.4 PKS-1 Key Selector
3.5 PPB-1 Push Button
3.6 PF-1 Flashing Light
3.7 PR-1 Transmitter
3.8 PEL-1 Electric Latch
Annexes
CE Declaration of Conformity
2
3
3
3
3
4
4
4
4
5
5
5
5
5
5
6
6
6
6
7
7
9
11
12
12
13
14
16
16
16
16
16
16
17
17
17
INSTRUCTIONS PW320/PW330
2
Warnings
Please read this instruction manual carefully before the
installation of gate-automated system.
This manual is exclusively for qualified installation
personnel. Powertech Electronics Inc. is not responsible for
improper installation and failure to comply with local
electrical and building regulations.
Keep all the components of PW320/230 system and this
manual for further consultation.
In this manual, please pay extra attention to the contents
marked by the symbol:
Be aware of the hazards that may exist in the procedures
of installation and operation of the gate-automated
system. Besides, the installation must be carried out in
conformity with local standards and regulations.
If the system is correctly installed and used following all
the standards and regulations, it will ensure a high degree
of safety.
Make sure that the gates works properly before installing
the gate-automated system and confirm the gates are
appropriate for the application.
Do not let children operate or play with the
gate-automated system.
Do not cross the path of the gate-automated system when
operating.
Please keep all the control devices and any other pulse
generator away from children to avoid the gate-automated
system being activated accidentally.
Do not make any modifications to any components except
that it is mentioned in this manual.
Do not try to manually open or close the gates before you
release the gear motor.
If there is a failure that cannot be solved and is not
mentioned in this manual, please contact qualified
installation personnel.
Do not use the gate-automated system before all the
procedures and instructions have been carried out and
thoroughly read.
Test the gate-automated system weekly and have
qualified installation personnel to check and maintain the
system at least every 6-month.
Install warning signs (if necessary) on the both sides of
the gate to warn the people in the area of potential
hazards.
INSTRUCTIONS PW320/PW330 3
1.1 Applications
1.2 Description of the Automation
PW320/PW330 is applied for residential automation of single or dual leaf gate. PW320/PW330 has to be operated
with electricity and it’s forbidden to be operated by back-up batteries for normal use. Back-up batteries are only
allowed for emergent operation when there is a power failure, and the gear motors can be released by special keys
to move the gate manually.
The following diagram of PW320/PW330 typical installation describes some terms and accessories of a gate
automation system:
1.3 Description of Devices
A
B
C D
E
PW320/PW330 includes the accessories shown in Figure 2.
Please check the accessories the same as the package provided.
Attention: Some accessories of PW320/PW330 are not included due to local regulations or customized order.
A) 2 PW320/PW330 electromechanical gear motors with mounting brackets.
B) 2 release keys.
C) 1 pair of PH-2photocells.(one TX and one RX)
D) 2 PR-1 radio transmitters.
E) 1 PKS-1 key selector with two keys.
F) 1 PPB-1 push button switch.
G) 1 PF-1 flashing light.
H) 1 Control box
I) 1 PEL-1 electric latch.
J) 1 PS-1 stopper.
K) Various small parts: bolts, nuts, etc.
See Tables 1, 2, 3, 4, 5, 6.
Figure 2
Figure 1
1) Product Description and Applications
F
G H
I J
K
I
J
F
E
C
H
G
A
A
INSTRUCTIONS PW320/PW330
4
1.3.1 PW320/PW330 Electromechanical Gear Motors
PW320/PW330 consists of a worm screw reduction
gear and a 24V direct current motor. The gear motor
could be released manually by special release keys
when there is a power failure.
The gear motor is installed with two post brackets, one
rear plate and one front plate for the installation.
1.3.2 Control Box
Front plate 2pcs 2pcs
Rear plate 4pcs 2pcs
Post bracket 4pcs 4pcs
M8*25L hex bolt 4pcs 4pcs
M8 self-locking nut 2pcs 4pcs
M12 *25L hex bolt 0 2pcs
M12 self-locking nut 2pcs 2pcs
Release key 2pcs 2pcs
Table 1: List of small parts PW320 PW330
5*30 Screw 4 pcs
Nylon screw anchor 4 pcs
Table 2: List of small parts for Control Box Quantity
Figure 3
Figure 4
Figure 5
Figure 6
1.3.3 PH-2 Photocells
The pair of PH-2 photocells has to be installed on the
wall and connected to the control panel. The function of
the photocells is to detect the obstacles found on the
optical axis between the transmitter (TX) and the
receiver (RX).
1.3.4 PR-1 Radio Transmitter
PR-1 radio transmitter is used for the remote control of
the gate movement. To use the transmitter, press and
hold the button for 1 second. There are two buttons on
the transmitter and (A) button is “open-stop-close
mode” and (B) button is “pedestrian mode”.
1)PW320
2)PW330
3)Release Key
Control box consists of one control panel with
incorporated receiver, one transformer and two back-up
batteries.
Provides the complete automation of the gear motors
and other accessories of PW320/PW330 kit.
To connect separate terminals on the control panel and
activate the gear motors and other accessories, the
installation manual has to be carefully read beforehand.
TX
RX
INSTRUCTIONS PW320/PW330 5
3*20 Screw 3 pcs
Nylon screw anchor 3 pcs
Table 2: List of small parts for PF-1 Quantity
3*20 Screw 3 pcs
Nylon screw anchor 3 pcs
Table 4: List of small parts for PPB-1 Quantity
3*20 Screw 3 pcs
Nylon screw anchor 3 pcs
Keys 2 pcs
Table 3: List of small parts for PKS-1 Quantity
Figure 7
Figure 8
Figure 9
1.3.5 PF-1 Flashing Light
PF-1 flashing light is controlled by control box and blinks
when the gate is moving. The flashing light stops
blinking when the gates finish opening or closing.
1.3.6 PKS-1 Key selector
The PKS-1 key selector is used for opening the gate
outdoors without the radio transmitter. PKS-1 key
selector is supplied with two keys
1.3.7 PPB-1 Push Button
The PPB-1 push button is used for opening the gate
indoors without the radio transmitter.
2.1 Notes of Motors in Operation
The PW320/PW330 gate openers are applicable to per leaf of 3.0/4.0 meters in width and 250/350 kg in weight which
can be opened up to 120 degrees primarily for residential use; where the performance shall be influenced by the
factors such as gate dimension, weight and climate that the driven torque is necessarily to be adjusted properly.
2) Installation:
M8*25L hex bolt 3 pcs
M8 self-locking nut 3 pcs
Key 2 pcs
Table 6: List of small parts for PEL-1 and PS-1 Quantity
Figure 10
1.3.8 PEL-1 Electric Latch and PS-1 Stopper
PEL-1 electric latch is used to lock the gate and it has to be used
with PS-1 stopper and installed on the master gate.
INSTRUCTIONS PW320/PW330
6
Figure 11
Figure 12
2.1.1 Tools in Installing
Please make sure all tools and cables are ready and conform to the industrial safety standard before installation.
Please refer to Figure 11.
The installation procedure of PW320/PW330 may be changed due to various accessories and quantities installed.
The basic wiring diagram is shown in Figure 12.
No wiring cables for accessories are supplied with KIT PW320/PW330.
2.1.2 Motors, Components and Its Installation in Illustration
PW320/PW330 is required to connect two cores wires, which requires very low voltage that no professionally trained
personnel is required in installation; however, the users are advised to read the installation manual carefully before
going for it. After getting to know all accessories and their positions, suggest starting from cable conduit arrangement
to prevent the cables from being broken or damaged
2.2 Power Connection
1. The installation of power supply cable to the motor should be carried out by a qualified professional electrician.
2. The power supply cable of the motor should be equipped with short circuit protection and leakage protection.
Please make sure to shut off the power before going installation or maintenance.
2.2.1 Notes for Power Connection
INSTRUCTIONS PW320/PW330 7
Check the following items before going for installation:
Figure 13
Figure 14 (Aerial View)
2.3.1 Preparation for Motor Installation
2.3 Installation
PW320/PW330 is not applicable to a gate which is inefficient or unsafe, neither to solve the defects due to incorrect
installation nor poor maintenance.
1). Make sure the weight and dimensions of the gate conform to the operation range of PW320/PW330. Don’t use
PW320/PW330 if the gate specifications do not meet the requirements.
2). Make sure the gate structure conform to the criteria of automatic operation and force regulations.
3). Make sure there is no serious friction existing in the opening or closing travel of the gate leaves.
4). Make sure the gate is at horizontal level that the gate will not move aside at any position.
5). Make sure the gate can bear the impact of the motor torque when it is installed on any hole of the bracket which
the surface is sufficiently sturdy.
6). Make sure the photo sensors are installed on flat surfaces to ensure the two ends of receiving and transmitting
corresponded to each other.
7). Check the dimensions of the motors as below.
8). Make sure to leave enough space when the gate is opening.
PW320
PW320
PW330
PW330
Min
150mm
150mm(Max)
Min
150mm
150mm(Max)
INSTRUCTIONS PW320/PW330
8
Figure 16 (Aerial View)
Figure 17
Figure 15 (Aerial View)
10) . Using the leaf-opening angle as criteria to make sure all criteria in Figure 17 can be met.
11). “C” value is 139mm.
12). “D” can be measured from the gate easily.
13). “A” = “C” + “D”
14). The value of “B” can be calculated from the value of “A” and the leaves opening angle. Ex. If “A”=160mm with
the leaves opening angle of 100 degrees, then the value of “B” is approximate 190mm.
**Please make sure “B” and “A” are similar or the same in value that the leaves can be operated smoothly,
also to reduce the burden of the motor.
9). If the gate is OPENED OUTWARD, please leave at least 70mm between the post brackets and the gate.
PW320 PW330
PW320 PW330
Min
70mm
Min
70mm
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels PowerTech ouvre-porte
PowerTech
PowerTech PW220 Manuel utilisateur
PowerTech
PowerTech KIT PL600 Manuel utilisateur
PowerTech
PowerTech PA250 Manuel utilisateur
PowerTech
PowerTech KIT PL600 Manuel utilisateur
PowerTech
PowerTech PW150 Mode d’emploi
PowerTech
PowerTech PL600H Manuel utilisateur
PowerTech
PowerTech PW330L Manuel utilisateur
PowerTech
PowerTech PL500 Manuel utilisateur
PowerTech
PowerTech PL300E Manuel utilisateur
