DIGITAL ANGLE FINDER
DIGITAL ANGLE FINDER
Operation and Safety Notes
DIGITAALINEN KULMAMITTA
Käyttö- ja turvallisuusohjeet
DIGITAL VINKELMÄTARE
Bruksanvisning och säkerhetsanvisningar
KĄTOMIERZ CYFROWY
Wskazówki dotyczące obsługi i bezpieczeństwa
SKAITMENINIS KAMPAMATIS
Naudojimo ir saugos pastabos
DIGITALER WINKELMESSER
Bedienungs- und Sicherheitshinweise
GB Operation and Safety Notes Page 5
FI Käyttö- ja turvallisuusohjeet Sivu 12
SE Bruksanvisning och säkerhetsanvisningar Sidan 19
PL Wskazówki dotyczące obsługi i bezpieczeństwa Strona 26
LT Naudojimo ir saugos pastabos Psl 34
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 41
B
A
2
658
1 3
7
4
C
2
65
D
E
2
65
GB 5
Introduction..........................................................Page 6
Intended use................................................................Page 6
Scope of delivery .......................................................Page 6
Description of parts....................................................Page 6
Technical data.............................................................Page 6
Safety instructions..........................................Page 7
Safety instructions for batteries .................................Page 8
Before start of operation..........................Page 9
Insert/replace battery...............................................Page 9
Starting up the device..................................Page 9
Using the angle ruler..................................................Page 9
Troubleshooting ..........................................................Page 9
Cleaning and maintenance.....................Page 10
Disposal....................................................................Page 10
Warranty................................................................Page 11
GB
6
DIGITAL ANGLE FINDER
Q Introduction
We congratulate you on the purchase of your new
device. You have chosen a high quality product. The
instructions for use are part of the product. They
contain important information concerning safety, use and
disposal. Before using the product, please familiarise yourself
with all of the safety information and instructions for use. Only
use the unit as described and for the specified applications. If
you pass the product on to anyone else, please ensure that you
also pass on all the documentation with it.
Q Intended use
Only for private use.
Not for commercial use.
Q Scope of delivery
1x Angle Ruler
1x Battery
1x Instruction for use
Q Description of parts
1Measuring ruler
2Locking knob
3LCD display
4Battery compartment button
5ON/OFF button
6ZERO button
7Battery receptacle
8Hanging hole
Q Technical data
Measurement unit: degrees (°)
Measuring range: 0 - 360°
Resolution: 0.1°
Accuracy: ± 0.3°
Measuring system: Liner capacitive measuring system
Display: LCD display
Operating temperature: +5°C - +40 °C
Influence of humidity: within a range from 0% to 80%
relative humidity irrelevant
Battery: 3V CR2032 (included)
GB 7
Safety instructions
BEFORE USING THIS DEVICE, PLEASE
READ THE DIRECTIONS FOR USE!
PLEASE KEEP THE DIRECTIONS FOR USE
IN A SAFE PLACE!
CAUTION! RISK OF INJURY!
JKEEP THE PRODUCT OUT
OF THE REACH OF
CHILDREN. THIS PRODUCT
IS NOT A TOY! This product should
never be used by children unsupervised.
DANGER TO LIFE AND RISK OF
ACCIDENT FOR TODDLERS AND
CHILDREN! Never leave children alone
and unsupervised with the packaging
material.
JThere is a risk of suffocation from the
packaging material. Children often
underestimate risks. Always keep children
away from the product.
DANGER TO LIFE! Batteries could be
swallowed and pose a lethal hazard.
Consult a doctor immediately if anyone
swallows a battery.
JThis appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a safe
way and understand the hazards
involved. Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
JNever expose the product to high
temperatures, water or moisture as this
may damage the product.
JDo not put the angle ruler under any
strain. This may damage the chip in the
angle ruler.
JKeep the angle ruler clean and dry.
Fluids could damage the angle ruler.
GB
8
Safety instructions for
batteries
JCAUTION! RISK OF
EXPLOSION! Never recharge
the batteries!
JBatteries must not be short-circuited. This
could result in over-heating and risk of
fire or explosion.
JRemove a depleted battery from the
product immediately; otherwise there is
an increased risk of leakage!
JKeep batteries out of the reach of
children; do not throw them into fire; do
not short-circuit them; and do not take
them apart.
JEnsure polarity is correct (+ and –).
JOnly use the recommended battery
type.
JIf these instructions are not complied
with, the battery may be discharged
beyond its cut-off voltage. There is then a
risk of leakage. If the battery has leaked
into your device, please remove it
immediately in order to prevent any
damage to the product!
JWear protective gloves! If they
come into contact with skin, leaked or
damaged batteries could cause chemical
burns; you should therefore wear suitable
protective gloves at all times if such an
event occurs.
JAvoid contact with skin, eyes, and
mucous membranes. If you come into
contact with battery acid, rinse the
affected spot with plenty of water
and/or consult a doctor immediately!
J
WARNING!
Switch the product OFF
before inserting the battery (LCD
display 3is off.)
JRemove the battery from the device if it is
not in use for a long period of time.
JDo not, on any account, short-circuit the
terminals.
GB 9
Q Before start of operation
Q Insert/replace battery
Tip: Low voltage symbol showing in the LCD display 3
indicate a discharged/flat battery.
Tip: When changing the battery, the LCD display 3may
experience faults. Remove the battery and insert it again.
j Push the battery compartment button 4, and then pull out
the battery receptacle 7(see fig B).
j Remove the old battery.
j
Insert battery receptacle containing the new battery into the
battery compartment and ensure correct polarity (+ and –).
Make sure that the plus terminal points outwards.
j
Push the battery receptacle 7fully in (see Fig. B).
Q Starting up the device
Q Using the angle ruler
j Press the ON/OFF button to switch the LCD display 3on.
j
Loosen the locking knob 2by turning it anti-clockwise.
j
Put on a flat surface. Make sure both rulers
1
are aligned with
the surface (see fig. C), and then press ZERO button
6
to set
data to zero.
j
Rotate the ruler to measure the angle. Note: The locking
knob 2can be tightened by turning it clockwise, so as to
hold a desired measured angle.
j
You may also open the 2 rulers 180° straight aligned with
the surface (see fig. D), and then press ZERO button 6to
set zero. Rotate the ruler to measure the angle.
Tip: The display will show “Err”, if the ruler has been turned
over 360° (see fig. E). Turn back the ruler to the original
starting point and measure again.
Tip: The LCD display 3automatically switches itself off after
approx. 4 minutes.
Q Troubleshooting
The device contains sensitive electronic components. That is why
it experiences interference when in close proximity to radio
transmission devices. If any indication errors appear in the
display, remove such devices out of the proximity of the angle
ruler.
Electrostatic discharge could result in malfunctions.
j
When such malfunctions occur, remove the battery for a
short while and re-insert.
GB
10
Failure Cause Solution
Low voltage
symbol
shown on LCD
display 3.
The battery voltage
is lower than 2.7V.
Replace the battery
in line with the chap-
ter on “Inserting /
replacing battery”.
The LCD dis-
play 3does
not continue to
count.
Faulty wiring or
circuit
Remove battery
and re-insert after
30 seconds.
Nothing is dis-
played on the
LCD display 3.
1. LCD display is
switched off.
2. Battery is the wrong
way round or the
battery contact is
poor.
3. The battery voltage
is lower than 2.4V.
1. Switch the LCD
display on by
pressing the ON/
OFF key 5.
2. Remove the bat-
tery and insert /
replace it in line
with the terminals
and the chapter
“Inserting/repla-
cing the battery”
so that it touches
all contacts.
3. Replace the bat-
tery in line with
the chapter “In-
serting / repla-
cing the batte-
ry”.
Q Cleaning and maintenance
j
Clean the angle ruler before and after using it with a dry
cloth; never use petrol, solvents or cleaning agents.
j
Do not immerse the angle ruler into water. Liquids can
damage the angle ruler.
j
Always switch the LCD display 3off when not using the
angle ruler. This will extend the life of the battery.
j
Keep away from electrical current and electrically charged
pens to prevent damage to the chip.
Tip: You may use the hanging hole 8to store the angle ruler
after use or cleaning.
Q Disposal
The packaging is made entirely of recyclable
materials, which you may dispose of at local
recycling facilities.
Contact your local refuse disposal authority for more details of
how to dispose of your worn-out product.
