Power Max TAC-585 Manuel utilisateur

TAC-585

Semi-Commercial Treadmill User Manual

OWNER’S MANUAL

IMPORTANT: Read all instructions carefully before using this product. Retain this

owner’s manual for future reference. The specifications of this product may vary from

this photo, subject to change without notice.

www.powermaxfitness.net

TABLE OF CONTENTS

WARRANTY 2

PRODUCT BRIEF 3

SECURITY PRECAUTIONS AND WARNING 5

INSTALLATION INSTRUCTIONS 7

USING INSTRUCTIONS 9

ROUTINE MAINTENANCE AND INSTRUCTIONS 14

1 YEAR LIMITED WARRANTY

PowerMax Fitness warrants to the original purchaser that this product is free from defects in material

and workmanship when used for the purpose intended, under the conditions that it has been

installed and operated in accordance with PowerMax Fitness's Owner's Manual. PowerMax Fitness's

obligation under this warranty is limited to replacing or repairing, free of charge, any parts which

may prove to be defective under normal home use. This warranty does not include any damage

caused by improper operation, misuse or commercial application. From the date of purchase, the

frame is warranted to be free from defects for 1(one) year*.

Customer Care

Phone: +91-8080-206-206

Email: support@powermaxfitness.net

Support / Complaint Generation: support.powermaxfitness.net

This warranty is extended only to the original owner and is not transferable. When ordering

replacement parts please have the following information ready:

1. Owner's Manual

2. Model Number

3. Description of Parts

4. Part Number

5. Date of Purchase

* Terms and Conditions Apply. For T&C visit www.powermaxfitness.net

www.powermaxfitness.net

1. PRODUCT BRIEF

Single function Motorized Treadmill

Main Parameters and Parts List

Main Technical Parameters

No. Parameters Names Description

1 Rated voltage 220-240V

2 Rated frequency 50-60Hz

3 Speed 1.0-20 km/h

4 Running surface 1450 * 580mm

5 Max user weight 150kg

6 Expand dimensions 2040*930*1400mm

www.powermaxfitness.net

Accessory Bag List

No. Name Qty.

1 Screw M10*50 4

2 Screw M8*25 4

3 Inner hexagon spanner 5mm 1

4 Inner hexagon spanner 6mm 1

5 Silicon oil 1

6 User manual 1

7 MP3 Cable 1

8 Power line 1

9 Safety key 1

Packing List

No. Name Unit Qty

1 Complete machine Set 1

2 Side Cover Set 1

3 Protective cover Set 1

4 Accessory bag Set 1

www.powermaxfitness.net

2. SECURITY PRECAUTIONS AND WARNING

Note: Please read the instructions carefully before use.

♦Indoor using and storing the treadmill, avoid dampness, and cannot be spilled by water.

♦Please wear suitable clothes and sneakers before exercise. Prohibited to exercise on the

treadmill barefoot.

♦High power plug must be grounded, electric outlet should have a dedicated circuit, do not

share with other electrical equipment.

♦Keep children away from the machine to avoid accidents.

♦Avoid too long time and overload operation, otherwise will cause motor and controller

damaged, and will accelerate the deterioration of bearing, running belt and running board.

Should maintain machine on a regular basis.

♦Keep machine away from dust to avoid strong static.

♦Please cut the electric power off after using.

♦Please maintain good ventilation when running.

♦Please clamp security lock cable on your clothing to make sure the machine stops at

emergency condition.

♦If you feel not very well when using this machine, please stop and consult a doctor.

♦Silicone oil must be kept away from children after use.

♦If power cord is damaged, please contact our qualified maintenance personnel

for service rather than disassemble it at your own discretion.

Forbidden

♦Don't use the machine in the status of the shell break in or break off （the internal structure

exposed）or under the condition of welding-parts may fall off.

---- Otherwise an accident or injury may happen.

♦Don't jump up and down in the process of movement.

---- May be injuries caused by the fall.

♦Don't keep machine in or near moist space such as the bathroom.

♦Don’t place machine in direct sunlight, or high temperature places such as near a stove or a

heating appliance.

----Otherwise may cause the leakage and burst into flames.

♦Don't use when the power cord is damaged or power plug pin is loose.

----Otherwise will lead to an electric shock, short circuit or fire.

♦Don't damage or bent by force or reverse the power cord. Don’t place heavy objects on

machine, don't clamp the power line.

----Otherwise will cause fire or get an electric shock.

Tips: Before folding the treadmill, make sure that the gradient is "zero".

www.powermaxfitness.net

♦Don't use machine for more than 2 people at the same time, and don't get close to the

machine when it is in use.

---- Or it may be an accident or injury due to falls.

♦People who can’t express their consciousness or can’t operate the machine by themselves

cannot use the treadmill.

----May occur accident or injury.

♦Avoid drinking water or pouring water when operation.

---- May cause electric shock and fire. Forbidden!

♦People who seldom do exercise shouldn't suddenly do intense exercise.

♦After eating or when feel tired, do not use machine.

---- May lead damage to your health.

♦This product is suitable for family use, does not apply to schools, gymnasium and so on. ----

There is the danger of injury.

♦Don’t use when hard objects are in pants pockets.

----May cause accident or injury.

♦Don’t use when the power plug is on the needle, garbage, or water.

----May cause electric shock, short circuit, or fire. Do not use with wet hands!

♦when not in use, pull out the power plug from the socket.

----The dust and moisture can age the insulation, and result in leakage fire.

♦This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance by a person responsible for

their safety.

♦Children should be supervised to ensure that they do not play with the appliance.

Ground Protection System!

♦This product must be grounded. If the machine is dysfunctional, grounding will provide a

good channel for electric current, in order to reduce the electric shock risk.

♦This product is equipped with power plug with grounding conductor and plug. Completely

insert the plug to standard socket.

♦If the equipment grounding conductor’s connection is improper, it will cause electric shock.

If you have doubts about whether your product is grounded correct or not, please entrust

professional to check.

♦Please use the socket which has the same shape with the grounding plug. Don’t use plug

adapter.

www.powermaxfitness.net

3. INSTALLATION INSTRUCTIONS

When installing, simple fix all screws first, then tighten screws when the installation of frame is done.

1. Put the machine flat on the ground. Cut the nylon cable ties on the base. Then stand the columns

and console with the direction shown in the picture below (The machine is heavy, please ensure there

are two people to install it).

2. Use 6# inner hexagon spanner, screw M10*50, screw M8*25 to lock the columns on the base, as

shown in the picture bellow (do not tighten it).

3. Use 6# inner hexagon spanner and screw M8*25 to lock the console on the columns (do not

tighten it).

4. (Before step 5, please tighten all screws first. If it’s multifunction model, please do this step at last)

Use screwdriver to remove the preinstalled screw M5*14 and use these screws to fix the base corner

protective covers on the columns.

M10*50

M8*25

www.powermaxfitness.net

5. Silicon oil needs to be added before using the treadmill, method is as follow:

A. Open the cover of the silicon oil tube

on the front motor cover.

B. Cut the upper part of the silicon oil

bottle.

90ml Scale

C. Squeeze the silicon oil from the

hole site (not more than 90ml,

otherwise it will overflow), and

then press the cover back.

M5*14

www.powermaxfitness.net

7. Put the safety key on the picture showing place and press the start button to start the treadmill.

NOTE: please confirm that all screws are locked uniformly according to the requirements after

installation, and check no part is left out before plugging electricity.

4. USING INSTRUCTIONS

Using treadmill

1. Insert the power plug properly and turn on the switch (in red color) (1). When the light is on,

there will be beep sound, and then the screen will be light up (Systems of TFT screen takes more

time to enter the start interface).

6. Plug the power line as showing

Safety key is in red

color. Please find it in

the accessory bag.

www.powermaxfitness.net

2. Please keep the safety key away from children when the treadmill is not in use. Please put the

silicon oil bottle in places children cannot reach. If it is eaten or split into eyes by mistake, please use

water to wash and consult doctor immediately.

3. Safety key Introduction

The treadmill can only start when the safety key is put on the yellow area of the

console. Clip the safety key on clothes when using the treadmill to prevent

accidents. Put the safety key back when continue using the treadmill.

4. Folding Instructions

Fold the treadmill: It will save space when the treadmill is folded. Please turn off the switch and pull

out the power plug before folding. Lift the running deck until it is held. Unfold the treadmill: Kick the

pressure rod, hold the running deck and then let the running deck to fall gradually.

We advise to add silicon oil according to the following schedule:

A. Light user (Use the machine less than 3 hours per week): Open the motor cover once in a

month to check and make sure the oil in the oil tank is no less than 30ml.

Kick this

part to

lower the

running

deck
