Power Fist 8500613 Manuel utilisateur
2 For technical questions call: 1-800-665-8685
Digital Laser
Tachometer
Combo Set
V 3.04 8500613
SPECIFICATIONS
Accuracy ±0.05% + 1 digit
Sampling Time 0.8 Sec (over 60 RPM)
Memory Max. Value, Min. Value, Last Value
Photo Tach Measuring Distance 2 to 20 in. (50 to 500 mm)
Rotational Speed
Measuring Range
2.5 to 99,999 RPM
Resolution 0.1 RPM (2.5 to 999.9 RPM)
1 RPM (over 1,000 RPM)
Contact Tach Rotational Speed
Measuring Range
0.5 to 19,999 RPM
Resolution 0.1 RPM (0.5 to 999.9 RPM),
1 RPM (over 1,000 RPM)
Linear Contact
Tach
Line Speed
Measuring Range
0.05 to 1,999.9 m/min
Resolution 0.01 m/min (0.05 to 99.99 m/min)
0.1 m/min (over 100 m/min),
Visit www.princessauto.com for more information 3
8500613 V 3.04
Digital Laser Tachometer Combo Set
Laser Classification Class 2
Max Power Output < 1 mW
Wavelength 635 N-m
Operating Temperature 32 to 122°F (0 to 50°C)
Battery 4 x 1.5V AA batteries (included)
Size 190 × 72 × 37 mm
Weight 220g (including battery)
Housing ABS Plastic
INTRODUCTION
Accurately measure surface speed and rotation speed.
FUNCTIONS
Automatic range selection. The Max. Value, Min. Value and Last Value is
automatically stored in memory. The digital display gives exact RPM with no
guessing or errors.
SAFETY
WARNING! Read and understand all instructions before using this tool.
The operator must follow basic precautions to reduce the risk of personal
injury and/or damage to the equipment.
Keep this manual for safety warnings, precautions, operating or inspection
and maintenance instructions.
HAZARD DEFINITIONS
Please familiarize yourself with the hazard notices found in this manual.
A notice is an alert that there is a possibility of property damage, injury or
death if certain instructions are not followed.
4 For technical questions call: 1-800-665-8685
V 3.04 8500613
Digital Laser Tachometer Combo Set
WARNING!This notice indicates a specific hazard or unsafe practice that
could result in severe personal injury or death if the proper precautions
are not taken.
PERSONAL SAFETY
WARNING! Wear personal protective equipment approved by the
Canadian Standards Association (CSA) or American National Standards
Institute (ANSI).
SPECIFIC SAFETY PRECAUTIONS
WARNING! Wear personal protective equipment approved by the
Canadian Standards Association (CSA) or American National Standards
Institute (ANSI).
1. Do not expose tool to rain or wet conditions.
2. Use the correct tool for the job. This tool was designed for a
specific function. Do not modify or alter this tool or use it for an
unintended purpose.
3. Do not carry the tool with fingers near or on the
measuring button.
4. Control the tool, personal movement and the work environment
to avoid personal injury or damage to tool.
5. Do not operate any tool when tired or under the influence of
drugs, alcohol or medications.
6. Store tools properly in a safe and dry location. Keep tools out of
the reach of children.
GENERAL SAFETY PRECAUTIONS
Laser Emitter
WARNING! Laser radiation is emitted from this tool. Do not stare into
the beam. Follow all instructions and procedures in this manual when
using or adjusting the laser. Failure to follow instructions may result in
exposure to hazardous radiation.
Visit www.princessauto.com for more information 5
8500613 V 3.04
Digital Laser Tachometer Combo Set
1. This tool contains a Class II laser product that emits
laser radiation.
a. A Class II laser product does not produce damaging
radiation under normal operating condition. Magnifying the
beam can cause eye damage.
2. Do not stare into the laser aperture.
3. Be aware of laser light reflected from work surfaces. Reflective
laser radiation can cause cumulative damage.
4. Do not disassemble the laser or laser housing. Doing so may
expose the user to a radiation hazard.
5. Wear safety eyewear that will block the appropriate laser
wavelength and reduce exposure to a safe level.
PARTS IDENTIFICATION
WARNING! Do not operate the tool if any part is missing. Replace
the missing part before operating. Failure to do so could result in a
malfunction and personal injury.
Remove the parts and accessories from the packaging and inspect for
damage. Make sure that all items in the parts list are included.
Contents:
• Digital laser tachometer
• Carrying case
• Reflecting tape marks (600 mm length)
• 1 pc Contact speed measurement adapter
• 3 pc Contact rotational speed measurement adapters
6 For technical questions call: 1-800-665-8685
V 3.04 8500613
Digital Laser Tachometer Combo Set
IDENTIFICATION KEY
A Signal light beam aperture
B Measure button
C Display window
D Hold button
E Function switch
F Battery cover
G Contact tach spindle
H Speed measurement adapters
I Reflective mark (not shown)
ASSEMBLY
When this manual refers to a part number, it refers to the included Parts
Identification section.
Attached a speed measurement adapter by inserting the contact tach spindle
(G) into the opening of the adapter. A metal tab on the spindle will fit into a
slot on the adapter. Firmly seat the adapter before use.
OPERATION
The tachometer will take a measurement (non-contact or contact) and store
the values in memory for review.
1. Press the measuring button (B) to begin measurement.
2. Release the measuring button to end measurement. All
measurement results are automatically stored.
3. Press the Hold button (D) and to show the Max. value, the Min.
value and the Last value.
Visit www.princessauto.com for more information 7
8500613 V 3.04
Digital Laser Tachometer Combo Set
NON-CONTACT MEASUREMENT PREPARATION
Cut reflective tape (I) into approx. 1/2 in. (12 mm) squares, peel the backing
off and apply one square to each rotation shaft.
1. The non-reflective area must always be greater than the reflective
area for an accurate reading.
2. If the shaft is normally reflective, it must be covered with black
tape or black paint before attaching reflective tape.
3. Shaft surface must be clean and smooth before applying
reflective tape.
NON-CONTACT MEASUREMENT WITH PHOTO
1. Apply a reflective mark to the object being measured, slide the
function switch (E) to RPM PHOTO position.
2. Depress the measuring button (B) and align the Signal light
beam (A) with the reflective markers. Ensure all markers are
passing through the light.
3. Release the measuring button when the display reading stabilizes
(approximately 2 seconds). The reading is complete.
Low RPM Measurement
Measuring a low RPM rotation shaft requires the following method:
1. Attach additional reflective marks. Try to space equally on the
rotation shaft.
2. Take a reading that allows all reflective mark to pass through the
laser beam.
3. Divide the reading shown on the LCD (C) by the number of
reflective marks to obtain the real RPM.
8 For technical questions call: 1-800-665-8685
V 3.04 8500613
Digital Laser Tachometer Combo Set
CONTACT ROTATIONAL SPEED MEASUREMENT
1. Slide the function switch to the RPM CONTACT position and
install the proper adapter (H).
2. Gently press the contact adapter to the centerpoint of the
rotating shaft.
3. Press the measure button until the reading stabilizes. Release the
measuring button.
4. Break contact with the rotating shaft. The reading is complete.
CONTACT LINEAR SPEED MEASUREMENT
1. Slide the function switch to m/min. and install the linear
speed adapter.
2. Press the linear speed adapter against the moving surface.
3. Press the measuring button until the reading stabilizes. Release
the measuring button.
4. Remove the linear speed adapter from the moving surface. The
reading is complete.
IMPORTANT! Measurements should be taken on the outer surface of a
cylinder when possible. The gauge difference between the outer and
inner surface may affect the reading. To obtain a slightly more accurate
reading of an inner surface, multiply the measurement result by 0.9 to
get an approximate RPM.
Visit www.princessauto.com for more information 9
8500613 V 3.04
Digital Laser Tachometer Combo Set
CARE AND MAINTENANCE
1. Maintain the tool with care. A tool in good condition is efficient,
easier to control and will have fewer problems.
2. Inspect the tool components periodically. Repair or replace
damaged or worn components.
3. Inspect the tool components periodically. Replace damaged or
worn components.
4. When servicing, use only identical replacement parts. Only use
accessories intended for use with this tool. Replace damaged
parts immediately.
5. Maintain the tool’s label and name plate. These carry important
information. If unreadable or missing, contact Princess Auto Ltd.
for replacements.
WARNING! Only qualified service personnel should repair the tool. An
improperly repaired tool may present a hazard to the user and/or others.
TROUBLESHOOTING
Contact Princess Auto Ltd. for a solution if the tool does not function
properly or parts are missing. If unable to do so, have a qualified technician
service the tool.
