Poppstar MS30 Manuel utilisateur

MS30 USER MANUAL

Content

BRIEF INTRODUCTION.........................................................................................2

EATURE

.................................................................................................................2

ASIC PERFORMANCE

..............................................................................................2

PECIFICATION

........................................................................................................3

PRODUCT DETAILS...............................................................................................5

ACKING LIST

..........................................................................................................5

RONT VIEW

............................................................................................................5

IDE

IEW

...............................................................................................................6

ACK

IEW

.............................................................................................................7

EMOTE CONTROL

...................................................................................................8

BASIC OPERATION................................................................................................9

SAGE PREPARING

...................................................................................................9

PERATION OF FILE SHARING

................................................................................12

OPERATION OF PRODUCT USAGE ................................................................14

AIN

ENU

..........................................................................................................15

ILE

OPY

ENU

..................................................................................................20

ETUP

ENU

.........................................................................................................20

IRED

ETUP

................................................................................................24

MAINTENANCE NOTICE.....................................................................................25

COMMON FAULTS AND TROUBLE SHOOTING ...........................................26

OTHERS..................................................................................................................27

Brief introduction

Feature

The product is a new kind of multimedia player product. The product can

provide good watching. Meanwhile, it can also store and play many kinds of

video files. The product, which facilitated with many port, can show you

picture and video with high definition. It is really your desirable entertainment

products.

Basic performance

Video- MOV,WMV,MKV,MP4,AVI,MPG,TS/M2TS/TP,ISO,IFO,VOB,DAT

Audio- MP3,WMA,WAV,AAC,OGG,Dolby digital AC3

Image-JPG/BMP/PNG/GIF

USB HOST- Connection USB mass storage device

HDMI-HDMI high definition port.

Network -RJ45 port,10/100M,can connect to local internet

1080P output -Full HD 1080P (1920x1080) decoder output.

External DVD - Support USB external DVD drive to play DVD movies.

Specification

USB host Support multiple USB storage

Network

connection RJ45 10/100M connect

Video output Composite video /HDMI

Audio output Stereo/digital HDMI/Optical

Audio MP3,WMA,WAV,AAC,OGG, Dolby digital AC3

Video

Video decode

MPEG 1/2/4, Divx,Xvid, H.264,WMA,VC-1

Format:

WMV,MKV,MOV,AVI,MP4,MPG,TS/M2TS/TP,ISO,IFO,

VOB,DAT

Subtitle SSASMISRTSUB

Picture JPG/BMP/PNG/GIF

Power adapter AC input100V240V50/60HZ

DC output12V, 2A

Dimension 153.87×116.15×28.2 mm

Weight About 443g

Supported video, audio and picture formats as follow

DECODE FORMARTS RESOLUTION

VIDEO

MPEG-1 DAT 320×240

MPG 720×576

MPEG-2

VOB 720×576

MPG 1920×1080P

TS/M2TS/TP 1920×1080P

MPEG-4,

DIVX, XVID

AVI 1920×1080P

MP4 1920×1080P

MKV 1920×1080P

VIDEO

VC-1 WMV 1920×1080P

H.264

AVI 1920×1080P

MP4 1920×1080P

MOV 1920×1080P

MKV 1920×1080P

AUDIO

MP3 Support

WMA Support

WAV Support

AAC Support

OGG Support

Dolby digital AC3 Support


JPG/JPEG Support

BMP Support

PNG Support

GIF Support(support a static display only)

Note: Up to the improvement, the appearance and specification will be

changed accordingly without notice.

Product details

Packing list

Check the accessories after receive the product. If there are some missing,

please contact immediately with your supplier to insure your consumer’s

right.

No. Name Quantity

1 Media player 1 pcs

2 Power Adapter 1 pcs

3 Remote Controller 1 pcs

4 AV cable 1 pcs

5 User Manual 1 pcs

6 Batteries 2 pcs

7 Screws several

Front view

Button description

Button Description Remark

Power on/off A short press on the button

turns on or turns off power

IR

Infrared receiver

Receives signals from the

remote control. Point the

tip of the remote control to

the infrared receiver and

ensure that the path

between the two is

unobstructed.

Side View

Interface description

Description Remark

USB HOST Support multiple external USB

storage devices

3-in-1 card reader Support MS, SD, MMC

How to use memory cards: The Product has an integrated multimedia card

reader supporting memory cards including MS, SD, and MMC. Gently insert

the memory card into the reader with the arrow side upward until there goes a

“click” sound.

Back View

Port definition

Port Port definition Instruction

DC IN Power port Can input power

～ Optical Audio output

port Can output digital audio

signal



AV Composite

video output port Can output composite video

and audio

HDMI High definition

port Can output digital signal via

HDMI port

LAN Network port Can connect to network via

internet port

USB HOST Outside USB

port Can read outside USB

storage via USB port

Remote control

BUTTON FUNCTION

POWER Turn on and off in the stand by mode

MUTE Turn on or shut audio output

TV SYSTEM Press to switch between NTSC

, PAL, 480P, 576P,

720P 50HZ, 720P 60HZ, 1080I 50HZ and 1080I 60HZ,

1080P 50HZ,1080P 60HZ.

0-9 Press to input digital

GOTO

Press to play the video at the chapter after setting

schedule

GUIDE Switches to the main menu.

FR Press t

o fast rewind from current play and again to

select the speed

Press to fast forward from current play and again to

select the speed

RETURN Return to the previous menu

SETUP Opens the settings menu

Press shortly to move cursor left

Press shortly to move cursor right

Press shortly to move cursor up

Press shortly to move cursor down

OK Press this button confirms a selection and starts the

playback of a media file.

PREV Press to return to previous file

NEXT Press to go to next file

VOL- Press to decrease the volume

VOL+ Press to increase the volume

OPTION Opens the options menu in the browser t

o rename or

delete the file

STOP Ends the playback of a media file

PALY/PAUSE Starts or pauses the playback

REPEAT Press to set repeat option: chapter, Title or off

COPY Enter the copy mode

SELECT Press to select copy files or folders in the copy mode

CONFIRM No role for the time being

DISPLAY

Press to display time, title, information of chapter when

play video and photo

SUBTITLE Switch the subtitle if the file supported

SLOW Press to have slow motion:1X, 3/4X1/2X1/4X1/8X

1/16X.Press PLAY to resume regular play mode.

AUDIO Switch the audio format output

ZOOM

Press to zoom when playing back photos or Video

programs

Photo zoom levels: 2X,4X,8X,16X

Video zoom levels: 1X,2X,3X,4X,8X

ALL Presses this key, show all files

MUSIC Presses this key, show all audio files

PHOTO Presses this key, show all picture files

MOVIES Presses this key, show all video files

Basic operation

Usage preparing

1



Power connection

Take out power adapter from the package and connect it.

2



Connection of TV audio output

The product is designed with multi-output, including composite(AV) and

HDMI. Individuals can select different interface according various need. The

product can detect video output automatically, making the operation friendly

and convenient. Please refer to the following instruction for connection to

avoid any problem.

Composite output connection(AV)

Plug the yellow connector into the AV output of product and AV input of TV,

and plug the red and white connector into the audio input of TV or HIFI. Turn

on the TV and select AV mode. Turn on the product and TV displays the

interface of initiation.

HDMI output mode

HDMI is a output with best audio and video effect which outputs digital video

and audio composited at the same time. Connect HDMI cable to output of

product and display device with HDMI input. Select HDMI mode in TV until it

displays the interface of initiation.

Optical output mode
