Polycom Collaboration Server (RMX) 1800 Instructions d'installation

[Type the document title]

Polycom Document Title 1



Version 8.1.8 |September 2013 |3725-69957-002/A

Polycom® RealPresence®

Collaboration Server (RMX) 1800

Hardware Guide

Polycom, Inc.

6001 America Center Drive

San Jose CA 95002

USA

No part of this document may be reproduced or transmitted in any form or by any means, electronic or

mechanical, for any purpose, without the express written permission of Polycom, Inc. Under the law,

reproducing includes translating into another language or format.

As between the parties, Polycom, Inc., retains title to and ownership of all proprietary rights with respect to

the software contained within its products. The software is protected by United States copyright laws and

international treaty provision. Therefore, you must treat the software like any other copyrighted material (e.g.,

a book or sound recording).

Every effort has been made to ensure that the information in this manual is accurate. Polycom, Inc., is not

responsible for printing or clerical errors. Information in this document is subject to change without notice.

Trademark Information

POLYCOM® and the names and marks associated with Polycom's products are trademarks and/or service

marks of Polycom, Inc., and are registered and/or common law marks in the United States and various other

countries.

All other trademarks are the property of their respective owners.

Patent Information

The accompanying product may be protected by one or more U.S. and foreign patents and/or pending patent

applications held by Polycom, Inc.

Table of Contents

Polycom, Inc i

Table of Contents

Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Main Features ............................................................................................................................. 1

RealPresence Collaboration Server 1800 Specifications ....................................................... 2

RealPresence Collaboration Server 1800 System Capacities ............................................... 3

Conferencing Capacities ........................................................................................... 3

Resource Capacities ................................................................................................... 4

Site Requirements ...................................................................................................................... 6

Safety Requirements ......................................................................................................... 6

Shelf Mount Safety Precautions ...................................................................................... 6

Installation Precautions .................................................................................................... 6

Installing the RealPresence Collaboration Server 1800 ................................................ 7

Unpacking the RealPresence Collaboration Server 1800 ..................................... 7

Mounting the RealPresence Collaboration Server 1800 on a Shelf .................... 8

Connecting the RealPresence Collaboration Server 1800 to a Power Source ........... 8

Connecting the RealPresence Collaboration Server 1800 to AC Power ............ 8

Connecting Cables to the RealPresence Collaboration Server 1800 ........................... 9

First-time Power-up .......................................................................................................... 9

RealPresence Collaboration Server 1800 Front Panel ................................................. 10

RealPresence Collaboration Server 1800 Rear Panel .................................................. 11

Appendix A Regulatory Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Important Safeguards ..................................................................................................... 13

Regulatory Notices .......................................................................................................... 13

USA and Canadian Regulatory Notices .................................................................. 13

EU Regulatory Notices .............................................................................................. 14

Japan .......................................................................................................................... 14

Chinese ....................................................................................................................... 14

Korea .......................................................................................................................... 14

Polycom, Inc. 1

Hardware Description

This Hardware Guide provides information on the RealPresence Collaboration Server 1800

and its components.

Main Features

The Polycom RealPresence Collaboration Server 1800 offers the following features:

•Linux®based

• Support for standard network ports (H.323, SIP, and LAN)

• New hardware codec technologies

• Up to 1080p 60 high definition video conferencing

• Telecommunication grade high availability and on-line upgrading

• Easy integration of conference elements into external network management

• Enhanced Continuous Presence (multi-image video)

• IVR (Interactive Voice Response) module

Illustrations in this book are for your reference only and may not accurately depict the actual system.

RealPresence Collaboration Server 1800 Hardware Guide

Polycom, Inc. 2

RealPresence Collaboration Server 1800 Specifications

Table 1-1 RealPresence Collaboration Server 1800 Specifications

Physical

Height 2U (8.9 cm.)

Width 17.36 '' (44.1 cm.)

Depth 191.34 '' (486 cm.)

Weight Up to 14.5 Kg (31.97 lbs)

Media Protocols

Audio G.711, G.722.x, G.729A, Siren 14, Siren 22 (in mono or

stereo) and Siren LPR.

Video H.261, H.263, H.263+, H.264, H.264 High Profile

Network ports

IP H.323, SIP

, VoIP

LAN LAN 1, LAN 2

Power Supply

AC Input/ Range, Power output Voltage range: 100-240 VAC 50-60 Hz.

Current: 10-3.5 AMP

Maximum power output: 740 Watts.

Power Consumption

AC Maximum Power consumption 350 Watts.

Environment

Operating temperature 10° to 35°C (50° to 95°F).

Storage temperature -40° to 70°C (-40° to 158° F).

Relative humidity 20% to 90% non-condensing.

Operating altitude Up to 2 KM (6 562 Ft.)

Operating ESD 4 KV.

RealPresence Collaboration Server 1800 Hardware Guide

Polycom, Inc. 3

RealPresence Collaboration Server 1800 System Capacities

Conferencing Capacities

The following table summarizes the different system capacities.

System Functions Number

Maximum number of Video participants in a conference 100

Maximum number of Audio-only participants in a conference 100

Maximum number of Audio calls per second 5

Maximum number of Video calls per second 2

Maximum number of conferences 200

Maximum number of Meeting Rooms 1000

Maximum number of Entry Queues 40

Maximum number of Profiles 40

Maximum number of Conference Templates 100

Maximum number of SIP Factories 40

Maximum number of IP Services 2

Maximum number of IVR Services 40

Maximum number of Recording Links 20 (Default)

Maximum number of IVR Video Slides 150

Maximum number of Log Files (1Mb max.) 4000

Maximum number of CDR Files 2000

Maximum number of Fault Files 1000

Number of Participant alerts No limitation

Maximum number of concurrent RealPresence Collaboration Server 1800

Web Client connections to the MCU

Maximum number Address Book entries 4000

Maximum number of Users 100

Maximum number of Reservations (internal Scheduler) 2000

RealPresence Collaboration Server 1800 Hardware Guide

Polycom, Inc. 4

Resource Capacities

The following table lists the resource capacity in various system configurations.

The following table shows the number of video port consumed by each type of video

resolution.

Resource Type/Video Resolution

(Resolutionunit:720p30)

3 Video

Acceleration

Cards

2 Video

Acceleration

Cards

1 Video

Acceleration Card

Audio-only 100 70 35

H.261 CIF p30 50 35 15

H.263 CIF p30 100 70 35

H.264 CIF p30 100 70 35

H.264 CIF p60 100 70 35

H.263 4CIF p30 100 70 35

H.264 4CIF p30 100 70 35

H.264 4CIF p60 100 70 35

H.264 720p 30 100 70 35

H.264 720p 60 50 35 17

H.264 1080p 30 50 35 17

H.264 1080p 60 25 17 8

Resource Type/Video Resolution

(Resolutionunit:720p30)

3 Video

Acceleration

Cards

2 Video

Acceleration

Cards

1 Video

Acceleration Card

H.261 CIF p30 2 2 2

H.263 CIF p30 1 1 1

H.263 4CIF p30 1 1 1

H.264 CIF p30 1 1 1

H.264 CIF p60 1 1 1

H.264 4CIF p30 1 1 1

H.264 4CIF p60 1 1 1

H.264 720p 30 1 1 1

H.264 720p 60 2 2 2

H.264 1080p 30 2 2 2

H.264 1080p 60 4 4 4

RealPresence Collaboration Server 1800 Hardware Guide

Polycom, Inc. 5

The audio-only call resource of the RealPresence Collaboration Server 1800 system is independent

of video call resource.

RealPresence Collaboration Server 1800 Hardware Guide

Polycom, Inc. 6

Site Requirements

This section describes the requirements your site must meet for safe installation and

operation of the system.

Safety Requirements

For your protection, please read these safety instructions completely before operating the

equipment.

• Look carefully for potential hazards in your work area: moist floors, ungrounded

power cables, frayed power cords, missing safety grounds and so forth.

• Locate the main circuit breaker within the room.

• Locate the emergency power OFF switch within the room.

• Never assume that power is disconnected from a circuit.

• Use only the power cord supplied with the system.

• The power cord should only be connected to a power outlet that has a protective

ground contact.

• Ensure that the power cord is easily accessible from the back of the system at all times.

• Place the equipment in a well-ventilated area where the vents are free from obstruction.

• Do not place heavy objects directly on top of the RealPresence Collaboration Server

1800 unit.

• Do not use liquids around your equipment.

Shelf Mount Safety Precautions

The following precautions should be followed with regards to rack mount safety:

• Keep the area around the RealPresence Collaboration Server 1800 clean and free of

clutter.

• Decide on a suitable location for the equipment rack that will hold the RealPresence

Collaboration Server 1800 unit. It should be situated in a clean, dust-free area that is

well ventilated. Avoid areas where heat, electrical noise and electromagnetic fields are

generated. You will also need it placed near a grounded power outlet.

• Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor

with the full weight of the rack resting on them.

• Install the heaviest components on the bottom of the rack first, and then work up.

• Allow the power supply units to cool before touching them.

Installation Precautions

The following precautions should be followed with regards to installation of the

RealPresence Collaboration Server 1800:

When handling electronic components, standard anti-static precautions must be observed:

•Wear a grounding strap

•Keep components in anti-static bags, when not installed in the RealPresence Collaboration

Server 1800.

RealPresence Collaboration Server 1800 Hardware Guide

Polycom, Inc. 7

• Use a regulating uninterruptable power supply (UPS) to protect the RealPresence

Collaboration Server 1800 from power surges and voltage spikes, to keep your MCU

operating in case of a power failure.

• Place the RealPresence Collaboration Server 1800 on a hard, flat surface such as a

desktop or mount it on 19” rack.

• The airflow of the RealPresence Collaboration Server 1800 is from front to back. Be sure

that the areas in the front and rear side of the system are clear for proper ventilation.

Installing the RealPresence Collaboration Server 1800

The following procedures have to be performed to install the RealPresence Collaboration

Server 1800 in your site:

• Unpacking the system

• Installing the system in a rack or as a standalone system

• Connecting the system to the power source

• Connecting the network (LAN and IP) cables to the system

Unpacking the RealPresence Collaboration Server 1800

To unpack and lift the RealPresence Collaboration Server 1800:

1When you receive the RealPresence Collaboration Server 1800 packing case, inspect the

equipment for damage and verify that the components match the packing slip.

2Open the top cover of the packing case.

Boxes are placed on the top Stratocell® and contain power cables, 2 ethernet cables,

USB key and documentation.

Make sure that boxes contain all the required parts.

Sealed System! The RealPresence Collaboration Server 1800 is a sealed system, breaking the

seal and opening the chassis VOIDS the WARRANTY!

Write down the system’s serial number that is on a sticker on the back of the unit. It will be needed

for product registration later in the process.

Autres manuels pour Collaboration Server (RMX) 1800

Table des matières

Autres manuels Polycom Serveur

Polycom

Polycom RSS 2000 Manuel utilisateur

Polycom

Polycom RSS 4000 Manuel utilisateur

Polycom

Polycom RSS 2000 Manuel utilisateur

Polycom

Polycom KIRK Wireless Server 6000 Manuel de l'opérateur

Polycom

Polycom RealPresence RMX 4000 Instructions d'installation

Polycom

Polycom RealPresence Manuel utilisateur

Polycom

Polycom RealPresence Collaboration Server Virtual Edition... Manuel utilisateur

Polycom

Polycom KIRK 8000 Manuel utilisateur

Polycom

Polycom RSS 2000 Manuel utilisateur

Polycom

Polycom KIRK 600v3 Manuel utilisateur

Polycom

Polycom realpresence 1800 Instructions d'installation

Polycom

Polycom Realpresence collaboration server 1500 Manuel de service

Polycom

Polycom SpectraLink 8000 System Mode d’emploi

Polycom

Polycom RMX 2000 Instructions d'installation

Polycom

Polycom Collaboration Server (RMX) 1800 Instructions d'installation

Polycom

Polycom RealPresence RMX 1500 Series Fiche technique

Polycom

Polycom Realpresence collaboration server 1500 Manuel de service

Polycom

Polycom RSS 2000 Manuel utilisateur

Polycom

Polycom 3725-32870-002 Manuel utilisateur

Polycom

Polycom KIRK Wireless Server 6000 Manuel utilisateur

Polycom

Polycom Collaboration Server (RMX) 2000 Instructions d'installation

Polycom

Polycom RealPresence RMX 4000 Instructions d'installation

Polycom

Polycom Realpresence collaboration server 1500 Instructions d'installation

Polycom

Polycom RealPresence 800s Manuel de service

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
