Polycom KIRK 7020 Manuel utilisateur
Polycom® KIRK®
7010/7020/7040
Charge your handset 14-16 hours
prior to first use for best performance
Quick Guide
For more information about the
handset, refer to user guide available
for download at
www.polycom.com
Volume
Control
isplay
Left
Softkey
Call
Transfer
Right
Softkey
On/Off
Hook
Microphone
Four Way
Navigation
Key
Headset
Connector
Tear Off
Unit
LE Alarm Button
14184661-HD, ED. 1.fm Page 1 Friday, February 26, 2010 8:38 AM
2
Basic Handset O tion
Turning Handset On/Off
•
To turn on the handset, press left
softkey
.
• To turn off the handset, press left
softkey until the question
Turn
off?
appears in the display. Confirm
with
Yes.
Adjusting S eaker Volume
Use the key placed at the upper right side
of the handset for volume control.
Locking Key ad
• Press
Menu
followed by
to lock
keypad
.
• Press
Unlock
followed by
to unlock
keypad
.
Shortcuts
Predefined Shortcuts
Predefined shortcuts are unchangeable
and assigned to different keys on the
handset
.
Silent mode On/Off
:
Press the
Menu
button, followed by the
#
b
utton to turn
the handset silent mode on/off. In silent
mode the ringer will be muted and the
vibrator activated
.
Call transfer
:
While off hook, press
R
.
Call list: Press left side of the navigation
key to enter Call list
.
Missed Calls: Press right side of
navigation key.
14184661-HD, ED. 1.fm Page 2 Friday, February 26, 2010 8:38 AM
3
Find Name: Press top or bottom of
navigation key.
Exit Menu: Whilst navigating menus,
press the
R
button to exit out of the menu
and go back to the main screen.
Save contact: ial number and press
Save
.
Personal Shortcuts
Personal shortcuts consist of functions,
you have chosen to add from a list of
shortcuts. The list is assigned to the right
softkey.
To add a shortcut
:
1 Press
Shortcut
.
2 Scroll to
Edit shortcut
Edit shortcutEdit shortcut
Edit shortcut
and press
Select
.
3 Press
Select
to add the function to
the list of personal shortcuts.
To use a shortcut
:
1 Press
Shortcut
.
2 Scroll to the desired shortcut and
press
Select
.
Making Calls
Off Hook Dialling (Dial Directly)
1 Press
to make a call.
2 ial number.
3 Press to terminate the call.
On Hook Dialling (Pre-Dial)
1 ial number.
2 Press to make a call.
3 Press
to terminate the call.
14184661-HD, ED. 1.fm Page 3 Friday, February 26, 2010 8:38 AM
4
S eed Dial
• Press a key (0-9) continuously for three
seconds until a call is started. (You must
assign a key to a number in Phone
Book).
Assigning S eed Dials
1 Press the
Menu
MenuMenu
Menu
button to enter the
main menu.
2 Scroll the
Phone Book
and then press
the
Select
button.
3 Scroll to
Speed dial
and then press the
Select
button.
4 Scroll to the appropriate speed dial
entry (0-9) and then press the
Add
name
button.
5 Select the appropriate phone book
entry and press the
K
button.
6 Select the appropriate number and
press the
K
button.
From Call List
1 Press left side of navigation key to
enter Call list.
2 Scroll to desired name or number and
press .
From Phone Book
1 Press
Menu
to enter main menu.
2 Scroll to
Phone Book
and press
Select
.
3 Scroll to
Find name
and press
Select
.
4 Find the desired name and press
to make a call.
14184661-HD, ED. 1.fm Page 4 Friday, February 26, 2010 8:38 AM
5
Answering Calls
• Press to answer a call when your
handset rings.
Mute a Call
• Press
Silence
and the ring signal is
muted.
Reject a Call
Press
Reject
to refuse the call.
Call Transfer
• Press
R
and dial number.
To withdraw the call, press
R
again.
Note: The feature is system dependent.
Turning S eaker hone On/Off
(Not available on 7010)
• While on a call, press
Loud on
to turn
speakerphone on.
• Press
Loud off
to turn speakerphone
off.
Turning Micro hone Mute On/Off
• While on a call, press
Mic Mute
to turn
microphone mute on.
• Press
Mic on
to turn microphone mute
off.
Changing Settings
Adjusting Ringing Volume
1 Press
Menu
to enter main menu.
2 Scroll to
Settings
and press
Select
.
3 Scroll to
Ringing volume
and press
Select
.
4 Press left or right side of navigation
14184661-HD, ED. 1.fm Page 5 Friday, February 26, 2010 8:38 AM
6
key to adjust the volume.
5 Press
Set
SetSet
Set
and then
Back
.
Changing Ringing Tone
1 Press
Menu
to enter main menu.
2 Scroll to
Settings
and press
Select
.
3 Scroll to
Ringing tone
and press
Select
.
4 Scroll to desired ringing tone and
press
Change
to listen to chosen
ringer tone.
5 Press
Back
.
Turning Vibrator On/Off
(Not available on 7010)
1 Press
Menu
to enter main menu.
2 Scroll to
Settings
and press
Select
.
3 Scroll to
Vibrator
and press
Select
.
4 Scroll to
n
or
ff
and press
Change
.
5 Press
Back
.
Adding Contact to Phone
Book
1 Press
Menu
to enter main menu.
2 Scroll to
Phone Book
and press
Select
.
3 Scroll to
Add name/number
and press
Select
.
4 Type the name of the contact using
the keys 2-9.
5 Scroll to number and enter the
number of the contact (max. 24
digits).
6 Press
Save
to store the name and
number.
Handset O tions Status
To display the status of the handset
options (Battery, ringer volume, firmware
14184661-HD, ED. 1.fm Page 6 Friday, February 26, 2010 8:38 AM
7
etc.).
1 Press the
Menu
button to enter the
main menu.
2 Scroll to
Status
and then press the
Select
button.
3 Press the Top or Bottom of the
navigation key to highlight the
appropriate menu item and then
press the
Select
button to enter the
selected items menu.
4 Press the
Back
button.
Activate Bluetooth Function
(
7040 feature only
)
1 Press
Menu
to enter main menu.
2 Scroll to
Settings
and press
Select
.
3 Scroll to
Bluetooth
and press
Select
.
4 Scroll to
Active
and press
Select
.
5 Scroll to
n
and press
Select
.
Pair Wireless Headset with the
Handset
1 Press
Menu
to enter main menu.
2 Scroll to
Settings
and press
Select
.
3 Scroll to
Bluetooth
and press
Select
.
4 Scroll to
Search
for compatible
Bluetooth headset and press
Select
.
5 Select the headset code number listed
in the display of the handset and
press
Stop
, then press
Add
.
6 Enter pin code and press
K
(Consult
the user guide of the Bluetooth
headset for the pin code information).
7 Press
K
, and press
ptions
in order
to connect to the headset.
8 Scroll to
Connect
and press
Select
.
9 Press
K
.
14184661-HD, ED. 1.fm Page 7 Friday, February 26, 2010 8:38 AM
8
Auto Connect
1 Press
Menu
to enter main menu.
2 Scroll to
Settings
and press
Select
.
3 Scroll to
Bluetooth
and press
Select
.
4 Scroll to
Active
and press
Select
.
5 Scroll to
Settings
and press
Select
.
6 Activate
Auto connect
by pressing
Select
, then press
Back
. The wireless
headset will now connect
automatically to the handset when
the headset is turned on.
Headset Volume
1 Press
Menu
to enter main menu.
2 Scroll to
Settings
and press
Select
.
3 Scroll to
Bluetooth
and press
Select
.
4 Scroll to
Active
and press
Select
.
5 Scroll to
Settings
and press
Select
.
6 Scroll to
Headset
volume and press
Select
.
7 Press left or right side of navigation
key to adjust the volume.
Switch Between Headset and
Handset
When the headset is active and the hand-
set is off hook,the audio can be switched
between the headset and the handset.
1 Activate handset / headset soft key by
pressing the left or the right side of
the navigation key.
2 Press
Handset
, and the audio is
switched to the handset.
3 Press
Headset
, and the audio is
switched back to the headset.
Battery
The battery is connected to the handset
from factory and must not be removed.
To replace the battery, please contact your
local distributor.
14184661-HD, ED. 1.fm Page 8 Friday, February 26, 2010 8:38 AM
9
Technical S ecification
Approvals
Generic Access Profile: EN 300444 V1.4.1:
2002
EMC: EN 301 489 - 1: Version 1.6.1
EN 301 489 - 6: Version 1.2.1
Radio: EN 301 406 V1.5.1
Safety: EN 60950 - 1: 2006
Size and weig t
Size: 148 x 50.4 x 21.6mm
Weight: 123g incl. battery ± 10g
Capacity 7010/7020/7040
Active talking time up to 20 hours
Standby time up to 200 hours
Capacity 7040 wit bluetoot turned on
Active talking time up to 15 hours
Standby time up to 100 hours
Temperature
Operating temperature incl. charging:
0-40°C
IP Rating
According to EN60529
7010: IP54 ( ust protected and water
splash proof)
7020/7040: IP64 ( ust tight and water
splash proof)
Drop Test
According to IEC 60068-2-31 (2008-05)
Vibration Test
According to IEC 60068-2-6 (2007-12)
Bump Test
According to IEC 60068-2-27 (2008-2)
Disinfectant Resistant Handset
14184661-HD, ED. 1.fm Page 9 Friday, February 26, 2010 8:38 AM
10
International Regulatory and
Product Information
This KIRK 7010/7020/7040
Handset has been marked
with the CE mark. This
mark indicates compliance
with EEC irectives 89/
336/EEC, 73/23/EEC
1999/5/EC. A full copy of
the eclaration of
conformity can be obtained
from Polycom Ltd, 270
Bath Road, Slough,
Berkshire, SL1 4 X, UK.
The WEEE Marking on this
equipment indicates that
the product must not be
disposed of with unsorted
waste, but must be
collected separately.
Visit www.polycom.com
for further guidance on
battery recycling.
14184661-HD, ED. 1.fm Page 10 Friday, February 26, 2010 8:38 AM
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels Polycom Combiné
Polycom
Polycom VVX 300 Manuel utilisateur
Polycom
Polycom VVX 500 series Manuel utilisateur
Polycom
Polycom SpectraLink 6020 Instructions de montage
Polycom
Polycom VVX D60 Manuel utilisateur
Polycom
Polycom KIRK 5020 Manuel utilisateur
Polycom
Polycom Diagnostic Handset 1610 Manuel utilisateur
Polycom
Polycom KIRK 4020 Manuel utilisateur
Polycom
Polycom KIRK 2010 Manuel utilisateur
Polycom
Polycom KIRK KIRK 4040 Manuel utilisateur
Polycom
Polycom KIRK 4020 Manuel utilisateur
Polycom
Polycom SoundPoint IP 320 Manuel utilisateur
Polycom
Polycom SpectraLink 1725-36092-001 Manuel utilisateur
Polycom
Polycom VVX410 Manuel utilisateur
Polycom
Polycom KIRK KIRK 4040 Manuel utilisateur
Polycom
Polycom KIRK Manuel d'installation et d'exploitation
Polycom
Polycom KIRK 6020 Manuel utilisateur
Polycom
Polycom VVX 300 Manuel utilisateur
Polycom
Polycom PENNNET 650 Manuel utilisateur
Polycom
Polycom SoundPoint IP 32 Series Manuel utilisateur
Polycom
Polycom SpectraLink 8450 Manuel utilisateur
