PNI CT25PE Manuel utilisateur
PNI CT25PE
Smart thermostat / Интелигентен термостат
Intelligenter Thermostat / Termostato inteligente
Thermostat intelligent / Intelligens termosztát / Termostato
intelligente / Slimme thermostaat / Inteligentny termostat
Termostat inteligent incastrabil
EN User manual .................................... 3
BG Ръководство за употреба .......... 22
DE Benutzerhandbuch ......................... 44
ES Manual de usuario ........................... 65
FR Manuel utilisateur ........................... 86
HU Használati utasítás .......................... 107
IT Manuale utente ............................... 128
NL Handleiding ..................................... 149
PL Instrukcja obsługi ............................ 172
RO Manual de utilizare .......................... 191
3
Introduction
PNI CT25PE is a programmable flush mounted thermostat
for electric underfloor heating, which turns the heating
system on and o according to the set temperature. You
can set dierent temperatures for dierent time periods
and days.
The thermostat can work and display the temperature in 3
ways:
- according to the floor sensor
- according to the built-in air sensor
- according to both sensors
How quickly the air in the room heats up does not depend
on the settings of the thermostat, but on the size and the
design of the heating system.
The thermostat has a direct 230V output for electric
underfloor heating systems.
4
Special warnings
As the product must be connected to a 230V mains
supply and to a heating equipment, the installation must
be performed only by qualified personnel, in order to
avoid irreparable damage to the product or to the heating
equipment to which it is connected, defects which are not
subject to warranty.
Forthe first configuration of thethermostat,we recommend
that you call a specialist.
Main features
• Illuminated LCD screen
• 3 operating modes : Eco, Manual and Scheduled
• 4 programmable periods for each day of the week
• Display the set temperature and the room temperature
• Opened window detection function
• Key lock function
• Anti-freeze function
5
Technical specifications
• Power supply: 230V
• Maximum load: 16A
• Temperature range that can be set: 5°C ~ 35°C
• Displayed temperature range: 0 ~ +50°C
• Sensor: NTC 10K
• Temperature measurement accuracy: ± 0.1°C
• Temperature setting step: ± 0.5°C
• WiFi 2.4Ghz
• Transmission power: 100mW
• Water resistance: IP30
• Housing: ABS with fire standard UL94-5
6
Product description
Up
Child protection active
(keys locked)
No external sensor
alarm
Over-heating
protection
WiFi signal level
On/Off
Settings
Down
Open window
detection
Hour
Day of the week
Current period
7
Connecting the thermostat to the WiFi network
and adding it to the Tuya Smart application
Note: Make sure you have your mobile phone connected to the
2.4GHz WiFi network and the GPS location enabled. For a
quick setup, make sure the phone and thermostat are as close to
each other as possible (1-3 m).
WARNING:
Make sure you have a 2.4 Ghz wireless network available and
that you have connected your phone to it. The new generation
routers and phones also come equipped with a 5 Ghz wireless
network activated, and the devices connect automatically on
this frequency. The thermostat cannot be connected to the
5 Ghz wireless network because it only works on the 2.4 Ghz
frequency. To configure the router and the 2.4 Ghz wireless
network, call a specialist.
8
1. Connect your phone to the WiFi network.
2. Download the app Tuya Smart.
Android iOS
3. Open the application, create an account and log in.
4.Add the thermostat to the application by pressing the +
icon in the upper right corner of the screen or by pressing
the Add device button (this button shows only when you
do not have any devices added to the application).
5. Select the option Small Home Appliances on the left side
of the screen.
6. From the list of devices displayed on the right side of the
screen, select Thermostat (Wi-Fi).
7. Select the WiFi network you want to connect to and add
9
the password. Click Next.
8.In the next interface, select the option EZ Mode from the
upper right corner.
9. Long press the key from the thermostat to enter the
pairing mode. Then, press the key ˄. The icon will
blink on the screen.
10. Then check Confirm the indicator is blinking rapidly.
Click Next.
11. The application will start scanning nearby devices.
12. After you identify your device, you will receive the
Added Successfully confirmation.
13. To finish, click the Done button.
From the application, you can turn the thermostat on and
o, you can change the operation mode of the thermostat
(Manual, Eco, Auto) or you can set the weekly program.
10
