Stealth installaon
Stealth installaon guide
Also applicable to: Stealth+, Stealth M, Stealth M+
Be aware:
The Stealth is specically designed
to be built in to an appliance/lighng
xture or as a permanently connected
device in the electrical installaon of
a building. Installaon should always
be executed by a registered installer
in compliance with the local electrical
code (e.g. BS 7671 or NEC).
It is required to include an overcurrent protecve device (circuit breaker),
that support a maximum rang of 16A (depending on your localisaon). Be
sure to switch o the circuit before installing the Stealth!
The product should be installed in a closed ame retardant casing with a
proper strain-relief mechanism.
Use the L↑ labelled clamp to connect the phase wire to the appliance and
connect the neutral wire to one of the ‘N’ labelled clamps. Then connect
the incoming phase wire to the clamp labelled ‘L’ and the neutral wire to
the free ‘N’ connecon.
For double phase 230V networks the second phase can be connected to the ‘N’ poles
(it will not be switched).
Informaon for the installer
Technical details
Voltage: 100-240 V~ Frequency: 50 / 60 Hz Total max. current: 16 A*
If a normal Stealth with relay is used, these addional maximum rangs apply:
• Inducve load: 4A
• Capacive load: 1A
Exceeding these rangs will adversely aect the service life of the relay!
Dimensions:
57.1 x 39 x 21 mm
ZigBee Dynamic MESH
2.4 GHz
* Total max. current Stealth M and M+ : 20A.
All specicaons without prejudice.
See www.plugwise.com for detailed informaon.
Be wise, plug in.
Stealth installaon
Stealth installaon guide
1. Insert screwdriver and move in the direcon of the arrow (up)
2. Insert wire
L L N
Appliance/ circuit
Inverter
N
L
Be aware:
Connect the L↑ (black line) to the appliance to be measured (in this
example the inverter of the solar panel).
Be wise, plug in.
Stealth installaon
Verify the installaon
You can verify the installaon without the need of WiFi/ LAN:
Make sure you have installed the Stealth and Stretch 2.0.
Remember, the Stretch 2.0 must not be connected to LAN!
1. Connect the adapter with the Stretch 2.0 and the wall socket. The Stretch
2.0 will start in WiFi access point mode.
2. Connect your smartphone (installer) with the network of the Stretch via
the WiFi access point.
Password: The Stretch ID (see scker)
3. Go to : hp://192.168.40.40 via the mobile browser on your smartphone.
The Stretch 2.0 web interface starts loading and connues generang a
new appliance for the installed module.
Username: stretch
Password: The Stretch ID (see scker)
4. In case of energy producon (solar panel):
You will noce below the image of the Stealth in the green eld (and
the MAC adress) a negave sign (-) in front of the solar producon if
the installaon has been executed correctly (and if the solar panels
are producing energy). This may take some me. If the installaon is
connected incorrectly there will be no negave sign (-) in front of the
power output.
In case of energy consumpon (appliance):
If the installaon has been executed correctly there will be no negave
sign (-) in front of the power output.
