Bariatric Podiatry Chair

Model: 50CD

SERVICE MANUAL

Bariatric Podiatry Chair Service Manual

2 | P a g e

Contents

1. Introduction 3

General Warnings 3

2. Cleaning and Decontamination 4

3. Maintenance 5

General Maintenance 5

Service Checklist 6

4. Troubleshooting 7

5. Parts List and Diagrams 8

Exploded Diagram 9

Base Drawing 10

Middle Drawing 11

Top Drawing 12

Lift Lever Drawing 13

Link Lever Drawing 14

Back-Rest Drawing 15

Divided Leg-Rest Drawing 16

Leg Slider Drawing 17

6. Guarantee 18

7. Technical Specification 19

8. Revisions to Manual 20

Plinth 2000 Ltd is an ISO Audited company to ISO9001:2008

Our products are CE marked in conformity with the EC Directive MDD 93/42/EEC

Bariatric Podiatry Chair Service Manual

3 | P a g e

1. Introduction

Thank you for purchasing a product from Plinth 2000 Ltd. We use the highest quality

components and manufacturing techniques to ensure that our products are simple

to use and will last a long time. It is recommended that all users read and retain this

User Manual for reference.

Throughout this manual notice is made of a Warning and Caution system to highlight

to the user practices, procedures or conditions that should either not be allowed to

happen or happen with caution.

Warnings are in a box with bold type and identify potential hazards, procedures or

conditions which could result in death, injury or serious damage.

Cautions are in a box with plain type and identify conditions or procedures where if

caution is not taken it may result in damage or failure of equipment.

General Warnings

WARNING

Maximum Load (SWL) is 320kg distributed evenly.

Do not use flammable gasses in proximity to an electrically operated chair.

Do not concentrate weight on either side or either end of the chair.

Use only accessories approved for use with this chair.

Disconnect power supply before moving chair.

Children must be adequately supervised in the presence of the chair.

Do not allow children to play with the chair at any time.

Bariatric Podiatry Chair Service Manual

4 | P a g e

2. Cleaning and Decontamination

WARNING

If contamination is suspected then decontaminate the chair before use.

Torn or damaged upholstery should be replaced immediately.

CAUTION

Do not use Alkalis or other organic solvents for routine cleaning.

Always cover the vinyl with paper towelling or chair covers if it can come into

contact with bare skin.

Cleaning

Always wear suitable protective clothing before carrying out this procedure.

Disconnect the mains supply to the chair and move it to a suitable cleaning area and

lock the castors.

Step 1. Using warm water and soap on a damp cloth, carefully wipe the chair over

from top to bottom. Take great care around electrical components.

Step 2. Wipe the chair carefully from top to bottom using a clean damp cloth and

soap free water.

Step 3. Carefully dry the chair from top to bottom with clean lint free paper towels.

Decontamination

To decontaminate the chair repeat the above steps but using a dilute solution of

Hypochlorite and warm water (10,000ppm) instead of warm water and soap. At the

end of the procedure discard all cleaning materials in a safe manner and wash hands

thoroughly.

Bariatric Podiatry Chair Service Manual

5 | P a g e

3. Maintenance

Plinth 2000 Ltd products are designed to be maintenance free. However keeping

your Plinth products clean and regularly checked will assist in prolonging their

working life. The following is a guide of simple checks that the user can carry out on

a six monthly basis. We would also recommend an annual service visit by a Plinth

2000 trained engineer.

WARNING

Disconnect chair from electrical supply before commencing any of the following

checks.

Examine the chair for any signs of damage. Pay particular attention to all nuts, bolts

and fasteners to check they are present and tight but not over tight.

Upholstery bolts should all be checked (each section has between 2 and 6 No. M6

bolts), they should all be present and tight.

Check gas struts (if fitted) and ensure that they operate through the full range of

movement and lock fully.

Check hinge pins are lubricated and not rusty.

Check main chair nylon pivot bearings are lubricated sufficiently.

Examine mains and switch cables for any damage, cuts, kinks, abrasions etc. These

must be replaced if necessary.

Check mains lead, switch cables and slave motor leads are all correctly and securely

attached.

Check correct plug fuse is fitted (5A).

WARNING

Any electrical checks or work other than the visual inspection above must be

performed by a qualified electrician.

Do not connect BLUE or BROWN wires to the earth terminal of a plug.

Bariatric Podiatry Chair Service Manual

6 | P a g e

Bariatric Podiatry Chair Service Manual

7 | P a g e

4. Troubleshooting

In the unlikely event of the chair failing to operate and having carried out the normal

practical fault finding steps below then please contact our Customer Service Team

on +44 (0)1449 767887 or email [email protected]. Please have the

serial number to hand before making contact so we can help you more efficiently.

Fault

Possible Cause

Remedy

Chair is unstable

Uneven floor

Adjustable foot

Move chair to flat floor

Check presence, condition

and adjustment of foot

All motors will not work

Power disconnected

Fuse Blown

Hand/ Footswitch

disconnected

Connect power supply

Replace fuse in plug

Check the switch is fully

connected to the motor

One motor will not

work but others

working

Lead from height

motor/control box not

connected to slave motor

Fault with switch

Fault with control box

Fault with motor

Check and connect all leads

Replace switch

Replace control box

Replace motor

Motor sinks

Switch permanently

operated

Motor fault

Unplug and re-connect

switch

Replace motor

Leg rest will not work

(manual versions)

Gas spring incorrectly

adjusted (not being

triggered)

Gas spring faulty

Rotate gas spring until the

pin is just in contact with the

lever (2-3mm play required)

Replace gas spring

Leg rest sinks under

load (manual versions)

Gas spring incorrectly

adjusted (permanently

triggered)

Rotate gas spring until the

pin is just in contact with the

lever (2-3mm play required)

Armrests slip or are

loose

Locking thumbwheels not

correctly tightened

Thumbwheels damaged from

over tightening

Correctly tighten locking

thumbwheels

Replace thumbwheels

Bariatric Podiatry Chair Service Manual

8 | P a g e

5. Parts Lists and Diagrams

Bariatric Podiatry Chair Service Manual

9 | P a g e

Bariatric Podiatry Chair Service Manual

10 | P a g e
