Plantronics Tristar Manuel utilisateur

User's Guide

Guide d’Utilisation

Manual del Usuario

Manual do Usuário

user’s

TriStar®Headset

guide

With a TriStar®headset, you will experience a level of

comfort and on-the-job freedom that will make your job

easier than ever before. Worn on one ear, the TriStar fea-

tures a unique three-contact support system for a secure

fit no matter how much you move around. And it's light-

weight for maximum comfort throughout the day.

To help you make the most of the TriStar headset'

features, please read the important information contained

in this manual. It explains the components and functions of

both

the Voice Tube and Noise-Canceling models and ways

optimize their performance.

welcome

to hands-free

communications from

Plantronics

123 4 5 6

6Small and Large Belltip

Embout cloche petit avec

coussinet/Embout cloche

gros avec coussinet

Casquillo en campana

pequeño/Casquillo en

campana grande

Receptor Belltip Pequeno

com Espuma/Receptor

Belltip Grande com

Espuma

7Voice Tube

Tube Micro

Tubo Acústico

Tubo do Microfone

8Boom Grip

Manche de la Perche

Sujetador del Brazo

Ajuste da Extensão

9Noise Canceling

Microphone

Microphone antibruit

Micrófono reductor de

ruido

Microfone com

cancelamento de ruído

TriStar NC

TriStar®

before

BEFORE YOU

BEGIN

AVANT DE

COMMENCER

ANTES DE

COMENZAR

ANTES DE

COMENÇAR

you begin

english

Select one of the four earbuds and

insert it into the receiver, aligning the

pins with the notches. Rotate the

earbud clockwise,

⁄

turn, until it

clicks into place.

Try all four earbuds until you find

one that comfortably rests against,

but does not enter, your ear canal.

WARNING

For your safety and comfort, the

earpieces should not be inserted into the

ear canal.

Never remove the black retention ring

from the base of the earpiece or use an

earpiece without the retention ring in

place.

This headset is not intended for children

under the age of 14 and can be danger-

ous and harmful to younger children.

Some parts of this headset are small

enough to be swallowed or to become

lodged in a child’s windpipe, ears or

nose. In addition, this headset, as with

any product with long strings or cords,

may be dangerous for infants and young

children as the cords may become

wrapped around a child’s neck, causing

strangulation. To avoid danger of suffo-

cation, keep the plastic bags in which

this product is wrapped away from

babies and children. Do not use the bags

in cribs, beds, carriages or playpens. The

plastic bags could block the nose and

mouth and prevent breathing.

BEFORE YOU BEGIN

adjusting

the ear piece

ADJUSTING THE

EAR PIECE

RÉGLAGE DE

L’ÉCOUTEUR

AJUSTE DE LA

OREJERA

AJUSTE DA PEÇA

AURICULAR

english

Grasp the earloop and move the

receiver housing out as far as possible.

Place the earloop above and slightly

in front of your ear and rotate down

and back.

Adjust the receiver arm up and down

and side to side until the earbud

is comfortably positioned in your

outer ear.

ADJUSTING THE

EAR PIECE

adjusting

the mouth piece

ADJUSTING THE

MOUTH PIECE

RÉGLAGE DU

TUBE MICRO

AJUSTE DEL TUBO

ACÚSTICO

AJUSTE DO TUBO

DE VOZ

Noise-Canceling Models

Standard Models

english

Hold the receiver securely against

your ear with one hand.

With your other hand, adjust the

voice tube so that the tip sits two

finger-widths from the corner of

your mouth. To prevent breath noise,

avoid positioning the voice tube in

front of your mouth.

Carefully shape the boom with both

hands as shown. Do not bend or

twist the boom within

⁄

inch of the

microphone.

Position the boom so that the

micro-

phone sits two finger-widths from the

corner of your mouth.

Make sure the front of the micro-

phone

faces your mouth. If necessary,

carefully rotate the microphone into

the proper position. Avoid repeated

twisting of the boom.

To temporarily move the Noise-

Canceling microphone boom away

from your mouth, rotate the boom

grip. To return the boom to its origi-

nal position, reverse the rotation.

ADJUSTING THE

MOUTH PIECE

2"

50.8 mm

BackFront

Polaris™models

POLARIS™

MODELS

ADDITIONAL

FEATURES

CASQUES DE

MODÈLE POLARIS

FONCTIONS

ADDITIONNELLES

MODELOS DE

AUDÍFONOS

POLARIS

CARACTERÍSTICAS

ADICIONALES

MODELOS DE

FONES DE OUVIDO

POLARIS

RECURSOS

ADICIONAIS

and additional

features
