User Guide

NEED MORE HELP?

CALL US!

Instead of driving back to

the store, call us for help on

pairing, ﬁt or usage of your

new headset.

1-866-363-2583

Package Contents and Features

AC Charger 100 –240V

Refer to separate Safety Guide before using headset.

note Never charge the battery where the temperature may fall below

32°F (0°C) or rise above 104°F (40°C). Do not use your headset while it is

connected to the charger.

CHARGING TIME

2.5 hours ............... Full charge

Red status light glows while

charging. Do not use until

fully charged.

One-Touch Button:

Power On/Off

Call Answer/End

Pairing Mode

Voice Dialing

Optional Earloop

(ts either ear)

LED Status Light

Connector

for Rechargeable

Li-ion Battery

What Is Bluetooth?

Package Contents and Features

Optional Earloop

(ts either ear)

LED Status Light

Bluetooth wireless technology provides a way for devices, like headsets and

phones, to communicate with each other without wires. Pairing is the set-up

process of introducing your headset to your phone. Before using your headset

for the rst time, you must pair it with your Bluetooth-enabled phone.

Plantronics QuickPair™ Technology

To simplify the Bluetooth setup process, your new headset uses Plantronics

QuickPair technology. This process is shown on the next page.

• The rst time you turn your headset on, your headset

automatically enters pairing mode for 10 minutes.

•

Until you successfully pair your headset with a Bluetooth-enabled

phone, every time you turn it on it will enter pairing mode.

• To later pair to a new phone, with the headset off, press and

hold the One-Touch Button until the LED ashes red-blue, which

indicates pairing mode status .

Range (the distance between headset and phone)

• To maintain the connection, keep your headset within 33 feet of

your phone.

• For the least amount of interference place the headset and phone

on the same side of your body.

If you move too far from your phone and lose the Bluetooth connection:

•

the headset may reconnect automatically within 60 seconds when

you move closer to your phone (you will hear a low tone), OR

• you may have to tap the One-Touch Button to reconnect (you will

hear a low tone), OR

• if neither of the above options work, you may have to reconnect

to your headset using your phone’s Bluetooth menu.

What Is Bluetooth?

How to Pair Your Phone With Your Headset for the First Time

1 Turn on the Bluetooth feature on your phone.

For most phones, select Settings/Tools > Connections >

Bluetooth > On. See your phone’s user guide for more information.

2 Turn on the QuickPair feature of your headset.

Turn on your headset by pressing and holding the One-Touch Button

until the LED ashes blue, then alternately ashes red-blue.

If you don’t see these ashes, press and hold the One-Touch Button until

you see the red-blue ashes.

3 Set your Bluetooth phone to ‘discover’ to locate the headset.

This usually involves going to ‘setup,’ ‘connect,’ or ‘Bluetooth’ menu on

your phone and selecting the option to ‘discover’ or ‘add a device.’

4 Once available headsets are listed, select your headset

(FreeHand 1xx). If prompted for a passkey, enter 0000.

When pairing is successful, the status light on your headset glows blue.

Your phone will also conrm when pairing is complete.

Pairing Your Headset

SETTINGS

Ti me a nd D ate

Phone Settings

Bluetooth

Sound Settings

Network Ser vices

Security

Reset Settings

BLUETOOTH

Discover/

BLUETOOTH

FreeHand 1xx

PASSK EY

0000

Call Us with Questions 1-866-363-BLUE (2583)

Headset Controls and Indicators

Action Status Light Tone

Turn the headset

on or off

Press and hold the

One-Touch Button for

3 seconds.

On: Short blue ash

Off: Short red ash, then

turns off

On: Four rising tones then one

high tone

Off: High tone then four

descending tones

Answer/end

a call

Tap the One-Touch Button. None Brief tone at the beginning or

end of the call.

Make a call Enter the number on your

phone and press Send.

Blue ash every 2 seconds

until the call is ended.

No tone. Phone rings until

answered.

Battery level None Red ashing Five rapid high tones every 10

seconds when battery is critically

low. Charge immediately.

Adjust the volume Use your phone to adjust

or lower volume.

None None

Transfer a call from

headset to phone,

or from phone to

headset

While the call is in progress,

press and hold the One-

Touch Button until you hear

a tone.

None Single low tone

Dismiss missed

call indicator

Tap One-Touch Button Triple blue ash every 20

seconds until dismissed.

None

Out of range Press One-Touch Button

once to manually reconnect.

Headset will automatically

attempt to reconnect when

in range.

None 2 high tones when leaving

range. Single high tone when

back in range. Single low tone

when manually or automatically

reconnected.

Voice dial Press and hold One-Touch

Button until you hear a tone.

None Single low tone

Troubleshooting

My headset

does not work

with my phone.

Your headset may not have been in pairing mode when your phone

was searching for it. Repeat the pairing process on page 4.

You may have made incorrect menu selections on your phone while

pairing. Repeat the pairing process on page 4.

Callers cannot

hear me, or I

cannot hear

callers/dialing

tone.

Make sure the headset is turned on.

Your headset may be out of Bluetooth range or experiencing

interference. Move the headset closer to your phone, and make sure

your headset and phone are on the same side of your body.

Your headset battery is drained. Recharge the battery using the

supplied AC power adapter.

The listening volume is too low. Increase the volume on your phone.

My headset is

ﬂashing red

then blue

Your headset is in Pairing mode. If you are not trying to pair the

headset, reset it by simply turning headset off then on again.

Otherwise, see Pairing on page 4.

Product Speciﬁcations

Talk Time* Up to 6.5 hours

Standby Time* Up to 6 days

Charge Time 2.5 hours for full charge

Range Up to 33 feet (10 meters) away from phone

Power Requirements 5V DC – 180 mA

Battery Type Rechargeable lithium ion polymer

Storage/Usage

Temperature

32º F - 104º F (0º C - 40º C)

Version 2.0 + EDR (Enhanced Data Rate)

Supports your phone’s Bluetooth Hands-free (HFP) and

Headset (HSP) proles.

* Battery enabled. Performance may vary by device.

FFeeddeerraall CCoommmmuunniiccaattiioonnss CCoommmmiissssiioonn ((FFCCCC)) SSttaatteemmeenntt

1155..2211

You are cautioned that changes or modifications not expressly approved by the part

responsible for compliance could void the user’s authority to operate the equipment.

1155..110055((bb))

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

-Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules.Operation is subject to the following

two conditions:

1) this device may not cause harmful interference and

2) this device must accept any interference received, including interference that may cause

undesired operation of the device.

FFCCCC RRFF RRaaddiiaattiioonn EExxppoossuurree SSttaatteemmeenntt::

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. End users must follow the specific operating instructions for satisfying RF

exposure compliance. This transmitter must not be co-located or operating in conjunction

with any other antenna or transmitter.

Industry Canada (IC) Statement

15.21

You are cautioned that changes or modifications not expressly approved by the

part responsible for compliance could void the user’s authority to operate the

equipment.

15.105(b)

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the IC rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

* Reorient or relocate the receiving antenna.

* Increase the separation between the equipment and receiver.

*Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

* Consult the dealer or an experienced radio/TV technician for help.

Operation is subject to the following two conditions:

1) this device may not cause interference and

2) this device must accept any interference, including interference that may

cause undesired operation of the device.

IC RF Radiation Exposure Statement:

This equipment complies with IC radiation exposure limits set forth for an

uncontrolled environment. End users must follow the specific operating

instructions for satisfying RF exposure compliance. This transmitter must not be

co-located or operating in conjunction with any other antenna or transmitter.

Table des matières

Autres manuels Plantronics casque

Plantronics

Plantronics Discovery 645 Manuel utilisateur

Plantronics

Plantronics BLACKWIRE C610-620 MOC - QUICK START GUIDES Manuel utilisateur

Plantronics

Plantronics Savi Go WG100/B Guide de référence

Plantronics

Plantronics Calisto II Manuel utilisateur

Plantronics

Plantronics Discovery 650 Manuel utilisateur

Plantronics

Plantronics GameCom 307 Manuel utilisateur

Plantronics

Plantronics MX500-C Manuel utilisateur

Plantronics

Plantronics DISCOVERY 925 Manuel utilisateur

Plantronics

Plantronics DSP SERIES PERSONO SOFTWARE - QUICK START... Manuel utilisateur

Plantronics

Plantronics DISCOVERY 925 Manuel utilisateur

Plantronics

Plantronics Savi Office WO10 Manuel utilisateur

Plantronics

Plantronics Voyager Legend Manuel utilisateur

Plantronics

Plantronics CS50-USB Manuel utilisateur

Plantronics

Plantronics Blackwire C325-M Manuel utilisateur

Plantronics

Plantronics BackBeat 903 Manuel utilisateur

Plantronics

Plantronics M1500 Manuel utilisateur

Plantronics

Plantronics RIG 500 Series Manuel utilisateur

Plantronics

Plantronics GameCom X10 Manuel utilisateur

Plantronics

Plantronics Blackwire 7225 Manuel utilisateur

Plantronics

Plantronics Marque M155 Manuel utilisateur

Plantronics

Plantronics Plantronics Explorer 360 Manuel utilisateur

Plantronics

Plantronics Blackwire C320 Manuel utilisateur

Plantronics

Plantronics EncorePro 300 Series Manuel utilisateur

Plantronics

Plantronics BackBeat 903 Guide de référence

Manuels casque populaires d'autres marques

Sena

Sena SMH10 Manuel utilisateur

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuel utilisateur

Sennheiser

Sennheiser EPOS ADAPT 230 Manuel utilisateur

Doro

Doro Flexus HS2005 Manuel utilisateur

GE 98971 Manuel utilisateur

Hama

Hama 00184070 Manuel utilisateur

Blue Tiger

Blue Tiger Advantage PLUS Manuel utilisateur

Jawbone

Jawbone Icon Manuel utilisateur

Jabra

Jabra FR 20 Manuel utilisateur

Roxcore

Roxcore Flow A+ Manuel utilisateur

Turtle Beach

Turtle Beach XP 510 Manuel utilisateur

Philips

Philips SHB6101 Manuel utilisateur

Jabra

Jabra PRO 9460 Duo Manuel utilisateur

HyperX

HyperX HyperX Cloud Flight Manuel utilisateur

Bose

Bose MIE2 Mobile Manuel utilisateur

Jabra

Jabra Steel Manuel utilisateur

HyperX

HyperX cloud ii Manuel utilisateur

Southwing

Southwing SA505 Manuel utilisateur
