Pioneer DXT-736BT Manuel utilisateur

ORDER NO.

PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan

PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.

PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium

PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936

PIONEER CORPORATION 2011

CRT4771

COMPLETE CAR AUDIO PACKAGE CD RDS RECEIVER

DXT-736BT

/XSUS

This service manual should be used together with the following manual(s) listed below.

For the parts numbers, adjustments, etc. which are not shown in this manual,

refer to the following manual(s).

Model No. Order No. Mech. Module Remarks

DEH-7300BT/XSUC CRT4659

CX-3269 CRT4488 S11.1STD-DOUT CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly

K-ZZZ AUG. 2011 Printed in Japan

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.

and any use of such marks by Pioneer Corporation is under license.

Other trademarks and trade names are those of their respective owners.

DXT-736BT/XSUS

1234

SAFETY INFORMATION

WARNING

This product may contain a chemical known to the State of California to cause cancer, or birth defects or

other reproductive harm.

Health & Safety Code Section 25249.6 - Proposition 65

EXPLODED VIEWS AND PARTS LIST

PACKING(Page 40)

PACKING SECTION PARTS LIST * : Non spare part

Owner's Manual

EXTERIOR(Page 44)

EXTERIOR SECTION PARTS LIST

Mark No. Description DEH-7300BT/XSUC DXT-736BT/XSUS

5 Remote Control Unit CXE3669 Not used

18 Unit Box YHG5573 YHG5652

19 Contain Box YHL5573 YHL5652

22-1 Owner's Manual YRD5324 YRD5366

* 22-4 Warranty Card CRY1276 QRY3001

* Speaker Set Not used TS-165P/XIES

* Speaker Not used 16-1624CA/XI

Sub Unit Box Not used YHG5671

Part No. Language

YRD5366 English, Spanish(Espanol)

Mark No. Description DEH-7300BT/XSUC DXT-736BT/XSUS

7 Remote Control Unit CXE3669 Not used

8 Cover CNS7068 Not used

29 Detach Grille Assy YXA5728 YXA5861(Grille Assy)

40 Keyboard Assy YWM5492 *YWM5578(Keyboard Unit)

42 Holder QNC3027 QNC3018

46 Grille Unit YXA5732 YXA5860

ELECTRICAL PARTS LIST(Page 71)

KEYBOARD UNIT

The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.

Circuit Symbol and No. Part Name DEH-7300BT/XSUC DXT-736BT/XSUS

IC1802 Remote IC GP1UXC14RK Not used

R1801 Not used RS1/10SR473J

R1804 RS1/10SR101J Not used

C1801 CCG1192 Not used
