DVD MULTIMEDIA AV NAVIGATION SERVER

AVIC-N3

Quick Start Guide

This guide is intended to guide you though the basic

functions of this navigation system. For details, please

refer to the Operation Manual and Hardware Manual

provided with the product.

Hardware buttons

1Press or touch in the fol-

lowing order.

NAVI MENU button

➔Destination tab

➔Address Search

2Input the house number

and then touch “OK”.

3Input the street name.

4Select the street name

from list.

When route calculation is com-

plete, navigation guidance

begins.

5Begin driving in accor-

dance with navigation

guidance.

This navigation systems gives

you route guidance both visually

and by voice.

Search function overview

This navigation system has multiple methods for entering your des-

tination.

(1) Search by address

(2) Shortcut key for home address

(3) Shortcut key for favorite destination

(4) Search stores, restaurants, and other businesses in points of

interest database

(5) Search stores, restaurants, and other businesses in your

vicinity

Search result list for vicinity search

(6) Select a destination from your address book

(7) Select a previously routed destination

(8) Select a route to freeway entrance or exit

(9) Search destination by business telephone number

(1) NAVI/AV button

Switch between navigation map

displays and audio operation

displays.

(2) POS button

Display the navigation map.

(3) NAVI MENU button

Access the navigation menu.

(4) Joystick

Use for operation of audio and

video source.

(5) EJECT button

Press to eject a disc from the

navigation system.

(6) TRFC button *1

Preset button for XM Instant

Traffic & Weather audio service.

(7) MEMO button *1

Press and hold for MyMix func-

tionality.

(8) SRC (SOURCE) button

Press to toggle between audio

sources.

(9) VOLUME/ATT button

Rotate to increase or decrease

the volume.

(10) Disc loading slot

Insert a disc to play.

*1GEX-P10XMT XM Digital Satellite Data & Audio Receiver (sold

separately) is required, together with an active subscription.

Searching your destination by address

Published by Pioneer Corporation.

<KYGHX> <06A00001> Printed in China

Setting the voice guidance volume

Press or touch the following in

order.

NAVI MENU button ➔Settings tab

➔Volume

(1) (4) (5)

(6) (7) (8) (9)

(3)

(2)

(8) (7) (6)(5)

(4)

(10)

(3)

(2)

(1)

(9)

1Touch the screen to dis-

play the touch panel keys.

2To u c h “MENU” or “TOP

M.” to display the DVD

menu.

3Touch ➔to display .

4Touch to display the

touch panel keys to oper-

ate the DVD menu.

5Touch 5, ∞, 2or 3to

select the desired menu

item.

6To uch “ENTER” to start

playback.

(1) Traffic event

Stopped traffic

Stop and go traffic

Closed/blocked roads

Other event

(e.g., accident)

(2) Traffic flow

The following items represent

the traffic flow for the road.

5-15 mph

(8-24 km/h)

20-40 mph

(32-64 km/h)

45 mph or faster

(72 km/h or faster)

The icon indicates that the

average speed of the road is

over 45 mph (72 km/h).

Operation of XM Satellite Radio

You can use the navigation system to control a XM satellite digital

tuner.

Listening to your Apple iPod®

You can control your iPod with Dock connector via the touch screen

when it is connected to this navigation system via CD-IB100 iPod

adapter.

(1) Touch to display

the search categories.

CD-IB100 iPod adapter

(sold separately) is

required.

(1) Shows detailed informa-

tion of current song

(2) Use to enter the channel

number directly

(3) Use to toggle between

the following displays:

Detail information dis-

play – Ch Name List –

Song Title List

– Artist Name List

GEX-P10XMT XM Digital Satellite Data & Audio Receiver (sold

separately) is required, together with an active subscription.

Changing the source

1Touch the source icon and then select desired source.

Operation of the built-in DVD drive

1Insert a disc.

Touch “YES” to begin the disc

playback.

2Adjust the volume.

3Touch the screen to display

the touch panel keys for

additional control.

Operating the DVD menu

You can also press the SRC button

to switch sources.

Switching the view mode

Press (POS) button.

Scrolling the map

Touch where you would like to scroll to on the map screen.

Zoom in or zoom out

(1) Direct scale change

(2) Gradual scale change

Tapping it once will acti-

vate the shortcut keys.

Touching it a second

time will begin map

scroll. To scroll the map,

keep touching the map.

This navigation system

allows you to select dif-

ferent view modes

depending on your pref-

erence.

Traffic information on the map

Traffic conditions can be overlaid on the map when the optional

GEX-P10XMT is connected, together with an active XM subscription.

GEX-P10XMT XM Digital Satellite Data & Audio Receiver (sold

separately) is required, together with an active subscription.

Switching to the AV screen

1Press the NAVI/AV button to change the screen.

(1) (2)

(1)

(3)(2)(1)

(2)(1)

Source icon
