Pilz PSSu H IBSe Manuel utilisateur
Operating Manual — No. 21721-EN-02
Decentralised system PSSuniversal I/O
Operating Manual PSSu H IBSe
Operating Manual PSSu H IBSe
PSSu H IBSe
This document is a translation of the original document.
All rights to this documentation are reserved by Pilz GmbH & Co. KG. Co ies may be made
for internal ur oses.
Suggestions and comments for im roving this documentation will be gratefully received.
Pilz®, PIT®, PMI®, PNOZ®, Primo®, PSEN®, PSS®, PVIS®, SafetyBUS ®, SafetyEYE®,
SafetyNET ®, the s irit of safety® are registered and rotected trademarks of
Pilz GmbH & Co. KG in some countries.
SD means Secure Digital.
Preface
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Contents
Contents
Contents Page
Chapter 1 Introduction
1.1 Validity of documentation 1-1
1.1.1 Retaining the documentation 1-1
1.2 Overview of documentation 1-2
1.3 Definition of symbols 1-3
Chapter 2 Overview
2.1 Module features 2-1
2.2 Front view 2-2
Chapter 3 Safety
3.1 Intended use 3-1
3.2 Safety regulations 3-3
3.2.1 Use of qualified personnel 3-3
3.2.2 Warranty and liability 3-3
3.2.3 Disposal 3-3
Chapter 4 Function description
4.1 Module features 4-1
4.1.1 Integrated protection mechanisms 4-1
4.1.2 Supply voltage 4-1
4.2 INTERBUS 4-2
4.2.1 Connection to Interbus 4-2
4.2.2 Selector switch for setting the
transmission rate
4-2
4.2.3 Selector switch for setting the INTERBUS
parameters
4-3
4.3 USB port 4-4
Chapter 5 Installation
5.1 General installation guidelines 5-1
5.1.1 Dimensions 5-1
5.2 Installing the head module 5-2
Chapter 6 Interfaces
6.1 Interface assignment 6-1
6.1.1 Connection to INTERBUS 6-1
6.1.2 Connection via USB 6-2
Contents
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
2
Chapter 7 Operation
7.1 Messages 7-1
7.2 Display elements 7-2
7.2.1 Display elements for system diagnostics 7-2
7.2.2 Display elements for INTERBUS
diagnostics
7-3
7.3 Diagnostic bytes 7-5
7.3.1 Structure and contents of the status byte
(Byte 0)
7-5
7.3.2 Structure and contents of the slot byte
(Byte 1)
7-5
7.3.3 Structure and contents of the channel byte
(Byte 2)
7-5
7.3.4 Structure and contents of the module byte
(Byte 3)
7-6
Chapter 8 Technical details
8.1 Technical details 8-1
8.2 Order reference 8-3
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
1.1 Validity of documentation
1 Introduction
11000IntroductionIntroduction1-1.1Validity of documentation1100Validity of documentation1-][BA Einf Gültigkeit Kopfmodul ohne SB
This documentation is valid for the PSSu H IBSe module. It is valid until
new documentation is published.
Please also refer to the following documents:
PSSuniversal System Description
PSSuniversal Installation Manual
Einf Einleitung
This operating manual explains the function and operation, describes
the installation and provides guidelines on how to connect the product .
1.1.1 Retaining the documentation
Retaining the documentation1-Einf Aufbewahren
This documentation is intended for instruction and should be retained
for future reference.
1.2 Overview of documentation
1 Introduction
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
1-2
1.2Overview of documentation1200Overview of documentation1-][BA_Einführung Übersicht Kopfmodule
1 Introduction
The introduction is designed to familiarise you with the contents, struc-
ture and specific order of this manual.
2 Overview
This chapter provides information on the module's most important fea-
tures.
3 Safety
This chapter must be read as it contains important information on safety
and intended use.
4 Function Description
This chapter describes the module's individual components.
5 Installation
This chapter explains how to install the module.
6 Interfaces
This chapter describes the module's interfaces.
7 Operation
This chapter explains the display elements and advises on what to do if
a fault occurs.
8 Technical Details
This chapter contains the product's technical details and order refer-
ence.
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
1.3 Definition of symbols
1 Introduction
1.3Definition of symbols1300Definition of symbols1-Einfhrung Zeichen
Information that is particularly important is identified as follows:
DANGER!
This warning must be heeded! It warns of a hazardous situation
that poses an immediate threat of serious injury and death and
indicates preventive measures that can be taken.
WARNING!
This warning must be heeded! It warns of a hazardous situation
that could lead to serious injury and death and indicates preven-
tive measures that can be taken.
CAUTION!
This refers to a hazard that can lead to a less serious or minor
injury plus material damage, and also provides information on
preventive measures that can be taken.
NOTICE
This describes a situation in which the unit(s) could be damaged
and also provides information on preventive measures that can
be taken. It also highlights areas within the text that are of partic-
ular importance.
INFORMATION
This gives advice on applications and provides information on
special features.
1 Introduction
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
1-4
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
2.1 Module features
2 Overview
22000OverviewOverview2-2.1Module features2100Module features2-Geraetemerkmale_Zusatz BA Einleitung
The product has the following features:
][Merkmale_Schnittstelle ST-Bus INTERBUS-Interface for switching
– Standard inputs/outputs
USB port for connection to a PC for
– Commissioning
– Service
][Merkm ale_LED ST-Bus LEDs for:
– System status
–USBstatus
– Status of the INTERBUS interface
][Merkmale_E-Module ST-Bus Electronic modules that can be used for input/output:
– All standard modules
(PSSu E S...)
2.2 Front view
2 Overview
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
2-2
2.2Front view2200Front view2-BA_Frontansicht
Key:
1: Selector switch for setting the transmission rate and other Interbus
parameters
2: Interbus interface for remote bus OUT
3: Interbus interface for remote bus IN
4: LEDs for system diagnostics
5: Labelling strip with:
– Order number
– Serial number
– Hardware version number
– Firmware version number on delivery
6: Field for 2D code
7: Labelling strip with interface configuration of the USB port
8: LEDs for Interbus diagnostics
9: Description of head module
10: USB port (Mini-B)
PSSu H
IBSe
Usb Dev
USB
2
D -
3
D +
5
G N D
USB
312 048
0000000
HW 000
000
RC
RD
UL
BA
RE OTE OUTRE OTE IN
ON OFF
DIAG
500k 2
1
2
3
4
5
6
7
8
9
10
