INTERBUS

Designation:

Revision:

Order No.:

This guide is valid for:

Quick Start Guide

IBS S7 300 DSC QS UM E

B / C01

27 43 16 1

IBS S7 300 DSC-T, Revision 10/442

5756B

INTERBUS Process Data in the PLC

The I/O address area of the SIMATIC®S7-300 PLC depends

on the type of CPU. It is split into an input and an output

addressarea. Thesecontain the data of the boards operated

in the PLC.

Driver blocks allow the area of the INTERBUS process data

(input and output data of INTERBUS devices) to be

transferred into or out of the S7-300 PLCblock by block. The

driver blocks create a process image that reads the inputs

prior to the application program, andwrites the outputs to the

controller board or output devices after they have been

processed by the application program.

The driver can transfer the input/output data of the

INTERBUS system into the I/Q area of the PLC, bit memory

areas or data blocks, or out of these areas.

Addressable Areas of the SIMATIC®S7-300

5770B013

Data block

Bit memory area

I/Q area

INTERBUS

m ax. 512 output

bytes

IN T E R B U S

(proce im age)

area

input area

output area

(m ax. 512 input

bytes)

5756B

Application Areas / Technical Data

The controller board is compatible with the Siemens

SIMATIC®S7-300 PLC.

Mechanical Structure

Format (w x h x d) 80 mm x 125 mm x 110 mm

(3.150 in. x 4.921 in. x

4.330 in.)

Weight 500 g

PLC

Permissible CPU types CPU 313 through 316

Data interfaces

PLC SIMATIC®S7-300 I/O bus

INTERBUS Remote bus,

9-pos. D-SUB female

connector

Operation/diagnostics RS-232-C,

9-pos. D-SUB male connector

Connection method Via SIMATIC®S7-300 I/O bus

Supply

Voltage Through external power

supply

Current consumption Max. 300 mA at 24 V DC

Max. 10 mA from the S7-300

I/O bus

Addressable PLC areas

Input/output areas, bit memory areas and data blocks

Occupied analog address area

16 byte inputs and 16 byte outputs

INTERBUS data

Number of devices 512 (254 remote bus devices)

Amount of process data 256 words (4096 digital

inputs/outputs)

Number of devices with

parameter channel 62

Operating temperature 0°C to 60°C (horizontal

mounting), 0°C to 40°C

(vertical mounting)

Optical diagnostics

Operating status Through 4-line LCD

Error status Through 4-line LCD

I/O status Through 4-line LCD

5756B

The following overview lists the sections of this

Quick Start Guide, which informs you about how

to start up the controller board and the entire

INTERBUS system.

Page 17

Page 24

Page 42

Page 57

Preparations

–Unpacking the controller board

–Description of the connecting and operating

elements

Installing the Controller Board

–Controller board installation in the PLC

–Inserting the parameterization memory

–INTERBUS system connection

Startup for Testing the INTERBUS System

–Startup of the entire system during the

installation phase to test the connected

INTERBUS devices

Appendix

–Replacing the controller board

–Replacing the parameterization memory

–Upgrading the firmware

–Connecting cable

Example of an INTERBUS and PLC Configuration

Startup With IBS CMD SWT G4

Configuration Software

–Startup of the controller board and the

connected INTERBUS system with

IBS CMD SWT G4 software. During startup

with IBS CMD SWT G4, all system options

are available

INTERBUS System Operation From the PLC

–Description of the INTERBUS standard and

diagnostic registers and its position in the

PLC

Page 27

Page 18

Page 4

Page 10

Automatic Diagnostic Functions

–Description of the diagnostic driver block Page 52

INTERBUS Operating Modes

–Description of the timing interaction between the

INTERBUS and the PLC

Page 19Integration of the Controller Board in

STEP 7

–Integrating the controller board into the PLC

5756B 1

General Notes

Unless mentioned otherwise, all information in this guide

refers to the IBS S7 300 DSC-T controller board, Order No.

27 19 97 5.

When using this guide, please observe the following notes:

The attention symbol refers to an operating procedure

which,if not carefully followed, could result in damage

to equipment or personal injury. The symbol is always

located to the left of the tagged text.

The note symbol gives you tips and advice on

hardware and software optimization. In addition, text

marked in this way informs you of system-related

conditions that must strictly be observed to achieve

error-free operation. The symbol is also used to clarify

terms.

The text symbol refers you to detailed sources of

information (manuals, data sheets, literature, etc.) on

the subject matter, product, etc. This text also

provides helpful information for the orientation in the

manual.

Rightandsecureuseoftheproductrequirespropertransport,

storage, mounting and assembly, as well as, careful

operation and installation. The use of this product is only

allowed to qualified personnel authorized to start up, to

ground and to mark devices, systems and electric circuits

according to the standards of safety technology. Phoenix

Contact assumes no liability for damage or personal injury

resulting from disregard of notes and safety guidelines

contained in this manual.

Please note that software/hardware designations and brand

names of the companies mentioned are, as a rule, protected

by copyright, trademark or patent.

CurrentPhoenixContactproductinformationisalsoavailable

on the Internet at: www.phoenixcontact.com.

Table of Contents

i5756B

INTERBUS Process Data in the PLC

Addressable Areas of the SIMATIC®S7-300

Application Areas / Technical Data

General Notes........................................................... 1

Preface .................................................................................2

Preparations ............................................................. 4

ESD Regulations ..................................................................4

Unpacking the Controller Board............................................4

Structure of the Controller Board..........................................5

Installing the Controller Board.............................. 10

Controller Board Installation In the PLC .............................11

Connecting the External Supply Voltage............................12

Inserting the Parameterization Memory..............................13

Connecting the INTERBUS System...................... 14

Connecting the RS-232 Cable............................................15

Integrating INTERBUS Process Data Into

the PLC.................................................................... 16

INTERBUS Operating Modes................................. 17

Example of an INTERBUS and PLC

Configuration.......................................................... 18

Integration of the Controller Board in STEP 7®... 19

Startup for Testing the INTERBUS System.......... 24

Checking the Connected INTERBUS Configuration...........26

Startup With IBS CMD SWT G4

Configuration Software.......................................... 27

Creating a Configuration File..............................................27

Starting the Entire System..................................................32

Table of Contents

5756B ii

Function Blocks of the Controller Board............. 33

Installing Function Blocks...................................................33

Example for Asynchronous Data Transfer......................... 34

Integrating the Example Into Your PLC..............................35

Description of the Function Blocks in the Example............ 37

INTERBUS System Operation From the PLC....... 42

Position of the INTERBUS Standard Registers .................43

Description of the Diagnostic Registers............................. 44

Description of Standard Functions..................................... 48

Automatic Diagnostic Functions.......................... 52

Diagnostic Data Evaluation................................................ 52

Appendix................................................................. 57

Replacing the Controller Board.......................................... 57

Replacing the Parameterization Memory...........................60

Upgrading the Controller Board Firmware .........................62

Connecting Cable............................................................... 62

Controller Board Messages (examples)............................. 68

25756B

Preface

Application

This Quick Start Guide helps you to start up and operate an

INTERBUS system connected to an IBS S7 300 DSC-T

controller board for Siemens SIMATIC®S7-300 PLC.

Purpose

This guide should make it possible to start up the INTERBUS

systemquickly andeasily. In the user manualofthe controller

board (IBS S7 300 DSC UM E) you will find a complete

description of all the features e.g., a detailed description ofall

possible services and error messages.

Content

This guide describes the easy startup of the INTERBUS

system as follows:

1. Setting and installing the hardware

2. Testing the entire system

3. Configuring and loading system data to the

parameterization memory

4. Controller board startup

5. Operating the INTERBUS system

Diagnostic and operating functions are described in

addition to startup.

Hardware and Software Requirements

–Controller board

IBS S7 300 DSC-T Order No. 27 19 97 5

–Parameterization memory

IBS MC FLASH Order No. 27 51 77 1

–Connecting cable

IBS PRG CAB Order No. 28 06 86 2

–Driver software

(on the disk provided with the IBS S7 300 DSC UM E

User Manual)

–Configuration software (demo version)

IBS CMD SWT G4 DEMO E Order No. 27 22 22 1

or CMD software (full version)

IBS CMD SWT G4 E Order No. 27 21 44 2

5756B 3

Further Documentation

User manual for the controller board

IBS S7 300 DSC UM E Order No. 27 21 33 2

Installation and I/O Systems Manual

IBS SYS PRO INST UM E Order No. 27 43 80 2

Diagnostics Guide

IBS SYS DIAG DSC UM E Order No. 27 47 29 3

Trademarks

SIMATIC®,

STEP 7®Registered trademarks of Siemens AG

WINDOWS®Registered trademark of Microsoft Corp.

45756B

Preparations

This section contains the basic settings which are necessary

before installing the controller board in the PLC and which

determine the operating behavior.

ESD Regulations

Persons who handle the controller board mustprotect

it by observing the ESD instructions before packing or

unpacking the board, opening control boxes or control

cabinets and before touching the board.

Unpacking the Controller Board

The controller board is supplied together with a package slip

with installation instructions. Please read the complete

installation instructions before unpacking the controller board.

Only qualified persons should pack, unpack and

handle the controller board while observing the ESD

instructions.

Table des matières

Autres manuels Phoenix Contact Contrôleurs

Phoenix Contact

Phoenix Contact AXC F 1050 Manuel utilisateur

Phoenix Contact

Phoenix Contact MCR-FL-D-T-2SP-24 Manuel utilisateur

Phoenix Contact

Phoenix Contact ELR W3 500AC I Series Manuel utilisateur

Phoenix Contact

Phoenix Contact PLCnext AXC F 2152 Manuel utilisateur

Phoenix Contact

Phoenix Contact RFC 4072S Manuel utilisateur

Phoenix Contact

Phoenix Contact AXC 1050 Manuel utilisateur

Phoenix Contact

Phoenix Contact IBS ABB DSC-T Guide de configuration

Phoenix Contact

Phoenix Contact ELR H5-IES-SC-24DC/500AC-0,6 Manuel utilisateur

Phoenix Contact

Phoenix Contact ILC 191 ME/AN Schéma de câblage

Phoenix Contact

Phoenix Contact AXC 3050 Manuel utilisateur

Phoenix Contact

Phoenix Contact CONTACTRON CSS 0.25-1/3 Manuel utilisateur

Phoenix Contact

Phoenix Contact AXC 1050 Manuel utilisateur

Phoenix Contact

Phoenix Contact ILC 131 STARTER KIT Manuel utilisateur

Phoenix Contact

Phoenix Contact AXC F 1152 Manuel utilisateur

Phoenix Contact

Phoenix Contact EV-PLCC-AC1-DC1 Manuel utilisateur

Phoenix Contact

Phoenix Contact ILC 330 Manuel utilisateur

Phoenix Contact

Phoenix Contact ILC 130 ETH Manuel utilisateur

Phoenix Contact

Phoenix Contact MCR-FL-D-U-I-2SP-24 Manuel utilisateur

Phoenix Contact

Phoenix Contact Nanoline Series Manuel utilisateur

Phoenix Contact

Phoenix Contact ILC 2050 BI Mode d’emploi

Phoenix Contact

Phoenix Contact ILC 330 Series Manuel utilisateur

Phoenix Contact

Phoenix Contact ELR H51-IESSC-24DC500AC-06 Manuel utilisateur

Phoenix Contact

Phoenix Contact RFC 4072R Manuel utilisateur

Phoenix Contact

Phoenix Contact AUTOMATIONWORX IBS PCI SC/I-T Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
