Phoenix Contact IBS ABB DSC-T Guide de configuration

Type:

Revision:

Order No.:

This guide is valid for :

INTERBUS

G4 Diagnostics Guide

IBS SYS DIAG DSC UM E

A / C01

27 47 29 3

IBS ABB DSC/SL/I-T Firmware ≥4.0

IBS PLC5 DSC/I-T Firmware ≥4.0

IBS S5 DSC/I-T Firmware ≥4.0

IBS BA DSC/I-T Firmware ≥4.0

5277A

Figure 1: Menu (Mode)

(Mode

)

5241A000

LEVL

LEN

MODE

CFG DIAG STAT OPT

MPM DEBG QFLG WFLG

ERRHIST

SCANTIME FW-V

NORM MONI

SNGL

ACTV CFGBRDG

SWTC

OPTITIME HW-V RSET LCD TEST

REC PF CRC PF TEN CRC TEN

ADBG

SAVE CFG

SER-No.

5277A

Possible indications in Line 1:

BOOT, RDY, ACTV,

RUN Page 8

CTRL Page 44

LOOK FOR FAIL Page 9

RBUS Page 46

LBUS Page 48

OUT1 Page 52

OUT2 Page 60

BUS Page 52

DEV Page 64

PF Page 68

USER Page 72

EVNT Page 70

E1 - E9 Page 15

Figure 2: Possible indications on the LCD

NTER

5241A030

5277A

Bus Structure and Device Counting Method

Figure 3: Example of a bus configuration

5241A031

1.0 2.0

3.0

4.0 4.1 4.2

5.0

6.0

7.0

8.0

9.0

10.0

7.1 7.2 7.3 6.1 6.2 6.3

Level 3Level 2

Level 1

Level 0

5277A

General Information

Depending on their design, controller boards of Generation 4

have a keypad with 6 keys and an LCD for status and diag-

nostics displays. The display is carried out via LEDs or sys-

tem messages (by means of driver blocks).

This guide describes the operation of the diagnostic display,

the signal representation of LEDs, and system messages in-

dicated via driver blocks.

Thedescriptionsrefertothefirmwareversion4.x.Information

on the firmware version is indicated in the text by the short-

form "FW4.0".

When using this guide, please observe the following notes:

The front cover page shows an overview of the menu

structure of the controller board.

The

attention

symbol refers to erroneous handling,

which could lead to damage to the hardware or soft-

ware or to personal injury. This symbol is always loca-

ted to the left of the tagged text.

The

hand

symbol gives you tips and advice on the ef-

ficient use of hardware and on software optimization.

In addition, text marked in this way informs you of sy-

stem-related conditions that must absolutely be ob-

served to achieve error-free operation. The hand is

also found in front of clarifications of terms.

The

text

symbol refers to detailed sources on informa-

tion (manuals, data sheets, literature, etc.) on the sub-

ject matter, product, etc. This text also provides helpful

information for the orientation, reading order etc. in the

manual.

5277A

Table of Contents

General Information 1

Keypad 2

Diagnostics Display 3

Structure of the Display 4

System Startup 8

BOOT 8

READY 8

ACTIVE 8

RUN 8

Error Messages 9

Controller Error 9

Error Localization 9

Remote Bus Error 10

Local Bus Error 11

OUT1 12

OUT2 13

General Bus Error 14

Bus Errors E1 - E9 15

Device Error 16

Peripheral Fault 17

User Error 18

EVENT Message 19

Extended Diagnostics 20

Selecting a Menu Item 20

Menu Structure 20

CFG Menu Item 21

ID - Identification Code of the Selected Device 21

LEN - Process Data Length of the Device 21

LEVL - Bus Level of the Selected Device 21

SWTC - List of Switched Off Devices 21

BRDG - List of Bridged Devices 21

ACTV CFG - Active Configuration 22

SAVE CFG - Saving the Configuration 22

DIAG Menu Item 23

MPM 23

5277A

DEBG - Debug 23

ADBG - Auto Debug 24

QFLG - Quality Flag 24

WFLG - Warning Flag 24

SNGL - Single (Single Error) 24

MPM Menu Item 24

Submenus of MPM Diagnostics 26

User Error 26

Peripheral Fault 26

Bus Error 26

Controller Error 27

DEBG Menu Item (Debug) 27

ADBG Menu Item (Auto Debug) 29

Help for Startup 29

QFLG Menu Item (Quality Flag) 30

WFLG Menu Item (Warning Flag) 31

SNGL Menu Item (Single Error) 31

STAT Menu 31

REC Menu Item 33

PF Menu Item (Peripheral Fault) 33

CRC Menu Item 33

PF TEN Menu Item 33

CRC TEN Menu Item 34

ERRHIST Menu Item 35

OPT Menu 36

SCAN TIME Menu Item 37

OPTI TIME Menu Item 37

FW-V Menu Item 37

HW-V Menu Item 37

SER-No. Menu Item 38

RSET Menu Item (RESET) 38

LCD TEST Menu Item 38

MONI Menu (Monitor) 38

Siemens S5 39

Flowchart for Error Recovery 43

Controller Error (CTRL) 44

iii

5277A

Remote Bus Error (RB) 46

Local Bus Error (LB) 48

Bus Error (BUS) 52

OUT1 56

OUT2 60

Device Error (DEV) 64

Peripheral Fault (PF) 68

EVENT 70

User Error (USER) 72

Fuse Types for INTERBUS Devices 90

Replacing INTERBUS Components 93

Repairing Defective INTERBUS Components 98

Technical Support 98

We Are Interested in Your Opinion! 99

Service Sheet for the Repair of Defective

INTERBUS Components 100

5277A

25277A

Keypad

Figure 4: Keypad

The keypad allows menu-driven operation of the LCD via the

arrow keys.

5241A003

INTERBUS

Diagnostics display

Keypad

Up Arrow

Down Arrow

Right Arrow, selection from

menu items or addresses

Left Arrow, selection from

menu items or addresses

ENTER, confirm selection

ESCAPE, leave menu item, change to

the next higher level
