Important

◗Only use Philips Oslo+ double-layer paper dustbags (type

HR6938).

◗Never use the appliance without the Motor Protection Filter.This

could damage the motor and shorten the life of the appliance.

◗Check if the dustbag has been placed correctly.

◗The infrared remote control on the handgrip contains electronic

components.To avoid defects:

Do not clean this part with water.

◗Never use the vacuum cleaner to suck up water or any other

liquid.Never suck up ashes until they are cold.

◗When the vacuum cleaner is used to suck up fine dust,the pores

of the dustbag may become clogged,causing the passage of air

through the dustbag to become obstructed.As a result,the

dustbag-full indicator will indicate that the dustbag needs to be

replaced,even though the dustbag is not full at all.

Connecting accessories

C1To connect the hose,push it firmly into the appliance (you will

hear a click).

C2To disconnect the hose,push the buttons and pull the hose out

of the appliance.

Conical coupling (specific types only)

C1To connect the tubes to the handgrip,insert the narrow

section into the wider section while turning it clockwise.The

tube with the clip is the lower tube.

Use the same method to connect the accessories to the tube.

2To disconnect,turn the tube or the accessories anticlockwise

and pull.

ENGLISH4

Active coupling (specific types only)

C1Connect the tube to the handgrip ("click").

Use the same method to connect the accessories to the tube.

C2To disconnect the tube from the handgrip,push the lock button

and pull the tube out of the handgrip.The accessories are

disconnected in the same way.

Telescopic tube (specific types only)

1Connect the tube to the handgrip ("click").

C2Adjust the tube to the length you find most comfortable during

vacuum cleaning.

Convertible nozzle

The convertible nozzle can be used on either carpets or hard floors.

1Connect the convertible nozzle to the telescopic tube ("click").

C2Push the rocker switch on top of the convertible nozzle with

your foot to make the brush strip for cleaning hard floors

come out of the nozzle housing.

C3Push the rocker switch again to make the brush strip disappear

into the convertible nozzle housing again.

ENGLISH 5

Accessories

C◗Open the cover

C◗You will find the accessories in the special storage compartment

in the body of the appliance.

Vacuum cleaning

C1Pull the cord out of the appliance and put the mains plug in the

wall socket.

C2Switch the appliance on by pushing the on/off switch on top of

the appliance with your foot.

Adjusting suction power

You can adjust the suction power while vacuum cleaning.

C◗Use the slide control on top of the appliance.

3Set to MAX for maximum suction power.

Use maximum suction power for vacuum cleaning very dirty carpets

and hard floors.

ENGLISH6

MIN

MAX

4Set to MIN for minimum suction power.

Use minimum suction power for vacuum cleaning curtains,table

carpets,etc.

C◗Some types are equipped with infrared remote control.

With the infrared remote control you can set the suction power to

one of 5 different suction power settings.When you switch the

appliance on,it will always start running at the highest suction power

setting.

C◗By pushing the - button,you will reduce the suction power by one

setting.

C◗By pushing the + button,you will increase the suction power by

one setting.

C◗Push the standby button to temporarily switch the vacuum

cleaner off,for instance when you have to move some furniture.

◗To continue vacuum cleaning,simply press the - button or the +

button.The appliance will start operating at the previously selected

suction power setting again.

Parking the tube

C◗Place the tube clip in the parking slot.You can slide the clip along

the tube to adjust the parking height of the tube.

ENGLISH 7

Storage

1Switch the appliance off.

2Remove the mains plug from the wall socket.

C3Rewind the mains cord by pressing the cord rewind button.

C4Put the appliance in upright position and insert the tube clip on

the lower tube into the storage slot.

Replacing the dustbag

C◗Replace the dustbag as soon as the dustbag-full indicator burns

red continously (i.e.even when the nozzle is not placed on a

surface).

1Switch the appliance off.

C2Open the cover.

C3Lift the dustbag holder out of the appliance.

ENGLISH8

C4Remove the full dustbag from the holder by pulling the

cardboard tag.

C5Slide the cardboard front of the new dustbag into the two

grooves of the dustbag holder.

C6Slide the dustbag into the dustbag holder as far as possible.Re-

insert the dustbag holder into the vacuum cleaner.

You cannot close the cover if no dustbag has been inserted.

Replacing filters

C1Every time you empty or replace the dustbag,take the

Permanent Motor Protection Filter out of the appliance and

clean it by shaking it over a dustbin.

C2Press the Permanent Motor Protection Filter firmly back into

its holder in its original position.

ENGLISH 9

C3Press the filter holder with the clean filter into place in such a

way that it fits properly at the bottom.

◗Instead of with the improved Permanent Motor Protection Filter,

this appliance can also be equipped with anActivated Carbon

Filter.This filter absorbs 80% of all unpleasant smells.The two

electrostatically charged filter layers guarantee that the exhaust air

is perfectly clean.

◗TheAFS Micro Filter at the back of this appliance will filter a large

part of the smallest particles from the exhaust air by means of its

electrostatically charged fibres.

4Replace theAFS Micro Filter when you insert the first of a new

set of dustbags.

C5Place the sides and the bottom edge of the new filter properly

behind the ridges of the holder.

C6Make sure that the filter has been properly inserted into the

holder before you close the filter holder.

◗Instead of with theAFS Micro Filter,some appliances are equipped

with the revolutionary S-Class Filter.The S-Class Filter is able to

remove at least 99.97% of all particles down to 0.0003 mm in size

from the outlet air.This not only includes normal house dust,but

also harmful microscopic vermin such as house dust mites and

their excrements,which are well-known causes of respiratory

allergies.

Environment

To make recycling possible, the plastics used for this appliance have

been coded.

The cardboard packaging has been made of recycled material and is

fully recyclable.

Ordering dustbags and filters

Philips Oslo+ double-layer paper dustbags are available under type

number HR6938.

S-Class replacement packages are available under type number

HR6993.

New Activated Carbon Filters packages are available under type

number HR6968.

If you have any difficulties obtaining dustbags,filters or other accessories

for this appliance,please contact the Philips Helpdesk.

ENGLISH10
