Philips FC8473 Manuel utilisateur

Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification

ServiceManual

Philips Consumer Lifestyle

Vacuum cleaner

FC8473/01

FC8473/61

14/04 Version 1.4

PRODUCT INFORMATION

Safety

• This product meets the requirements regarding

interference suppression on radio and TV.

• After the product has been repaired, it should function

properly and has to meet the safety requirements as

officially laid down at this moment.

TECHNICAL INFORMATION

• Colour : Deep Black

• Power consumption : 1800 W

• Action radius : 9 m

• Cord length : 6 m

• Filtration : Washable double foam filter

HEPA 10

• Coupling : Conical

• Wheels : Plastic

• Dimensions appliance : 240 x 410 x 240 mm

• Weight : 4.5 kg

ACCESSORIES

• Nozzle : Multi nozzle

• Special nozzle : Parquet nozzle

• Tubes : Metal 2-piece Telescopic Tube

• Accessories : Crevice nozzle and Small nozzle

REPAIR INSTRUCTION

• No specific issues

OPTIONAL (accessories)

• No specific issues

FC8473/01 / FC8473/61

2-10

• To open the appliance, first remove the bucket by

pushing the Unlock button and lifting the bucket straight

upwards.

• To disassemble the Upperhousing:

Remove the CW Button and On/off button by using a

screwdriver to push the buttons upwards, in this way the

clicknocks can be loosened. (see picture)

• Remove the 6 screws (B), two are positioned under the

buttons. (see picture)

B B

• Remove the Exhaust grille and filter and “unclick the two

snap locks” on the backside with a screwdriver. (see

picture)

• The Upperhousing can now be separated, some force

may be needed.

• The Motor housing is secured with 5 screws, to reach all

screws the Cordwinder must be removed first.

• First detach the PCB assy from the Motor housing by

removing screw (C). (see picture)

• To be able to pull the Cordwinder out you must create

more space at the side of the wheel, do so by pulling the

Lower housing a little bit outwards. (see picture)

• Remove the 5 screws (D) and take the Motor housing

out of the Lower housing. (see exploded view at

page7-9)

DISASSEMBLY- AND RE-ASSEMBLY ADVISE

FC8473/01 / FC8473/61

3-10

D4 D1

220 - 240V

50Hz

0.47µF

275V

0.22µF

400V

Motor

TMP

TR1

2k-¼W

18k-¼W

DB3

1N4007

180k

MCR100-6

27k

¼W

3.9k

¼W

300k

¼W

47k

¼W

220µF

16V

220µF

16V

DW1

10V

½W

CIRCUIT DIAGRAM

DISASSEMBLY- AND RE-ASSEMBLY ADVISE

• The Motor housing is fixed around the motor with two

screws (E) and clicknocks all around and, these can easily

be detached and clicked in again while assembling.

• Working procedure for re-assembling the Upper housing:

First click the snap locks on the backside of the Upper

housing then assemble the frontside and tighten the 6

screws (B).

FC8473/01 / FC8473/61

4-10

PARTS LIST

Pos Service code Description Remark

9965 100 60936

9965 100 60947

4322 004 93801

4322 004 93821

9965 100 60938

Lid for Bucket

Bucket incl. Cone

HEPA lter

Micro lter

Exhaust grille

Buffalo - Mistral

Mistral

9965 100 60946

9965 100 61666

9965 100 60937

9965 100 60952

9965 100 60944

Unlock button for Bucket

Upper housing

CW Button

On/Off button

Spring for Button

Deep Black 80231

4322 006 24881

9965 100 60949

4322 005 34091

4322 005 34151

9965 100 60939

PCBA

Switch

Cordwinder 6 m / 4.8 plug

Cordwinder 6 m / UK/HK plug

Lower housing

Buffalo

Deep Black

9965 100 60941

9965 100 60945

9965 100 60948

9965 100 60942

4322 009 00721

Casterdish assy

Safety valve

Wheel assy

Motor Front

Service assy Motor (1800 W) Kingclean

9965 100 60951

4322 004 25021

4322 004 25041

4322 004 25061

4322 004 25121

Motorhousing

Hose

Handgrip conical 35 mm

Metal Telescopic Tube conical 35 mm

Smal nozzle conical 35 mm

Buffalo - Mistral

Deep Black 80231

4322 004 25111

4322 004 25081

4322 004 25141

4322 004 93911

Crevice nozzle conical 35 mm

All oor nozzle # 92 conical 35 mm

Parquet nozzle conical 35 mm

Exhaust Filter Sponge

Deep Black 80231

Buffallo

FC8473/01 / FC8473/61

5-10

EXPLODED VIEW

FC8473/01 / FC8473/61

6-10

EXPLODED VIEW

FC8473/01 / FC8473/61

7-10

EXPLODED VIEW

FC8473/01 / FC8473/61

8-10

EXPLODED VIEW

FC8473/01 / FC8473/61

9-10

EXPLODED VIEW

FC8473/01 / FC8473/61

10-10

Version history

Version 1.1 : FC8473/01 / FC8473/61 initial release.

Version 1.2 : Update picture removing exhaust grille in Disassembly- and Re-assembly advise.

Version 1.3 : In Parts List and Exploded view: Added Pos. 28, 4322 004 93901 Exhaust Filter Sponge Buffallo.

Version 1.4 : In Parts List: Changed Pos. 28, 4322 004 93901 Exhaust Filter Sponge Buffallo into 4322 004 93911.
