Philips FC6054/01 Manuel utilisateur

FC6053, FC6051, FC6050

4222.003.3316.2.indd 1 21-04-2006 16:00:09

4222.003.3316.2.indd 2 21-04-2006 16:00:10

4222.003.3316.2.indd 3 21-04-2006 16:00:10

4222.003.3316.2.indd 4 21-04-2006 16:00:11

FC6053, FC6051, FC6050

ENGLISH 6

 11

 17

 22

 27

 32

 37

 43

 48

 53

 59

 65

 71

 77

 82

 87

4222.003.3316.2.indd 5 21-04-2006 16:00:11

General description (Fig. 1)

ACrevice tool

BBrush tool

CBendable crevice tool (FC6053 only)

D Outerlter

E Innerlter

FCharging unit

GAdapter

HDust compartment

IDust compartment release button

JExhaust air openings

KCharging light (LED)

LOn/off slide

MContact strips

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

Check if the voltage indicated on the adapter corresponds to the

local mains voltage before you connect the appliance.

Do not use the appliance if it is damaged in any way.Take it to an

authorised Philips service centre for repair.

The adapter and the charging unit of this appliance cannot be

replaced. If the adapter or charging unit is damaged, the appliance

must be discarded.

Never suck up water or any other liquid. Never suck up ammable

substances and do not suck up ashes until they are cold.

Never immerse the vacuum cleaner or the charging unit in water.

Remove the adapter from the wall socket before cleaning the

charging unit.

Only charge the vacuum cleaner with the adapter and charging unit

supplied. During charging, the adapter will feel warm to the touch.

This is normal.

Always switch the vacuum cleaner off after use.

Keep the appliance out of the reach of children.

ENGLISH

4222.003.3316.2.indd 6 21-04-2006 16:00:11

The voltage on the contact strips in the charging unit is low (max.

12 volts) and therefore not dangerous.

Never block the exhaust air openings during vacuuming.

Switch the appliance off when recharging it.

Always use the vacuum cleaner with lter unit.

Noise level FC6053: Lc = 82 dB [A]

Noise level FC6051: Lc = 80 dB [A]

Noise level FC6050: Lc = 77 dB [A]

Preparing for use

Installing the charging unit

1 Attach the charging unit to the wall as indicated in the gure.

(Fig. 2)

If you attach the charging unit to the wall, the space between the screw

holes should be 70 mm.

2 You can also place the charging unit on a horizontal surface

(e.g. a table or desk). (Fig. 3)

3 Excess mains cord can be wound round the charging unit. (Fig. 4)

Charging the appliance

Chargetheapplianceforatleast16hoursbeforeyouuseitfortherst

time.

1 Insert the adapter into the wall socket.

2 Place the vacuum cleaner on the charging unit. (Fig. 5)

The charging light will go on to indicate that the appliance is

charging. (Fig. 6)

Note:The charging light will stay on as long as the appliance is connected to

the charging unit and the adapter is in the wall socket.

Note:The charging light does not give any information about the charge level

of the built-in batteries.

ENGLISH 7

4222.003.3316.2.indd 7 21-04-2006 16:00:11

Note:To optimise the lifetime of the rechargeable batteries, periodically

discharge them completely by letting the appliance run until it stops and then

recharge them fully again.



1 Push the on/off slide forwards to switch the appliance on. (Fig. 7)

2 Push the on/off slide backwards to switch the appliance off. (Fig. 8)



The appliance comes with the following accessories:

1 a brush tool to clean delicate surfaces;

2 a crevice tool to clean corners or narrow gaps;

3 a bendable crevice tool, contractible and extendable to clean hard-to-

reach places (FC6053 only).

1 Take the accessory you want to use.

2 Attach the accessory to the nozzle of the appliance. (Fig. 9)

Cleaning

Always remove the adapter from the wall socket before cleaning the

charging unit.

1 Clean the appliance with a damp cloth.

Emptying the dust compartment

Makesureyouemptythedustcompartmentandcleanthelters

regularly.

1 Hold the appliance over a dustbin and press the dust compartment

release button. (Fig. 10)

2 Remove the lter unit from the dust compartment. (Fig. 11)

3 Empty the dust compartment with your free hand.

4 Clean the outer lter and the inner lter.

ENGLISH8

4222.003.3316.2.indd 8 21-04-2006 16:00:11

Note:To clean the inner lter, you can remove the outer lter from the lter

holder by turning it anticlockwise.

Note:You can clean the outer lter and the inner lter with a brush or with a

normal vacuum cleaner if they are very dirty.

Note:If necessary, you can clean the outer lter and the inner lter in cold or

lukewarm water.

5 Place the outer lter back onto the lter holder and put the lter

holder back into the dust compartment. Make sure you insert the

lter holder in the correct way. (Fig. 12)

Never use the vacuum cleaner if the lter unit is still wet.

Storage

1 You can store the brush tool and the crevice tool by placing them

on the charging unit. (Fig. 13)

Replacement

Replace the inner lter if it can no longer be cleaned properly

(usually after having been cleaned about 50 times).

1 Remove the lter unit from the dust compartment. (Fig. 11)

2 Remove the outer lter from the holder by turning it anticlockwise.

(Fig. 14)

3 Remove the inner lter from the holder by gently turning it

anticlockwise. (Fig. 15)

4 Attach a new inner lter to the holder. (Fig. 16)

5 Push the tip of the inner lter inwards. (Fig. 17)

6 Reattach the outer lter to the holder. (Fig. 18)

ENGLISH 9

4222.003.3316.2.indd 9 21-04-2006 16:00:12



Newinnerltersareavailableundertypeno.FC8035.Contactyour

Philips dealer.

Environment

Do not throw the appliance away with the normal household waste

at the end of its life, but hand it in at an ofcial collection point for

recycling. By doing this you will help to preserve the environment.

(Fig. 19)

Saving energy

If you are not going to use the appliance for a longer period of time, we

advise you to remove the adapter from the wall socket to save energy.

Disposal of batteries

NiCd/NiMH batteries can be harmful to the environment and may

explodeifexposedtohightemperaturesorre.

Batteries contain substances that may pollute the environment.Always

remove the batteries before discarding the appliance or handing it in at

anofcialcollectionpoint.Disposeofthebatteriesatanofcialcollection

point for batteries.

Only remove the batteries if they are completely empty.

Remove the batteries in the following way.

1 Let the appliance run until it stops, undo the screws and open the

vacuum cleaner. (Fig. 20)

2 Cut the connecting wires one by one and remove the batteries.

(Fig. 21)

Guarantee & service

If you need information or if you have a problem, please visit the Philips

website at www.philips.com or contact the Philips Customer Care

Centreinyourcountry(youwillnditsphonenumberintheworldwide

guaranteeleaet).IfthereisnoCustomerCareCentreinyourcountry,

ENGLISH10

4222.003.3316.2.indd 10 21-04-2006 16:00:12
