User Manual

32PHD4503

Contents

1 Get Support 3

1.1 Identify and Register your TV 3

1.2 TV Help and User Manual 3

1.3 On-line Help and User Manual 3

1.4 Consumer Care / Repair 3

2 Software 4

2.1 Update Software 4

2.2 Software Version 4

3 Quick Guide 5

3.1 Remote Control 5

3.2 IR sensor 6

3.3 Joysticker - Local Control 6

4 Setting Up 7

4.1 Read Safety 7

4.2 TV Placement 7

4.3 Turn on TV 8

5 Connections 9

5.1 Connectivity guide 9

5.2 Antenna 9

5.3 Video Device 9

5.4 Audio Device 9

5.5 Computer 10

5.6 USB Device 10

6 Switch Source 12

6.1 Source List 12

6.2 Rename Device 12

7 Channels 13

7.1 About Channels and Switch Channels 13

7.2 Install Channel 13

7.3 Channel List 15

7.4 Select Channel Filter 16

7.5 Favorite Channels 16

7.6 Closed Caption (CC) and Language 16

7.7 Ginga 17

8 TV guide 18

8.1 What You Need 18

8.2 Using the TV Guide 18

9 Recording and Pause TV 20

9.1 What You Need 20

9.2 Recording 20

9.3 Pause TV 21

10 Videos, Photos and Music 22

10.1 From a USB Connection 22

10.2 Photos 22

10.3 Videos 22

10.4 Music 23

11 Open TV Setting Menus 24

11.1 Home Menu Overview 24

11.2 Utilities Menu 24

11.3 Quick Settings and All Settings 24

11.4 All Settings 24

12 Environmental 31

12.1 End of Use 31

13 Specifications 32

13.1 Power 32

13.2 Reception 32

13.3 Display Resolution 32

13.4 Display Input Resolution 32

13.5 Sound 32

13.6 Multimedia 32

13.7 Connectivity 33

14 Troubleshooting 34

14.1 Tips 34

14.2 Switch On 34

14.3 Remote Control 34

14.4 Channels 34

14.5 Picture 35

14.6 Sound 35

14.7 HDMI 35

14.8 USB 35

15 Safety and Care 37

15.1 Safety 37

15.2 Screen Care 38

15.3 Terms of Use 38

16 Copyrights 39

16.1 HDMI 39

16.2 Dolby Audio 39

16.3 DTS 2.0 + Digital Out ™ 39

16.4 Other Trademarks 39

17 Open Source 40

17.1 Open Source Software 40

17.2 Open Source License 40

Index 43

Get Support

1.1

Identify and Register your TV

Identify your TV - TV model number and serial

number

You might be asked to provide the TV product model

number and serial number. Find these numbers on

the packaging label or on the type label on the back

or bottom of the TV.

including full support (including downloads),

privileged access to information about new products,

exclusive offers and discounts, the chance to win

prizes and even participate in special surveys about

new releases.

Go to www.philips.com/welcome

1.2

TV Help and User Manual

Press  SETUP > Help

In the Help menu, you can easily get software

updates, reset TV to default settings, and read the

user manual.

- Update software: Check available software updates.

- User manual: Read the user manual for TV

information.

- Troubleshooting: Find a solution for frequently

asked questions.

- Factory settings: Reset all settings to factory

settings.

- Reinstall TV: Reinstall and redo the complete TV

installation.

- Contact info: Show the telephone number or web

address for your country or region.

1.3

On-line Help and User

Manual

To solve any Philips TV related problem, you can

consult our online support. You can select your

language and enter your product model number.

Go to www.philips.com/TVsupport.

On the support site you can find your country's

telephone number to contact us as well as answers to

frequently asked questions (FAQs). In some countries,

you can chat with one of our collaborators and ask

your question directly or send a question by email.

You can download new TV software or the manual to

read on your computer.

For more TV troubleshooting and frequently asked

questions (FAQs)...

to http://philips-tvconsumercare.kxondemand.com/

portal/en/ModelSelect

TV Help on your tablet, smartphone or computer

To carry out extended sequences of instructions more

easily, you can download the TV Help in PDF format

to read on your smartphone, tablet or

computer. Alternatively, you can print the relevant

Help page from your computer.

To download the Help (user manual) go

to www.philips.com/TVsupport

1.4

Consumer Care / Repair

For support and repair, call the Consumer Care

hotline in your country. Our service engineers will take

care of a repair, if necessary.

Find the telephone number in the printed

documentation that came with the TV.

Or consult our

website www.philips.com/TVsupport and select

your country if needed.

TV model number and serial number

You might be asked to provide the TV product model

number and serial number. Find these numbers on

the packaging label or on the type label on the back

or bottom of the TV.

 Warning

Do not attempt to repair the TV yourself. This may

cause severe injury, irreparable damage to your TV or

void your warranty.

Software

2.1

Update Software

Search for Updates

 (Home) > Settings > Update

software > Search for updates.

You need a computer and a USB memory device to

upload the software on the TV. Use a USB memory

device with 256MB free space. Make sure that write

protection is switched off.

1. Start the update on TV

- (Home) > Settings > Update

software > Search for updates.

2. Identify the TV

- Insert the USB memory into one of the USB

connections of the TV.

Select Start and press OK. An identification file is

written on the USB memory device.

3. Download the TV software

- Insert the USB memory into your computer.

- On the USB memory device, locate the

file update.htm and double click it.

- Click on Send ID.

- Select your region

- If new software is available, download the .zip file.

After the download, unzip the file and copy the

file autorun.upg onto the USB memory device.

Do not place this file in a folder.

4. Update the TV software

Insert the USB memory into the TV again. The update

starts automatically.

The TV switches itself off for 10 seconds and then

back on again. Please wait.

Do not . . .

- use the remote control

- remove the USB memory device from the TV

If a power cut occurs during the update, never

remove the USB memory device from the TV. When

the power returns, the update will continue.

Local Updates

For dealers and expert users…

 (Home) > Settings > Update software > Local

updates.

2.2

Software Version

To view the current TV software version…

 (Home) > Settings > Update

software > Current software Info

Quick Guide

3.1

Remote Control

Batteries and Cleaning

Replace batteries

If the TV does not react on a key press on the remote

control, the batteries might be empty.

To replace the batteries, open the battery

compartment on the back of the remote control.

1. Slide the battery door in the direction shown by the

arrow.

2. Replace the old batteries with 2

type AAA-R03-1.5V batteries. Make sure the + and -

ends of the batteries line up correctly.

3. Reposition the battery door and slide it back until it

clicks.

- Remove the batteries if you are not using the

remote control for a long time.

- Safely dispose of your old batteries according to the

end of use directions.

Cleaning

Your remote control is treated with a scratch-resistant

coating.

To clean the remote control, use a soft damp cloth.

Never use substances such as alcohol, chemicals or

household cleaners on the remote control.

Key Overview

Top

1.  Standby / On

To switch the TV on or back to Standby.

2. Playback keys

- Play , to playback

- Pause , to pause playback

- Stop , to stop playback

- Rewind , to rewind

- Fast forward , to go fast forward

3.  TV GUIDE

To open or close the TV Guide.

4.  USB

To access USB storage device.

5.  FORMAT

To open or close the Picture format menu.

6.  SETUP

To open the Settings menu.

Middle

1. HOME

To open or close the home menu.

2.  SOURCES

To open or close the Sources menu - the list of

connected devices.

3. Color keys

The buttons function follow the on-screen

instructions.

4. INFO

To open or close program infomation.

5.  BACK

To switch back to the previous channel you selected.

To close a menu without changing a setting.

6.  EXIT

To switch back to watching TV.

7.  OPTIONS

To open or close the Options menu.

8. OK key

To confirm a selection or setting.

9. Arrow / navigation keys

To navigate up, down, left or right.

10.  LIST

To open or close the channel list.

Bottom

1.  Volume

To adjust the volume level.

2. Number keys

To select a TV channel directly.

3. CC (Closed captions)

To switch Closed captions on, off or On during mute.

4.  Channel

To switch to the next or previous channel in the

channel list. To start the next or previous chapter on a

disc.

5.  Mute

To mute the sound or to restore it.

6. (Dot)

To enter digital sub-channels.

3.2

IR sensor

The TV can receive commands from a remote control

that uses infrared (IR) to send commands. If you use

this kind of remote control, always point it at the

infrared sensor on the front of the TV.

 Warning

Do not put any objects in front of IR sensor of the TV

as it may block the IR signal.

3.3

Joysticker - Local Control

Keys on TV

If you lost the remote control or its batteries are

empty, you can still do some basic TV operations.

To open the basic menu…

1. With the TV switched on, press the joystick key on

the back of the TV to bring up the basic menu.

2. Press left or right to select  Volume, 

Channel or  Sources.

Press up or down to adjust the volume or tune to the

next or previous channel. Press up or down to go

through the list of sources, including the tuner

selection.

The menu will disappear automatically.

Setting Up

4.1

Read Safety

Read the safety instructions first before you use the

TV.

To read the instructions, in User manual, see

chapter Safety and Care.

4.2

TV Placement

Tips on Placement

- Position the TV where light does not shine directly

on the screen.

- Position the TV up to 6 inches away from the wall.

- The ideal distance to watch TV is 3 times its

diagonal screen size. When seated, your eyes should

be level with the center of the screen.

TV Stand

You can find the instructions for mounting the TV

stand in the Quick Start Guide that came with the TV.

In case you lost this guide, you can download it

from www.philips.com.

Use the model number of the TV to look for

the Quick Start Guide to download.

Wall Mounting

5503 series TV

Your TV is also prepared for a VESA-compliant wall

mount bracket (sold separately).

Use the following VESA code when purchasing the

wall mount . . .

- 43PFD5503 - VESA MIS-F 200x100, M6 (Minimum

9 mm, Maximum 11 mm)

Preparation

First remove the 4 plastic screw caps out of the

threaded bushes on the back of the TV.

Make sure that the metal screws, to mount the TV to

the VESA-compliant bracket, go about 10mm deep

inside the threaded bushes of the TV.

Caution

Wall mounting the TV requires special skills and

should only be performed by qualified personnel. The

TV wall mounting should meet safety standards

according to the TVs weight. Also read the safety

precautions before positioning the TV.

TP Vision Europe B.V. bears no responsibility for

improper mounting or any mounting that results in

accident or injury.

4503 series TV

Your TV is also prepared for a VESA-compliant wall

mount bracket (sold separately).

Use the following VESA code when purchasing the

wall mount . . .

- 32PHD4503 - VESA MIS-F 100, M4 (Minimu

m 10mm, Maximum 14 mm)

Preparation

First remove the 4 plastic screw caps out of the

threaded bushes on the back of the TV.

Make sure that the metal screws, to mount the TV to

the VESA-compliant bracket, go about 10mm deep

inside the threaded bushes of the TV.

Caution

Wall mounting the TV requires special skills and

should only be performed by qualified personnel. The

TV wall mounting should meet safety standards

according to the TVs weight. Also read the safety

precautions before positioning the TV.

TP Vision Europe B.V. bears no responsibility for

improper mounting or any mounting that results in

accident or injury.

4.3

Turn on TV

Connect Power Cable

- Insert the power cable into the POWER connector

on the back of the TV.

- Make sure the power cable is securely inserted in

the connector.

- Make sure that the power plug in the wall outlet is

accessible at all times.

- When you unplug the power cable, always pull the

plug, never pull the cable.

Although this TV has a very low standby power

consumption, unplug the power cable to save energy

if you do not use the TV for a long period of time.

Switch On or Standby

Before you switch on the TV, make sure you plugged

in the mains power in the POWER connector on the

back of the TV.

Switch On

Press the power button on the side or the back of the

TV.

Switch to standby

To switch the TV to Standby, press  on the remote

control.

To switch off the TV completely, disconnect the

power plug.

When disconnecting the power plug, always pull the

power plug, never the cord. Ensure that you have full

access to the power plug, power cord and outlet

socket at all times.

Connections

5.1

Connectivity guide

Always connect a device to the TV with the highest

quality connection available. Also, use good quality

cables to ensure a good transfer of picture and

sound.

When you connect a device, the TV recognizes its

type and gives each device a correct type name. You

can change the type name if you wish. If a correct

type name for a device is set, the TV automatically

switches to the ideal TV settings when you switch to

this device in the Sources menu.

If you need help to connect several devices to the TV,

you can visit the Philips TV connectivity guide. The

guide offers information on how to connect and

which cables to use.

Go to www.connectivityguide.philips.com

5.2

Antenna

Insert the antenna plug firmly into

the Antenna socket at the back of the TV.

You can connect your own antenna or an antenna

signal from an antenna distribution system. Use an

IEC Coax 75 Ohm RF antenna connector.

5.3

Video Device

HDMI

For best signal quality transfer, use a High speed

HDMI cable and do not use an HDMI cable longer

than 5 m.

Copy protection

HDMI cables support HDCP (High-bandwidth Digital

Content Protection). HDCP is a copy protection signal

that prevents copying content from a DVD disc or Blu-

ray Disc. Also referred to as DRM (Digital Rights

Management).

HDMI - DVI

If you still own a device that only has a DVI

connection, you can connect the device to

HDMI connection with a DVI to HDMI adapter.

Use HDMI connection and add an Audio L/R cable

to Audio In for sound, on the back of the TV.

HDMI-CEC Connection - EasyLink

Connect HDMI CEC-compatible devices to your TV,

you can operate them with the TV remote

control. EasyLink HDMI CEC must be switched on on

the TV and the connected device.

Switch on EasyLink

 (Home) > Settings > General

settings > EasyLink > EasyLink > On

Operate HDMI CEC-compatible devices with TV

remote control

 (Home) > Settings > General

settings > EasyLink > EasyLink remote

control > On

Note:

- EasyLink might not work with devices from other

brands.

- The HDMI CEC functionality has different names on

different brands. Some examples are: Anynet, Aquos

Link, Bravia Theater Sync, Kuro Link, Simplink and

Viera Link. Not all brands are fully compatible with

EasyLink. Example HDMI CEC branding names are

property of their respective owners.

5.4

Audio Device

HDMI ARC

Only HDMI 2 on the TV has HDMI ARC (Audio

Return Channel).

If the device, typically a Home Theater System (HTS),

also has the HDMI ARC connection, connect it

to HDMI 2 ARC connection on this TV. With the

HDMI ARC connection, you do not need to connect

the extra audio cable that sends the sound of the TV

picture to the HTS. The HDMI ARC connection

combines both signals.

Digital Audio Out - Optical

Audio Out - Optical is a high quality sound

connection.

This optical connection can carry 5.1 audio channels.

If your device, typically a Home Theater System

(HTS), has no HDMI ARC connection, you can use this

connection with the Audio In - Optical connection on

the HTS. The Audio Out - Optical connection sends

the sound from the TV to the HTS.

Headphones

You can connect a set of headphones to

the  connection on the side of the TV. The

connection is a mini-jack 3.5mm. You can adjust the

volume of the headphones separately.

5.5

Computer

HDMI - DVI

If you still own a device that only has a DVI

connection, you can connect the device

to a HDMI connection with a DVI to HDMI adapter.

Use a DVI to HDMI adapter if your device only has a

DVI connection. Use HDMI connection and add an

Audio L/R cable for sound on the back of the TV.

Ideal Settings

 (Home) > Settings > Picture >

Advanced > Computer

Set to On to have the ideal picture settings for using

your TV as a computer monitor.

* Only available for HDMI sources.

5.6

USB Device

USB Flash Drive

You can view photos or play your music and videos

from a connected USB flash drive. Insert a USB flash

drive in the USB connection on the TV while the TV

is switched on.

The TV detects the flash drive and opens a list

showing its content.

If the contents list does not appear automatically,

press  SOURCES and select USB.

USB Hard Drive

If you connect a USB Hard Drive, you can pause or

record digital TV broadcasts (ISDB broadcasts or

similar).

Minimum Disk Space

- To pause a broadcast, you need a USB compatible

Hard Drive with a minimum of 4GB disk space.

- To pause and record a broadcast, you need a

minimum of 32GB disk space.

Before you can pause or record a broadcast, you

must connect and format a USB Hard Drive.

Formatting removes all files from the USB Hard Drive.

To Pause

To pause a broadcast, you need a USB-compatible

Hard Drive with a minimum of 4GB of disk space.

To Record

To pause and record a broadcast, you need a

minimum of 32GB of disk space.

1. Connect the USB Hard Drive to one of

the USB connections on the TV. Do not connect

another USB device to the other USB ports when

formatting.

2. Switch on the USB Hard Drive and the TV.

3. When the TV is tuned to a digital TV channel,

Table des matières

Autres manuels Philips TV

Philips

Philips 9206 Series Manuel utilisateur

Philips

Philips 27PT320 Manuel

Philips

Philips SignageSolutions 98BDL4150D Manuel utilisateur

Philips

Philips 6402 series Manuel utilisateur

Philips

Philips DCD778 Manuel utilisateur

Philips

Philips 50PUS8505 Manuel utilisateur

Philips

Philips 50PFL3707/F8 Manuel utilisateur

Philips

Philips 46PP962A/19 Manuel utilisateur

Philips

Philips 32PW9523-05M Manuel utilisateur

Philips

Philips 25PT5207/60 Manuel utilisateur

Philips

Philips 42FD9944-69S Manuel utilisateur

Philips

Philips 32PFL3008H/12 Manuel utilisateur

Philips

Philips 43PUG7408/78 Manuel utilisateur

Philips

Philips 43PUS6162/12 Manuel utilisateur

Philips

Philips 6707 Series Manuel utilisateur

Philips

Philips The One 55PUS8508/62 Manuel utilisateur

Philips

Philips 29PT6433 Manuel utilisateur

Philips

Philips 39PFL2608/F7 Manuel utilisateur

Philips

Philips 34PT6361 Manuel utilisateur

Philips

Philips Colour Television Manuel utilisateur

Philips

Philips 4304 Series Manuel utilisateur

Philips

Philips 6916 Series Manuel utilisateur

Philips

Philips 32PFH5501 Manuel utilisateur

Philips

Philips 58PFL4909 Manuel utilisateur

Manuels TV populaires d'autres marques

Toshiba

Toshiba 27A10 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur

Sanyo

Sanyo CE19LD90N-B Manuel utilisateur

North State

North State TV2GO Manuel utilisateur

RCA

RCA RTU7877 Manuel utilisateur

Sharp

Sharp 21K-FG1RU Manuel utilisateur

Sony

Sony Esprit TAV-L1 Manuel utilisateur

Grundig

Grundig 43 VLE 4820 Manuel utilisateur

Samsung

Samsung LN26C350D1D Manuel utilisateur
