Philips 257E7 Manuel utilisateur

www.philips.com/welcome

227E7

237E7

257E7

277E7

EN User manual 1

Customer care and warranty 19

Troubleshooting & FAQs 23

Table of Contents

1. Important ....................................... 1

1.1 Safety precautions and

maintenance .................................. 1

1.2 Notational Descriptions ............. 3

1.3 Disposal of product and packing

material........................................... 3

2. Setting up the monitor............... 5

2.1 Installation..................................... 5

2.2 Operating the monitor.................7

2.3 MHL (Mobile High-Denition

Link) introduction ........................ 9

2.4 SoftBlue Technology

introduction..................................10

3. Image Optimization.................... 11

3.1 SmartImage Lite ........................... 11

3.2 SmartContrast.............................. 12

4. Technical Specications ........... 13

4.1 Resolution & Preset Modes .....16

5. Power Management .................. 17

6. Customer care and warranty ...19

6.1 Philips’ Flat Panel Monitors

Pixel Defect Policy......................19

6.2 Customer Care & Warranty...... 22

7. Troubleshooting & FAQs.......... 23

7.1 Troubleshooting......................... 23

7.2 General FAQs.............................. 24

7.3 MHL FAQs....................................26

1. Important

This electronic user’s guide is intended

for anyone who uses the Philips

monitor. Take time to read this user's

manual before you use your monitor.

It contains important information and

notes regarding the operation of your

monitor.

The Philips guarantee applies provided

the product is handled properly for

its intended use, in accordance with

its operating instructions and upon

presentation of the original invoice

or cash receipt, indicating the date of

purchase, dealer’s name and model and

production number of the product.

1.1 Safety precautions and

maintenance

Warnings

Use of controls, adjustments or

procedures other than those specified

in this documentation may result in

exposure to shock, electrical hazards

and/or mechanical hazards.

Read and follow these instructions

when connecting and using your

computer monitor.

Operation

• Please Keep the monitor out of

direct sunlight, very strong bright

lights and away from any other heat

source. Lengthy exposure to this

type of environment may result in

discoloration and damage to the

monitor.

• Remove any object that could fall

into ventilation holes or prevent

proper cooling of the monitor’s

electronics.

• Do not block the ventilation holes

on the cabinet.

• When positioning the monitor, make

sure the power plug and outlet are

easily accessible.

• If turning o the monitor by detach-

ing the power cable or DC power

cord, wait for 6 seconds before

attaching the power cable or DC

power cord for normal operation.

• Please use approved power cord

provided by Philips at all times. If

your power cord is missing, please

contact your local service center.

(Please refer to Customer Care Con-

sumer Information Center)

• Do not subject the monitor to se-

vere vibration or high impact condi-

tions during operation.

• Do not knock or drop the monitor

during operation or transportation.

Maintenance

• To protect your monitor from pos-

sible damage, do not put excessive

pressure on the LCD panel. When

moving your monitor, grasp the

frame to lift; do not lift the monitor

by placing your hand or ngers on

the LCD panel.

• Unplug the monitor if you are not

going to use it for an extensive pe-

riod of time.

• Unplug the monitor if you need to

clean it with a slightly damp cloth.

The screen may be wiped with a

dry cloth when the power is o.

However, never use organic solvent,

such as, alcohol, or ammonia-based

liquids to clean your monitor.

• To avoid the risk of shock or perma-

nent damage to the set, do not ex-

pose the monitor to dust, rain, water,

or excessive moisture environment.

• If your monitor gets wet, wipe it with

dry cloth as soon as possible.

• If foreign substance or water gets in

your monitor, please turn the power

1. Important

o immediately and disconnect the

power cord. Then, remove the for-

eign substance or water, and send it

to the maintenance center.

• Do not store or use the monitor in

locations exposed to heat, direct

sunlight or extreme cold.

• In order to maintain the best per-

formance of your monitor and use

it for a longer lifetime, please use

the monitor in a location that falls

within the following temperature

and humidity ranges.

• Temperature: 0-40°C 32-104°F

• Humidity: 20-80% RH

• IMPORTANT: Always activate a mov-

ing screen saver program when you

leave your monitor unattended.

Always activate a periodic screen

refresh application if your monitor

will display unchanging static con-

tent. Uninterrupted display of still

or static images over an extended

period may cause “burn in”, also

known as “after-imaging” or “ghost

imaging”, on your screen.

• "Burn-in", "after-imaging", or "ghost

imaging" is a well-known phenom-

enon in LCD panel technology.

In most cases, the “burned in” or

“after-imaging” or “ghost imag-

ing” will disappear gradually over a

period of time after the power has

been switched o.

Warning

Failure to activate a screen saver, or

a periodic screen refresh application

may result in severe “burn-in” or “after-

image” or “ghost image” symptoms

that will not disappear and cannot be

repaired. The damage mentioned above

is not covered under your warranty.

Service

• The casing cover should be opened

only by qualied service personnel.

• If there is any need for any docu-

ment for repair or integration,

please contact with your local

service center. (please refer to the

chapter of "Consumer Information

Center")

• For transportation information,

please refer to "Technical Specica-

tions".

• Do not leave your monitor in a car/

trunk under direct sun light.

Note

Consult a service technician if the

monitor does not operate normally, or

you are not sure what procedure to take

when the operating instructions given in

this manual have been followed.

1. Important

1.2 Notational Descriptions

The following subsections describe

notational conventions used in this

document.

Notes, Cautions and Warnings

Throughout this guide, blocks of text

may be accompanied by an icon and

printed in bold or italic type. These

blocks contain notes, cautions or

warnings. They are used as follows:

Note

This icon indicates important

information and tips that help you make

better use of your computer system.

Caution

This icon indicates information that

tells you how to avoid either potential

damage to hardware or loss of data.

Warning

This icon indicates the potential for

bodily harm and tells you how to avoid

the problem.

Some warnings may appear in alternate

formats and may not be accompanied

by an icon. In such cases, the specific

presentation of the warning is mandated

by the relevant regulatory authority.

1.3 Disposal of product and

packing material

Waste Electrical and Electronic

Equipment-WEEE

This marking on the product or on

its packaging illustrates that, under

European Directive 2012/19/EU

governing used electrical and electronic

appliances, this product may not be

disposed of with normal household

waste. You are responsible for disposal

of this equipment through a designated

waste electrical and electronic

equipment collection. To determine the

locations for dropping off such waste

electrical and electronic, contact your

local government office, the waste

disposal organization that serves your

household or the store at which you

purchased the product.

Your new monitor contains materials

that can be recycled and reused.

Specialized companies can recycle

your product to increase the amount of

reusable materials and to minimize the

amount to be disposed of.

All redundant packing material has been

omitted. We have done our utmost to

make the packaging easily separable

into mono materials.

Please find out about the local

regulations on how to dispose of your

old monitor and packing from your sales

representative.

Taking back/Recycling Information for

Customers

1. Important

Philips establishes technically and

economically viable objectives

to optimize the environmental

performance of the organization's

product, service and activities.

From the planning, design and

production stages, Philips emphasizes

the important of making products that

can easily be recycled. At Philips,

end-of-life management primarily

entails participation in national take-

back initiatives and recycling programs

whenever possible, preferably

in cooperation with competitors,

which recycle all materials (products

and related packaging material) in

accordance with all Environmental

Laws and taking back program with the

contractor company.

Your display is manufactured with high

quality materials and components

which can be recycled and reused.

To learn more about our recycling

program please visit

http://www.philips.com/

about/sustainability/

ourenvironmentalapproach/

ourrecyclingprogram/index.page

2. Setting up the monitor

2.1 Installation

Package contents

227E7/237E7

257E7/277E7

Philipsand the Philips’Shield Emblem are registered trademar ks of

KoninklijkePhilips N.V.and are used under license from Koninklijke

PhilipsN.V.

Monitor drivers

User’sManual

使用前请阅读使用说明

保留备用

* CD

AC/DC Adapter * VGA

* HDMI

(227E7EDS/237E7EDS

/257E7EDS/277E7EDS)

* DVI

* Different according to region.

Note

Use only the AC/DC adapter model:

Philips ADPC1936 (227E7ES/227E7EDS/

237E7ES/237E7EDS/257E7ES/277E7ES/

277E7EDS)

Philips ADPC1945 (257E7EDS)

Install base stand

1. Place the monitor face down on soft

and smooth surface taking care to

avoid scratching or damaging the

screen.

2. Hold the base stand with both

hands and firmly insert the base

stand into the base column.

(1) Gently attach the base to the base

column until the latch locks the

base.

(2) Use your fingers to tighten the

screw located at the bottom of

the base, and secure the base to

the column tightly.

2. Setting up the monitor

Connecting to your PC

227E7ES, 237E7ES, 257E7ES, 277E7ES:

AC/DC power input

VGA input

DVI input

Kensington anti-theft lock

227E7EDS, 237E7EDS, 257E7EDS,

277E7EDS：

AC/DC power input

HDMI Audio out

VGA input

DVI input

MHL-HDMI input

Kensington anti-theft lock

Connect to PC

1. Connect the power cord to the back

of the monitor firmly.

2. Turn off your computer and unplug

its power cable.

3. Connect the monitor signal cable to

the video connector on the back of

your computer.

4. Plug the power cord of your

computer and your monitor into a

nearby outlet.

5. Turn on your computer and monitor.

If the monitor displays an image,

installation is complete.

2. Setting up the monitor

2.2 Operating the monitor

Front view product description

Press more than 3 seconds

to switch display power ON

or OFF.

Access the OSD menu

Confirm the OSD adjustment.

227E7ES/237E7ES/257E7ES

/277E7ES:

Change display format.

227E7EDS/237E7EDS/257E7

EDS/277E7EDS:

Adjust the speaker volume.

Adjust the OSD menu.

Change the signal input

source.

Adjust the OSD menu.

SmartImage Lite. There are

three

modes to be selected:

Standard,

Internet and Game.

Return to previous OSD

level.

Description of the On Screen Display

What is On-Screen Display (OSD)?

On-Screen Display (OSD) is a feature in

all Philips LCD monitors. It allows an end

user to adjust screen performance or

select functions of the monitors directly

through an on-screen instruction

window. A user friendly on screen

display interface is shown as below:

227E7ES, 237E7ES, 257E7ES, 277E7ES:













 

227E7EDS, 237E7EDS, 257E7EDS,

277E7EDS:

















Basic and simple instruction on the

control keys

To access the OSD menu on this Philips

Display simply use the single toggle

button on the backside of the Display

bezel. The single button operates like

a joystick. To move the cursor, simply

toggle the button in four directions.

Press the button to select desired

option.

2. Setting up the monitor

The OSD Menu

Below is an overall view of the structure

of the On-Screen Display. You can use

this as a reference when you want to

work your way around the different

adjustments later on.

Main menu Sub menu


OSD Settings

Setup

Language

Color

Audio

(available for

selective models)

Input

Picture Format

Brightness

Contrast

Horizontal

Vertical

Transparency

OSD Time Out

H.Position

Auto

V.Position

Phase

Clock

Resolution Notification

Reset

Information

English, Deutsch, Español, Ελληνική, Français,

Italiano, Maryar，Nederlands, Português,

Português do Brasil，Polski，Русский ,Svenska，

Suomi，Türkçe，Čeština，Українська, 简体中文,

繁體中文，日本語，한국어

Color Temperature

sRGB

User Define

Mute

VGA

DVI

MHL-HDMI (available for selective models)

SmartResponse

SmartContrast

Gamma

Over Scan

(available for selective models)

Pixel Orbiting

Volume

Wide Screen, 4:3

0~100

Off, 1, 2, 3, 4

5s, 10s, 20s, 30s, 60s

0~100

On, Off

Yes, No

0~100

Default, 6500K, 9300K

Red: 0~100

0~100

Green: 0~100

Blue: 0~100

Off, Fast, Faster, Fastest

On, Off

1.8, 2.0, 2.2, 2.4, 2.6

On, Off

Resolution notification

This monitor is designed for optimal

performance at its native resolution,

1920×1080@60Hz. When the monitor

is powered on at a different resolution,

an alert is displayed on screen: Use

1920×1080@60Hz for best results.

Display of the native resolution alert can

be switched off from Setup in the OSD

(On Screen Display) menu.

Physical Function

Tilt

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips TV

Philips

Philips 28PT4521/19 Manuel utilisateur

Philips

Philips 29PT6456 Manuel utilisateur

Philips

Philips 6100 series Manuel utilisateur

Philips

Philips 14AA3324/08B Manuel utilisateur

Philips

Philips 42PF5421/10 Guide de démarrage rapide

Philips

Philips HFL2869T Series Manuel utilisateur

Philips

Philips 20PV184 Manuel utilisateur

Philips

Philips Essence 5000 Series Manuel utilisateur

Philips

Philips 24PHT4003/98 Manuel utilisateur

Philips

Philips 7505 Series Manuel utilisateur

Philips

Philips 8217 Series Manuel utilisateur

Philips

Philips 21PT2012 Manuel utilisateur

Philips

Philips OLED806 Series Manuel utilisateur

Philips

Philips 20PT9007D-17B Mode d’emploi

Philips

Philips 5504 Series Manuel utilisateur

Philips

Philips OLED806 Series Manuel utilisateur

Philips

Philips 32PFL7572D - annexe 2 Manuel utilisateur

Philips

Philips 37PFL3403/93 Manuel utilisateur

Philips

Philips 50PFL6902 Manuel utilisateur

Philips

Philips Econova 42PFL6805H Manuel utilisateur

Philips

Philips COLOR TV 25 INCH TABLE TS2574C Manuel utilisateur

Philips

Philips MAGNAVOX PR1917C1 Manuel utilisateur

Philips

Philips 50PUT8215 Manuel utilisateur

Philips

Philips 25CE5270 Manuel utilisateur

Manuels TV populaires d'autres marques

Toshiba

Toshiba 27A10 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur

Sanyo

Sanyo CE19LD90N-B Manuel utilisateur

North State

North State TV2GO Manuel utilisateur

RCA

RCA RTU7877 Manuel utilisateur

Sharp

Sharp 21K-FG1RU Manuel utilisateur

Sony

Sony Esprit TAV-L1 Manuel utilisateur

Grundig

Grundig 43 VLE 4820 Manuel utilisateur

Samsung

Samsung LN26C350D1D Manuel utilisateur
