14PT1501

14PT1521

21PT1820

Telra_12536-951 (GB) 6 Front Pag1 1 1/13/2006 5:06:54 PM

Telra_12536-951 (GB) 6 Front Pag2 2 1/13/2006 5:06:55 PM

MODEL :

PROD. NO :

Please note the reference numbers

for yourTV set located on the

packaging or on the back of the set.

FR Veuillez noter les références de

votre téléviseur situées sur

l’emballage ou au dos de l’appareil.

NL Let op de referenties van uw

televisietoestel die op de

verpakking of op de achterkant

van het toestel staan.

DE Notieren Sie die

Referenznummern

IhresFernsehgeräts, die sich auf der

Verpackung bzw. auf der

Rückseite des Geräts befinden.

IT Notare i riferimenti del vostro

televisore situati sull’imballaggio o

sul retro dell’apparecchio.

GR ™ËÌÂÈÒÛÙÂ ÙÈ˜ Ô‰ËÁ›Â˜ ¯Ú‹ÛË˜

ÙË˜ ÙËÏÂﬁÚ·Û‹˜ Û·˜ Ô˘

‚Ú›ÛÎÔÓÙ·È ÛÙË Û˘ÛÎÂ˘·Û›· ‹

ÛÙÔ ›Ûˆ Ì¤ÚÔ˜ ÙË˜ Û˘ÛÎÂ˘‹˜

Introduction

Table of Contents

Thank you for purchasing this television set.

This handbook has been designed to help you install and operate your TV set.

We would strongly recommend that you read it thoroughly.

We hope our technology meets entirely with your satisfaction.

Note: Specification and information subject to change without notice.

Installation

Installingyourtelevisionset ..........................................2

ThekeysontheTVset ..............................................2

SafetyInformation...................................................3

Theremotecontrolkeys ............................................4

Quickinstallation...................................................5

Programmesort....................................................5

OthersettingsintheInstallmenu......................................5

Manualstore ......................................................6

Operation

Picturesettings ....................................................7

Timerfunction .....................................................8

TVlock...........................................................8

Teletext ..........................................................9

Peripherals

Connectingperipheralequipment.....................................10

Videorecorder ...................................................10

Otherequipment..................................................10

Sideconnections ..................................................10

Toselectconnectedequipment ......................................10

Practical information

Glossary .........................................................11

Safety Information: Electric, Magnetic and Electromagnetic Fields . . . . . . . . . . . .11

Tips.............................................................12

Recycling

This packaging of this set can be recovered or recycled.Apply to the local authorities in

order to minimise environmental waste.

Disposal of your old product.

Your product is designed and manufactured with high quality materials and components,

which can be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a product it means the product

is covered by the European Directive 2002/96/EC. Please inform yourself about the local

separate collection system for electrical and electronic products.

Please act according to your local rules and do not dispose of your old products with

your normal household waste. The correct disposal of your old product will help prevent

potential negative consequences for the environment and human health.

English

FrançaisNederlandsDeutschItaliano∂ÏÏËÓÈÎ¿

Telra_12536-951 1-6 (GB)_130106.1 1 1/16/2006 1:54:50 PM

The television set has 5 keys which are located

on the front or the top of the set depending

on the model. The on/off key switches the TV

set on/off.

The VOLUME - + (- ”+) keys are used

to adjust sound levels. The PROGRAM - +

(- P+ or - +) keys are used to select the

required programmes. To access the menus,

simultaneously hold down the ”- and ”

+ keys. The PROGRAM - + keys may then be

used to select an adjustment and the - ”+

keys to make that adjustment.

To exit from the menus, hold down the 2 ”

- and ”+ keys.

Note: when the Child Lock function is activated,

these keys are unavailable (refer to Features

menu on page 8).

& Positioning the television set

Place your TV on a solid, stable surface,

leaving a space of at least 5 cm around the

appliance. To avoid accidents, do not put

anything on the set such as a cloth or cover,

a container full of liquid (vase) or a heat

source (lamp). The set must not be exposed

to water.

éConnections

• Insert the aerial plug into the :socket at

the rear of the set.

• For the versions equipped with a radio:

insert the radio aerial socket into the FM

ANT socket using the adapter supplied.

If you are using an indoor aerial, reception may

be difficult in certain conditions. You can improve

reception by rotating the aerial. If the reception

remains poor, you will need to use an external

aerial.

• Insert the mains plug into a wall socket (220-

240 V / 50 Hz).

“Remote control

Insert the two R6-type batteries (supplied)

making sure that they are the right way round.

Check that the mode selector is set to TV.

The batteries supplied with this appliance do not

contain mercury or nickel cadmium. If you have

access to a recycling facility, please do not discard

your used batteries (if in doubt, consult your

dealer). When the batteries are replaced, use the

same type.

‘Switching on

To switch on the set, press the on/off key.

A red indicator comes on and the screen

lights up. Go straight to the chapter Quick

installation on page 5.

If the television remains in standby mode,

press P#on the remote control.

The indicator will flash when you use the remote

control.

Installing your television set

The keys on the TV set

5 cm

5 cm 5 cm

FM.�

ANT.

5 cm

5 cm 5 cm

FM.

ANT.

5 cm

5 cm 5 cm

FM.�

ANT.

5 cm

5 cm 5 cm

FM.�

ANT.

5 cm

5 cm 5 cm

FM.�

ANT.

5 cm

5 cm 5 cm

FM.�

ANT.

Telra_12536-951 1-6 (GB)_130106.2 2 1/16/2006 1:54:51 PM

Safety Information

• Plug the TV into a 220V – 240V AC, 50 Hz supply.

• Disconnect mains plug when :

– the red light below the TV screen is flashing continuously.

– a bright white line is displayed across the screen.

– there is a lightning storm.

– the set is left unattended for a prolonged period of time.

• Cleaning the TV screen. Never use abrasive cleaning agents. Use a slight damp chamois leather or

soft cloth.

• No naked flame sources, such as lighted candles, should be placed on top of the TV or in the vicinity.

• Do not place your TV set under direct sunlight or heat.

• Do not cover or block the TV as it could lead to overheating.

• Leave at least 5 cm around each side of TV set to allow for proper ventilation.

• Avoid placing your set (e.g. near the window) where it is likely to be exposed to rain or water.

• Battery Usage CAUTION – To prevent battery leakage that may result in bodily injury, property

damage, or damage to the unit:

– Install all batteries correctly, with + and – aligned as marked on the unit.

– Do not mix batteries (old and new or carbon and alkaline, etc.).

– Remove batteries when the unit is not used for a long time.

• The apparatus must not be exposed to dripping or splashing and no objects filled with liquids, such as

vases, shall be placed on the apparatus.

Useful Tips

• Do not leave your set on standby mode for a prolonged period of time. Switch off set to allow it to

be demagnetised. A demagnetised set supports good picture quality.

• Do not shift or move the set around when it is switched on. Uneveness in colour in some parts of

the screen may occur.

• Never attempt to repair a defective TV yourself. Always consult a skilled service personnel.

Telra_12536-951 1-6 (GB)_130106.3 3 1/16/2006 1:54:51 PM

Remote control keys

&Radio / TV mode

To switch the TV set to radio or TV mode (for

versions equipped with radio).

éSurround Sound (only available on certain versions).

To activate / deactivate the surround sound effect.

In stereo, this gives the impression that the

speakers are further apart. For models equipped

with Virtual Dolby Surround*, you can experience

Dolby Surround Pro Logic sound effects. In mono, a

stereo spatial effect is simulated.

“Screen information / permanent no.

To display / clear the program number, name (if it

exists), time, audio mode and time remaining for the

sleep feature. Press the key for 5 seconds to activate

permanent display of the number.

‘Pre-set sound

Used to access a series of stored settings: Voice,

Music, Theatre and return to Personal.

(Menu

To call up or exit the menus.

§Cursor / Format

These 4 keys are used to navigate through the

menus. The îÏ keys are used to enlarge or

compress the picture vertically.

èVolume

To adjust the sound level.

!Mute

To mute or restore the sound.

çNumber keys

Direct access to the programmes. For a 2 digit program,

enter the 2nd digit before the dash disappears.

0 Sleep

To select an automatic standby after a preset time

(from 0 to 180 minutes).

1 Standby

Lets you place the TV set on standby. To turn on the

TV, press P-@#, b, 0to 9(or Â).

2Sound mode (only available on stereo versions)

Used to force programmes in Stereo to Mono or,

for bilingual programs, to choose between Dual I or

Dual-II. For TV sets equipped for Nicam reception,

depending on the programmes, you can force the

Stereo Nicam sound to Mono or select between

Nicam Dual I, Nicam Dual-II and Mono.

The Mono indication is red when in forced position.

3Teletext keys (p. 9)

4Pre-set image

Used to access a series of stored settings: Rich,

Natural, Soft, Multimedia and return to Personal.

5Teletext (p. 9)

6Program selection

To access the next or previous programme. The

number, (name) and sound mode are displayed for a

few moments.

For some programs, the title of the program will be displayed

at the bottom of the screen.

7Selection of EXT socket

Press several times to select EXT and AV.

‘

(

Telra_12536-951 1-6 (GB)_130106.4 4 1/16/2006 1:54:52 PM

This menu lets you to change the numbering

of programmes.

&Press the Hkey. The MAIN MENU is

displayed on the screen.

éHighlight INSTALLATION and press the

cursor right key.

“Highlight SORT and press the cursor right

key.

‘ Select the programme you want to move with

the îÏ keys and press ¬.

(Then use the îÏ keys to choose the new

number and confirm with È.

§Repeat steps “and ‘as many times as

required to move the programmes.

èTo exit the menus, press Hseveral times.

Quick installation

Programme sort

Other settings in the Install menu

When you turn on the TV set for the first

time, a menu is displayed on screen. This

menu prompts you to select the country and

language for the menus :

If the menu is not displayed, press and hold down

the ”- and ”+ keys on the TV set for 5

seconds to display the menu.

&Use the îÏ keys on the remote control

to select your country and validate with ¬.

If your country does not appear in the list, select

choice “. . .”

éNext select your language using the îÏ

keys and validate with ¬.

“The search starts automatically.

Finally the INSTALLATION menu appears

automatically.

If the programmes found have not been

correctly numbered, use the Sort menu to

renumber them.

If no picture is found see Tips (p. 12).

‘If you want to exit the menus, press H

several times.

&Highlight INSTALLATION and press the

cursor right key. The following items will be

displayed:

• Language : to change the display

language for the menus.

• Country : to select your country (GB for

Great Britain).

This setting is used for the search,

automatic programme sort and teletext

display. If your country does not appear in

the list, select “. . .”

• Auto Store : to start automatic search

for all programmes available in your

region.

Finally the INSTALLATION menu

appears automatically.

If the programmes found have not been

correctly numbered, use the Sort menu to

renumber them.

If no picture is found see Tips (p. 12).

• If you want to exit the menus, press H

several times.

WELCOME

Country

...

Language

ENGLISH

MAIN MENU


FEATURES

INSTALLATION

LANGUAGE ENGLISH

Country ...

Auto Store

Manual Store

Sortrt

Telra_12536-951 1-6 (GB)_130106.5 5 1/16/2006 1:54:52 PM

This menu is used to store the programmes

one at a time or to add a programme to the

existing list.

&Press the MENU key to display the Main

Menu.

éHighlight INSTALLATION and press the

cursor right key.

“Highlight MANUAL STORE and press the

cursor right key.

• System : select Europe (automatic

detection*) or according to the versions

Western Europe (BG standard), Eastern

Europe (DK standard), United Kingdom

(I standard) or France (LL’ standard).

* Except for France (LL’ standard), you must select

the choice France.

• Search : press ¬. The search starts.

Once a programme is found, the scanning

stops. Go to the next step. If you know the

frequency of the required programme,

enter its number directly with the 0to 9

keys.

If no picture is found, consult the possible solutions

(p. 12).

• Fine tuning : if the reception is not

satisfactory, adjust using the È¬keys.

• Programme : enter the desired number with

the keys È¬ or 0to 9.

• Name : use the È¬ keys to move

around the name display area (5 characters)

and the

îÏ

keys to select the characters.

When the name has been entered press the

Èkey to exit.

• Store : press ¬. The programme is stored.

• Repeat steps éto èfor each programme to

be stored.

• To exit the menus press Hseveral times.

Manual store

MAIN MENU


FEATURES

INSTALLATION

Manual Store

Program 01

Name -----

System EUROPE

Search 671 MHz

Fine Tune

Store

Telra_12536-951 1-6 (GB)_130106.6 6 1/16/2006 1:54:53 PM

&From the MAIN MENU, Highlight

PICTURE and press the cursor right key.

é Use the îÏ keys to select a setting and

È¬ keys to adjust.

“Once the adjustments have been made select

Store and press ¬to store them.

‘Press Hseveral times to exit the menus.

Description of the adjustments :

• Brightness : this changes the picture brilliance.

• Colour : this changes the intensity of the

colour.

• Contrast : this changes the difference

between the light and dark tones.

• Sharpness : this changes the picture

definition.

• Colour Temp. : this changes the colour

rendering: Cold (bluer), Normal (balanced)

or Warm (redder).

• NR (Noise Reduction) : reduces picture

noise (snow), in the case of difficult

reception.

• Contrast+ : automatically adjusts contrast of

the picture by making the darkest part of the

picture permanently black.

• Store : to store the picture adjustments.

MAIN MENU


FEATURES

INSTALLATION


Brightness ---I-------

Colour

Contrast

Sharpness

Colour Temp. Normal

NR OFF

Contrast+ ON

Store

Picture settings

Telra_12536-951 1-6 (GB)_130106.7 7 1/16/2006 1:54:53 PM

This menu lets you block use of the TV set.

&From the MAIN MENU, Highlight

FEATURES and press the cursor right key.

éHighlight CHILDLOCK and press the cursor

right key.

“You must enter your secret access code.

The first time, key the code 0711.

The menu is displayed.

‘The next time you switch on the TV set, you

must enter your secret access code to access

the programmes.

(To cancel switch Child Lock to OFF.

§To change the code select New Code and

enter a new 4 figure code. Confirm by

entering a second time.

If you have forgotten your secret code, enter the

universal code 0711.

èPress Hseveral times to exit the menus.

This menu lets you use the TV set as an alarm

clock.

&From the MAIN MENU, Highlight

FEATURES and press the cursor right key.

éHighlight TIMER and press the cursor right

key.

The following items will be displayed:

“Sleep : to select an automatic standby period.

‘Time : enter the current time.

(Start Time : enter the start time.

§Stop Time : enter the stop time.

èProgram No. : enter the number of the

desired programme for the wake-up alarm.

!Activate : you can set :

• Once for a single alarm,

• Daily for each day,

• Off to cancel.

çPress bto put the TV set in standby.

It will automatically come on at the time

programmed. If you leave the TV set on, it will

just change programmes at the time entered

(and go into standby mode at the Stop Time).

Timer function

TV lock

MAIN MENU


FEATURES

INSTALLATION

Timer

Sleep OFF

Time -- : --

Start Time -- : --

Stop Time -- : --

Pr Nr 00

Activate OFF

MAIN MENU


FEATURES

INSTALLATION

FEATURES

Timer

Childlock

Telra_12536-951 1-6 (GB)_130106.8 8 1/16/2006 1:54:53 PM

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Philips TV

Philips

Philips MAGNAVOX TS3661C199 Manuel utilisateur

Philips

Philips 14PT3685/05 Manuel utilisateur

Philips

Philips 22PFL2978H/12 Manuel utilisateur

Philips

Philips 7505 Series Manuel utilisateur

Philips

Philips 14PV010/00P Manuel utilisateur

Philips

Philips 34PW8502 Manuel utilisateur

Philips

Philips 32PFL7613D Manuel utilisateur

Philips

Philips 14PT3131/55R Manuel utilisateur

Philips

Philips 17CE1230 Manuel utilisateur

Philips

Philips MAGNAVOX TS3260C299 Manuel utilisateur

Philips

Philips 34PT9421/69R Manuel utilisateur

Philips

Philips HTS2200 Manuel utilisateur

Philips

Philips 72TA5216 Manuel utilisateur

Philips

Philips 7600 series Manuel utilisateur

Philips

Philips 65PFL5922/F8 Manuel utilisateur

Philips

Philips 55PP9401 Manuel utilisateur

Philips

Philips 20PT4330 Manuel utilisateur

Philips

Philips 8528 Series Manuel utilisateur

Philips

Philips MATCHLINE 32PW9723/12 Manuel utilisateur

Philips

Philips Magnavox 19PR21C1 Manuel utilisateur

Philips

Philips DCD778 Manuel utilisateur

Philips

Philips 19PFL4322/45 Manuel utilisateur

Philips

Philips 29PT8103/12 Manuel utilisateur

Philips

Philips 42OLED818 Manuel utilisateur

Manuels TV populaires d'autres marques

Toshiba

Toshiba 27A10 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur

Sanyo

Sanyo CE19LD90N-B Manuel utilisateur

North State

North State TV2GO Manuel utilisateur

RCA

RCA RTU7877 Manuel utilisateur

Sharp

Sharp 21K-FG1RU Manuel utilisateur

Sony

Sony Esprit TAV-L1 Manuel utilisateur

Grundig

Grundig 43 VLE 4820 Manuel utilisateur

Samsung

Samsung LN26C350D1D Manuel utilisateur
