Philips SPD5220 Manuel utilisateur

External hard disk SPD5220

Ekstern harddisk SPD5230

SPD5240

SPD5250

User manual 3

Brugervejledning 9

4 What’s in the box?

5 How to connect this external hard disk to

your computer?

5 How to safely disconnect?

6 How to use the One-Click Back-Up button?

6 How to install for Mac

7 Warranty, Environment and Safety

8 Specifications

Contents EN

Important note

To startusing the One-Click Back-Up button, first activate the Carry it

Easy software (once only) byclicking on the CarryitEasy.exe file located on your

hard disk. For instructions and more information, see page 6.

When the computer does not recognize the hard disk (some computers

provide insufficient bus power), we advise you to use the Y-cable supplied together

with this product. For instructions and more information, see page 5.

What’s in the box?

A: External hard disk

C: Quick Start Guide

B:Y-cable

How to connect this external hard disk

on your system?

Plug the wrap around USB cable into an empty

USB port of your computer.

Adrive icon, Philips External Hard Disk, appears in

Windows Explorer. (The computer sometimes needs to

be restarted, before you can use the new hardware).

When the computer does not recognize the hard disk

(some computers provide insufficient bus power), we

advise you to use the Y-cable supplied together with this

product. Connect the Y-cable to the USB cable of the

hard disk and plug in the 2 connectors in the free

USB ports of your computer.The black connector is for

data transfer and power, the gray connector is for

additional power only.

How to safely disconnect?

1Double-click the Safely Remove Hardware icon

in the system trayin the lower right part of the screen.

2In the window that appears, select the name of the device that is to be removed,

then click the Stop button.

3When the Stop a hardware device screen appears, make sure the correct

information is displayed, and then click the OK button.

4When the message Safeto remove hardware appears, remove the drive from

the computer’sUSB port.

The hard disk is preconfigured for Windows 2000,Windows XP and Windows Vista,

with a NTFS format. For Mac, the hard disk needs to be formatted to FAT32.

Howto install for Mac

How to use the One-Click Back-Up button

For windows only, this functionality doesn’t work with Mac computers

The One-Click Back-Up button allows you to instantly synchronize or back-up your

files with the CoSoSys Carry it Easy software.To launch the software, double-click on

the CarryitEasy.exe file on the hard disk in your Windows explorer.

Follow the instructions on your screen to get started.

See the Carry it Easy manual in the folder manuals on your hard disk for more

instructions and more information.

Warranty, Environment and Safety

How to find warranty information?

Browse to the Philips warranty folder on the hard disk or look on

www.philips.com/support

You need Adobe Reader software to open these files. If you don’t have Adobe Reader,

you can download it for free on www.adobe.com.

The Philips warranty may not apply if damage is caused by accidents, shock, misuse or

neglect.

‘The making of unauthorized copies of copy-protected material including computer

programs, files, broadcasts and sound recordings, may be an infringement of copyrights

and constitute a criminal offence.This equipment should not be used for such

purposes.’

WEEE mark:“Information to the Consumer”.

Disposal of your old product

Your product is designed and manufactured with high quality materials and

components, which can be recycled and reused. Please inform yourself about the local

separate collection system for electrical and electronic products, including those

marked by the crossed-out wheel bin symbol. Please act according to your local rules

and do not dispose of your old products with your normal household waste.

WARNING

Plastic bags can be dangerous

To avoid danger of suffocation, keep this bag awayfrom babies and small children.

Although this product has been designed with utmost care for long-lasting

performance. Philips does advise you to handle electronics with good care:

Avoid contact with water, exposure to extreme forces.

Please make sure you place the device in a well-ventilated environment, to ensure

longest possible lifetime and optimal performance.

Specifications

Technical Specifications:

Interface Hi-Speed USB 2.0

Transfer speed 480 Mb/s

Rotational speed 5400 rpm

Cache memory 8 MB

System requirements USB1.1 (USB 2.0 for max. transfer speed)

Windows 2000,Windows XP,Windows Vista

For interactive help and support:

www.philips.com/support

For software updates and frequently asked questions:

www.philips.com/storageupdates

9 Hvad er der i æsken?

10 Hvordan tilsluttes denne eksterne harddisk til din

computer?

10 Hvordan frakobles den på en sikker måde?

11 Hvordan bruger man One-Click Back-Up knappen?

11 Hvordan installerer man på en Mac?

12 Garanti, miljø og sikkerhed

13 Specifikationer

Indhold

Vigtigt at bemærke

Når du skal begynde at brugeOne-Click Back-Up knappen, skal du først

aktivere Carry it Easy softwaren (kun én gang) ved at klikke på Carryiteasy.exe-

filen, der ligger på din harddisk. For vejledning og mere information se side 6.

Hvis computeren ikke genkender harddisken (nogle computeres USB-port

leverer ikke spænding nok), anbefaler vi dig at bruge Y-kablet der leveres sammen

med dette produkt. For vejledning og mere information se side 5.

Hvad er der i æsken?

A: Ekstern harddisk

C: Hurtigt i gang - guide

B:Y-kabel
