User manual

Always there to help you

AZ380

Question?

Contact

Philips

1EN

Contents

1 Important 2

2 Your CD Soundmachine 3

Introduction 3

What's in the box 3

Overview of the main unit 4

3 Get started 6

Connect power 6

Turn on 6

Turn off 6

4 Play 7

Play disc 7

Play from USB device 7

Play from an external device 7

Listen to FM or AM (MW) radio 8

Adjust volume 8

5 Play options 9

Repeat or shufe play 9

Program tracks 9

6 Product information 10

Specications 10

Maintenance 10

USB playability information 11

7 Troubleshooting 12

8 Notice 13

Disposal of your old product and

batteries 13

Contents

2EN

1 Important

• Read these instructions.

• Follow all instructions.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or

other apparatus (including ampliers) that

produce heat.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the unit.

• Only use attachments/accessories specied

by the manufacturer.

• Unplug this unit during lightning storms or

when unused for long periods of time.

• Refer all servicing to qualied service

personnel. Servicing is required when the

unit has been damaged in any way, such

as power-supply cord or plug is damaged,

liquid has been spilled or objects have

fallen into the apparatus, the unit has been

exposed to rain or moisture, does not

operate normally, or has been dropped.

• Battery usage CAUTION –To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Remove batteries when the unit is not

used for a long time.

• Batteries (battery pack or batteries

installed) shall not be exposed to excessive

heat such as sunshine, re or the like.

• The unit shall not be exposed to dripping

or splashing.

• Do not place any sources of danger on

the unit (e.g. liquid lled objects, lighted

candles).

• Where the MAINS plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

•Never remove the casing of this apparatus.

•Never place this apparatus on other electrical

equipment.

•Never look into the laser beam inside this apparatus.

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

3EN

2 Your CD

Soundmachine

Introduction

With this unit, you can:

• enjoy audio from discs, USB devices, and

other external devices;

• listen to FM or AM (MW) radio

What's in the box

Check and identify the contents of the package:

• Main unit

• AC power cord

• Quick start guide

4EN

Overview of the main unit

a - ALBUM +

• For MP3/WMA les: skip to the next

or previous album.

b MODE

• Select repeat or shufe mode.

c PROG

• Program tracks.

• Stop play.

• Erase a program.

• Start or pause play.

f /

• Skip to the previous or next track.

• Search within a track.

g Antenna

• Improve radio reception.

5EN

h TUNING

• Tune to radio stations.

i FM/MW

• Select FM or AM (MW) tuner.

• Connect a USB device.

k AC ~

• Connect AC power.

l MP3-LINK

• Connect an external audio device.

m Source selector

• Select a source: CD, USB, or RADIO.

• Turn the unit off.

n - VOLUME +

• Adjust volume.

o Disc compartment

6EN

3 Get started

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Connect power

You can use either AC power or battery as

power supply of this unit.

Battery power

Caution

•Risk of explosion! Keep batteries away from heat,

sunshine or re. Never discard batteries in re.

•Batteries contain chemical substances, so they should

be disposed of properly.

Note

•Batteries are not supplied with the accessories.

1 Open the battery compartment.

2 Insert 6 batteries (type: R14/ UM2/ C Cell)

with correct polarity (+/-) as indicated.

3 Close the battery compartment.

AC power

Warning

•Risk of product damage! Make sure that the power

supply voltage corresponds to the voltage printed on

the back or the underside of the unit.

•Risk of electric shock! When you disconnect the AC

power, always pull the plug or adaptor from the socket.

Never pull the cord.

Connect the AC power cord to:

• the AC ~ socket on the unit.

• the wall outlet.

Turn on

Switch the source selector to CD, USB, or

RADIO.

Turn off

Switch the source selector to OFF.

AC~

7EN

4 Play

Play disc

1 Switch the source selector to CD.

2 Lift to open the disc compartment.

3 Insert a disc with the printed side facing up,

then close the disc compartment.

4 Press to start play.

• To pause or resume play, press .

• To stop play, press .

• For MP3/WMA tracks, press - ALBUM

+to select an album.

• To select a track, press / .

• To search within a track, press and

hold / , then release to resume

normal play.

Play from USB device

Note

•Make sure that the USB device contains playable audio

content.

1 Switch the source selector to USB.

2 Insert the USB device into the socket.

» Play starts automatically. If not, press

Play from an external device

With this unit, you can also listen to an external

audio device such as an MP3 player.

1 Switch the source selector to CD, USB, or

RADIO.

2 Connect the MP3 link cable (not supplied)

to:

• the MP3-LINK socket on the unit.

• the headphone socket on an external

device.

3 Play the external device (see the device's

user manual).

Note

•The MP3-LINK socket is not for headphones.

8EN

Listen to FM or AM (MW)

radio

Note

•Position the antenna as far as possible from TV,VCR or

other radiation source.

•For better reception, fully extend and adjust the

position of the antenna.

1 Switch the source selector to RADIO.

2 Adjust the FM/MW slider to select FM or

AM (MW) tuner.

3 Rotate TUNING to tune to a radio station.

Adjust volume

During play, rotate - VOLUME + to adjust

volume.
