Philips AE6790 Manuel utilisateur

AE6790

Portable radio

User manual

www.philips.com/welcome

4 5

7 8

2 x 1.5V

A/R06/UM3

/R06/UM3

English

Congratulations on your purchase and welcome to Philips!

To fully benefit from the support that Philips offers, register

your product at www.philips.com/welcome.

Top & front panels (see 1)

– switches on/off the standby mode

2TUNING -

– in FM/MW mode, fine tunes a station

– sets hour during clock setting

3TUNING +

– in FM/MW mode, fine tunes a station

– sets minute during clock setting

9DISPLAY

– displays time or radio frequency

0Number Keys

– press to store preset stations

Side panel (see 1)

– 3.5 mm stereo headphone socket

5LOCK/UNLOCK

– disables or enables all other keys

6VOL

– adjusts volume level

7BAND

– press to switch to FM or MW mode

8SET CLOCK/PRESET

– in standby mode, sets the clock

– stores preset station

Power Supply

Batteries (not included)

1 Open the battery door and insert two alkaline batteries, type AAA,

R03 or UM4, as indicated in the battery compartment. (See 1).

• Incorrect use of batteries can cause electrolyte leakage and will corrode the

compartment or cause the batteries to burst:

• Do not mix battery types: e.g. alkaline with carbon zinc. Only use batteries

of the same type for the set.

• When inserting new batteries, do not try to mix old batteries with the new

ones.

• Remove the batteries if the set is not to be used for a long time.

Batteries contain chemical substances, so they should be disposed

of properly.

General information

Antennas

• For MW,the set uses a built-in antenna. Direct this antenna for best

reception by turning the whole set.

Connecting earphones

•You can connect headphones to the headphone socket.

Locking the set

•You can lock the set in any mode by sliding the

LOCK

key.

➜All keys are disabled.

•To unlock the set

➜slide the

LOCK

key to

UNLOCK

Basic operation

1Insert batteries as described in Power Supply.

➜

The clock information is displayed.

•Press

to switch on the set.

•Press

again to switch to standby mode.

2To adjust volume, turn VOL.

Switching on radio

1Press

to switch on the set.

2Press BAND to select FM or MW waveband.

➜ Waveband and radio frequency are displayed

Automatic tuning

•Press and hold

TUNING +/-

;the set searches a station automatically.

Manual tuning

By using this feature, it is possible to manually tune to a specific channel

frequency. In addition to antenna orienting for better radio reception, the

optimum reception can also be obtained by using this feature.

•In FM and MW mode, press

TUNING +/-

to tune to stations.

Storing preset stations manually

You can store up to 10 stations for each band respectively on

PRESET

for easy access.

1In FM and MW mode, tune to your desired radio station (See "Auto

tuning" and “Manual tuning”).

2Press SET CLOCK/PRESET.

3Press number keys to store the preset station 1-5; press the +5 button

followed by a 1-5 button to store preset station 6-10.

Helpful hints:

–If you have already saved a FM, or MW station in that preset number, it

will be overwritten by a new station.

–Preset stations of each band do not overwrite each other.

–Preset stations will be kept even when the set is out of power.

Selecting a preset station

•In FM and MW mode, press 1-5 to select station 1-5; press the +5

button followed by a 1-5 button to select station 6-10 .

Setting time

You can only set time in standby mode.

1Press SET CLOCK/PRESET.

2Press TUNING - to set hour.

3Press SET CLOCK/PRESET once to confirm.

4Press TUNING + to set minute.

5Press SET CLOCK/PRESET once to confirm.

➜ The set exits time setting.

Safety & maintenance information

• Do not expose the set, batteries to humidity, rain, sand or excessive

heat caused by heating equipment or direct sunlight.

• The apparatus shall not be exposed to dripping or splashing.

• Do not cover the ventilation openings with items such as newspapers,

table-cloths, curtains, etc.

• No objects filled with liquids, such as vases, shall be placed on the apparatus.

• No naked flame sources, such as lighted candles, should be placed on

the apparatus.

• The mechanical parts of the set contain selflubricating bearings and

must not be oiled or lubricated.

•To clean the set, use a dry cloth. Do not use any cleaning agents contain-

ing alcohol, ammonia, benzene or abrasives as these may harm the hous-

ing.

• Excessive sound pressure from earphones and headphones can cause

hearing loss.

• Battery shall not be exposed to excessive heat such as sunshine, fire or

the like.

Troubleshooting

If a fault occurs, first check the points listed below before taking the set for

repair.

If you are unable to remedy a problem by following these hints, consult

your dealer or service centre.

WARNING: Do not open the set as there is a risk of electric shock. Under

no circumstances should you try to repair the set yourself, as this will

invalidate the guarantee.

Problem

–Possible cause

•Remedy

No sound /power

–Volume not adjusted

•Adjust the VOL.

–Batteries dead/ incorrectly inserted

•Insert (fresh) batteries correctly

–Headphones connected to the set

•

Disconnect headphones.

Poor radio reception

–Weak radio signal

• For MW,the set uses a built-in antenna. Direct this antenna for best

reception by turning the whole set.

Display does not function properly / No reaction to operation of

any of the controls

–Electrostatic discharge

•Switch off and unplug the set. Reconnect after a few seconds.

Hearing Safety

Listen at a moderate volume.

•Using headphones at a high volume can impair your hearing. This

product can produce sounds in decibel ranges that may cause hearing

loss for a normal person, even for exposure less than a minute. The

higher decibel ranges are offered for those that may have already

experienced some hearing loss.

•Sound can be deceiving. Over time your hearing "comfort level"

adapts to higher volumes of sound. So after prolonged listening, what

sounds "normal" can actually be loud and harmful to your hearing. To

guard against this, set your volume to a safe level before your hearing

adapts and leave it there.

To establish a safe volume level:

•Set your volume control at a low setting.

•Slowly increase the sound until you can hear it comfortably and clearly,

without distortion.

Listen for reasonable periods of time:

•Prolonged exposure to sound, even at normally "safe" levels, can also

cause hearing loss.

•Be sure to use your equipment reasonably and take appropriate breaks.

Be sure to observe the following guidelines when using your

headphones.

•Listen at reasonable volumes for reasonable periods of time.

•Be careful not to adjust the volume as your hearing adapts.

•Do not turn up the volume so high that you can't hear what's around

you.

•You should use caution or temporarily discontinue use in potentially

hazardous situations.

•Do not use headphones while operating a motorized vehicle, cycling,

skateboarding, etc.; it may create a traffic hazard and is illegal in many

areas.

Disposal of your old product

Your product is designed and manufactured with high quality

materials and components, which can be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a

product it means the product is covered by the European Directive

2002/96/EC.

Please inform yourself about the local separate collection system for

electrical and electronic products.

Please act according to your local rules and do not dispose of your old

products with your normal household waste.The correct disposal of

your old product will help prevent potential negative consequences for

the environment and human health.

Environmental information

All unnecessary packaging material has been omitted.The packaging can

be easily separated into three materials: cardboard, polystyrene and plastic.

Your set consists of materials which can be recycled if disas-

sembled by a specialized company. Please observe the local

regulations regarding the disposal of packaging, dead bat-

teries and old equipment.

Meet Philips at the Internet

http://www.philips.com

Printed in China WK819
