Philips PowerLife GC2510 Manuel utilisateur

Steam Iron

GC2650, GC2640, GC2620,

GC2560, GC2530, GC2520, GC2510

L J

A D F GECB

ENGLISH 6

INDONESIA 14

TI”NG VI◊T 22

 30

GC2650, GC2640, GC2620,

GC2560, GC2530, GC2520, GC2510

General description (fig. 1)

ASpray nozzle

BCap of filling opening

CSteam control

- O= no steam

- l= minimum steam

- ;= maximum steam

- 1= Calc-Clean function

DShot-of-steam button

ESpray button T

FAutomatic shut-off light (GC2560 only)

GMains cord

HAnti-Calc tablet

ITemperature light

JType plate

KWater tank

LTemperature dial

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Check if the voltage indicated on the type plate corresponds to

the local mains voltage before you connect the appliance.

◗If the appliance is provided with an earthed plug, it must be

plugged into an earthed wall socket.

◗Do not use the appliance if the plug, the cord or the appliance

itself shows visible damage, or if the appliance has been dropped

or is leaking.

◗Check the cord regularly for possible damage.

◗If the mains cord is damaged, it must be replaced by Philips, a

service centre authorised by Philips or similarly qualified persons

in order to avoid a hazard.

◗Never leave the appliance unattended when it is connected to the

mains.

◗Never immerse the iron and the stand, if provided, in water.

◗Keep the appliance out of the reach of children.

◗Young children should be supervised to ensure that they do not

play with the appliance.

◗This appliance is not intended for use by young children or infirm

persons without supervision.

◗The soleplate of the iron can become extremely hot and may

cause burns if touched.

◗Do not allow the cord to come into contact with the soleplate

when it is hot.

◗When you have finished ironing, when you clean the appliance,

when you fill or empty the water tank and also when you leave the

iron even for a short while: set the steam control to position O, put

the iron on its heel and remove the mains plug from the wall socket.

ENGLISH6

◗Always place and use the iron and the stand, if provided, on a

stable, level and horizontal surface.

◗This appliance is intended for household use only.

Preparing for use

Filling the water tank

1Remove the mains plug from the wall socket.

C2Set the steam control to position O (= no steam).

3Open the cap of the filling opening.

C4Tilt the iron and fill the water tank up to maximum level.

If the tap water in your area is very hard, we advise you to use distilled

water. Do not use chemically descaled water.

Do not fill the water tank beyond the MAX indication.

Do not put perfume, vinegar, starch, descaling agents, ironing aids or

other chemicals in the water tank.

5Close the cap of the filling opening ('click').

Setting the temperature

◗The iron may give off some smoke when you use it for the first

time.This will cease after a short while.

C1Put the iron on its heel and set the temperature dial to the

required ironing temperature by turning it to the appropriate

position.

- Check the laundry care label for the required ironing temperature.

-1Synthetic fabrics (e.g. acrylic, viscose, polyamide, polyester)

-1Silk

-2Wool

-3Cotton, linen

- If you do not know what kind or kinds of fabric an article is made of,

determine the right ironing temperature by ironing a part that will

not be visible when you wear or use the article.

- Silk, woollen and synthetic materials: iron the reverse side of the

fabric to prevent shiny patches. Avoid using the spray function to

prevent stains.

ENGLISH 7

2Put the mains plug in an earthed wall socket.

3When the temperature light has gone out, wait a while before

you start ironing.

BThe temperature light will go on from time to time during ironing.

Using the appliance

Steam ironing

Make sure that there is enough water in the water tank.

1Set the temperature dial to the recommended position (see

section 'Setting the temperature').

C2Set the steam control to the appropriate steam position.

-Áfor minimum steam (temperature settings 2and 3).

-Èfor maximum steam (temperature settings 3to MAX).

BThe iron will start steaming as soon as the set temperature has been

reached.

GC2640/GC2620/GC2530/GC2520/GC2510 only:

Water may leak from the soleplate if the set temperature is too low

(MIN to 2).

Ironing without steam

1Set the steam control to position O(= no steam).

2Set the temperature dial to the recommended position (see

section 'Setting the temperature').

Features

Spray function

You can use the spray function to remove stubborn creases at any

temperature

1Make sure that there is enough water in the water tank.

C2Press the spray button several times to moisten the article to

be ironed.

ENGLISH8

Shot of steam

A powerful shot of steam helps to remove very stubborn creases.

The shot-of-steam function only works at temperature settings

between 2and MAX.

C1Press and release the shot-of-steam button.

Vertical shot of steam (GC2650/2640/2620/2560/2530/2520)

C1The shot-of-steam function can also be used when you are

holding the iron in vertical position.This is useful for removing

creases from hanging clothes, curtains, etc.

Never direct the steam at people.

Drip stop (GC2650/GC2560 only)

This iron is equipped with a drip stop function: the iron automatically

stops producing steam when the temperature is too low to prevent

water from dripping out of the soleplate.When this happens you will

hear a click.

Automatic shut-off (GC2560 only)

The electronic shut-off function automatically switches the heating

element off if the iron has not been moved for a while.

C◗The automatic shut-off light starts blinking to indicate that the

heating element has been switched off.

To let the iron heat up again, pick the iron up or move it slightly.The

automatic shut-off light goes out.

1If the temperature light goes on, wait for it to go out before

you start ironing.

2If the temperature light does not go on, the iron is ready for

use.

ENGLISH 9

Cleaning and maintenance

Double-Active Calc System

C◗The Anti-Calc tablet prevents scale from clogging the steam vents.

The tablet is constantly active and does not need to be replaced.

◗The Calc-Clean function removes the scale particles.

Calc-Clean function

Use the Calc-Clean function once every two weeks. If the water in

your area is very hard (i.e. when flakes come out of the soleplate

during ironing), the Calc-Clean function should be used more

frequently.

1Set the steam control to position O.

2Fill the water tank to the maximum level.

Do not pour vinegar or other descaling agents into the water tank..

C3Set the temperature dial to MAX.

4Put the plug in the wall socket.

5Unplug the iron when the temperature light has gone out.

6Hold the iron over the sink and set the steam control to the

Calc-Clean position (1).The steam control will spring up

slightly.

C7Pull the steam control upwards and remove it.

C8Hold the iron over the sink and move it to and fro.

BSteam and boiling water will come out of the soleplate. Impurities and

scale (if any) will be flushed out.

ENGLISH10
