ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Steam Iron Mistral
GC 2015
PRODUCT INFORMATION
Features
- Colour white/peach
- Ceralon soleplate
- Tank capacity (200 ml)
- Steam rate (25 g/min)
- Calc clean
- Shot of steam (45 g/min)
- Vertical steam
- Integrated cord winder with clip
- Length of cord : 1.9 m.
4322 277 00631
01/05
This product meets the requirements regarding
interference suppression on radio andTV.
TECHNICAL INFORMATION
Voltage : 120 V, 220-240 V.
Frequency : 50-60 Hz
Power consumption : 1300 W, 1600 W.
Water advice : Suitable for tap water use. However if
the tap water in your area is very hard,
we advise you to mix it with a equal
portion of distilled water or to use
distilled water only.
Soleplate
Ceralon, the name indicates the strong combination of a non-stick
coating (“lon”) blended with ceramic (“Cera”) particles. The
soleplate is coated with Ceralon material which is smooth gliding,
high scratch resistance and good durability advantage over the non
stick coatings.
Calc clean
The integrated Calc clean function ensure a longer lifetime using
normal tap water by removing the scale out of the steam chamber.
Shot of steam (S.O.S)
The shot of steam knob releases a powerful shot of steam boost
(up to 45 g/min), created by a separate shot of steam area. This
helps getting rid of stubborn wrinkles easily.
Vertical Steam
The same shot of steam button can be used in a vertical position
for curtains or hanging garments.
DISASSEMBLY ADVICE + PARTS LIST
BACKPLATE 1
SWIVEL 2
CORDSET 3
Remove Screw A 1x
Remove Backplate 1
Remove Screw B 2x
(cord clamp)
OPERATION KNOB 4
DOSING UNIT 5
INLAY 6
PUMP 8
NOZZLE 9
Remove Screw A 1x
Remove Backplate 1
Remove Screw B 2x
(cord clamp)
Remove Cord set 3
Remove Dosing unit 5
Remove Screw D 1x
Remove Operation knob 4
Remove Screw C 2x
Remove Inlay 6
DIAL 10
LIGHT CONDUIT 11
TANK SET 12
LIGHT 13
Remove Screw A 1x
Remove Backplate 1
Remove Screw B 2x
(cord clamp)
Remove Cord set 3
Remove Dosing unit 5
Remove Screw D 1x
Remove Operation knob 4
Remove Screw C 2x
Remove Inlay 6
Remove Dial 10
Remove Screw E 1x
COVER 14
THERMOSTAT BUSH 15
SOLEPLATE 16
SEALING SET 7
Remove Screw A 1x
Remove Backplate 1
Remove Screw B 2x
(cord clamp)
Remove Cord set 3
Remove Dosing unit 5
Remove Screw D 1x
Remove Operation knob 4
Remove Screw C 2x
Remove Inlay 6
Remove Dial 10
Remove Screw E 1x
Remove Tank set 12
Remove Screw F 3x
Romove Cover 14
RESISTOR
LAMP
FUSE
N
L
E
HEATING
UNIT
INPUT
THERMOSTAT
1. Backplate 4822 441 12291
2. Swivel 4822 325 10229
3. Cordset EU 4239 000 08070
4. Operation knob 9965 000 10616
5. Dosing unit 4239 021 07860
6. Inlay 4239 021 08080
7. Sealing set. 102,103 4822 310 11269
8. Pump 4822 360 10416
9. Nozzle 4822 479 20254
10. Dial (prtd Ita/Spa) 4239 021 09620
Dial (Ger/Swe) 4239 021 09570
Dial (Fre/Du) 4239 021 08200
11. Light conduit 4239 025 99590
12. Tank set (printed) 101 4239 021 08030
13. Lamp 4239 020 90650
14. Cover 4239 026 01710
15. Thermostat bush 4822 532 61258
16. Soleplate + thermostat 4239 021 08340
Pos Description Consist of Service code
EXPLODED VIEW
C
D
E
F
F
F
B
B
C
A
3
2
1
4
5
8
9
6
101
11
10
13
14
15
12
102
103
16
Screws : d x l
A,B,C,D,E 3.5 x 16.5 mm
F4.0 x 9.0 mm (with washer)
G4.0 x 9.0 mm
IMPORTANT + ADJUSTMENTS AND CONTROLS
IMPORTANT
Due to high voltage of the iron, only the specified cordsets must be used.
NOTES :
1) For standardisation reasons :
Dial : With English/Spanish text only.
Soleplate : Ceralon soleplate will be provided for all models.
Type plate : No info. about the typenumber and voltage has been stamped onto the typeplate.
When replacing the typeplate, engrave at least the typenumber onto the typeplate with a sharp object.
2) Parts with numbers from 100 and higher, cannot be ordered seperately.
3) After the product has been repaired, it should function properly and has to meet the safety requirements and
legal regulations as laid down and officially established at this moment.
ADJUSTMENTS AND CONTROLS
Thermostat
Thermostat, fitted to the soleplate 16 has already been adjusted by the supplier and secured by glue.To avoid mal-function of the
iron, NEVER re-adjust the thermostat.
NOTE : the thermostat can only be ordered together with the soleplate assembly 16.
