Philips HI282/22 Manuel utilisateur

Mistral Elan

HI 272/74/82/84/92/94

English Page 4

• Keep pages 3 and 50 open when reading these operating instructions.

Deutsch Seite 12

• Schlagen Sie beim Lesen der Gebrauchsanweisung Seiten 3 und 50 auf.

Dansk Side 20

• Hold side 3 og side 50 opslået mens De læser brugsanvisningen.

Norsk Side 28

• Slå opp på side 3 og 50 før De leser videre.

Svenska Sid 35

• Ha sidan 3 och 50 utvikt när ni läser bruksanvisningen.

Suomi Sivu 43

• Pidä sivut 3 ja 50 auki samalla kun luet käyttöohjetta.

MAX

A C B

FHIK

DNL

HI 292

HI 294

Important

• Please read these instructions in conjunction with the

illustrations before using the appliance.

• Before using for the first time, check if the voltage rating on

the typeplate corresponds to the mains voltage in your home.

• Never use the appliance if it is damaged in any way.

• Take care that children cannot touch the iron when hot and

that they cannot pull the mains cord.

• The ejected steam is hot and therefore hazardous. Never direct

the steam towards people.

• Remove the plug from the socket before filling the iron with

water or pouring out the remaining water after use.

• Never immerse the iron in water.

• When you have finished ironing, and also when leaving the

iron even for a short while:

- set the steam control to position O;

- put the iron in upright position;

- remove the mains plug from the wall socket.

Note: The soleplate may become seriously corroded if the iron

is stored with the soleplate facing downwards.

• Some parts of the iron have been slightly greased and as a

result the iron may slightly smoke when switched on for the

first time. After a short while, however, this will cease.

• Before using the first time remove any sticker or protective foil

from the soleplate. Clean the soleplate with a soft cloth.

• Do not put vinegar or other descaling agents into the water

reservoir.

• Do not use chemically descaled water.

• The cordset should not be allowed to touch the soleplate when

it is hot.

• If the mains cord of this appliance is damaged, it must be

replaced by the original type only.

Please apply to your Philips dealer or to the Philips

organisation in your country for replacement.

English

General description (fig. 1)

ATemperature control (rotate)

BSteam control (rotate)

O= no steam

N= normal steam

H= extra steam

1SELF CLEAN = self-cleaning / descaling, removing steam control

needle

CSpray button T (press)

DShot of Steam button s (press)

ESpray

FFilling aperture

GSoleplate

HWater reservoir with level indication

ITemperature pilot light (amber)

JType plate

KCord winder

LCord clip

MMeasuring beaker

N"Auto Stop" pilot light (red)

(with types HI 292 and HI 294 only)

Filling with water (for steam-ironing and spraying)

• Please fill this iron with normal tap water before using for the first time.

• For refilling, you can also use tapwater. However, if the water is very

hard (hardness higher than 17 °DH / 211⁄4°Clarke), it is advisable to

use distilled water.

- Remove the mains plug from the wall socket before filling the iron.

Set the steam control to position O (= no steam).

- Stand the iron on its end and pour water into the filling aperture (fig. 2).

Use the measuring beaker with spout for this purpose.

Do not fill higher than marking "MAX" on the water reservoir.

(Maximum filling = approx. 200 ml.)

Ironing temperature

• Always check first to see whether a label with ironing instructions is

attached to the article to be ironed. (See table.)

Follow these ironing instructions in all cases.

• If ironing instructions are missing but you do know the kind of fabric,

then see the table.

• The table is valid for the materials only and is not applicable to any

applied finish, gloss etc.

Textile to which some kind of finish has been applied (gloss, wrinkle,

relief etc.) can best be ironed at lower temperatures.

• Sort the laundry out according to ironing temperature first: wool with

wool, cotton with cotton, etc.

Table

Note.: Zon the label means:

"This article cannot be ironed!"

Instructions

on label

Steam

control

No steam

Normal steam

Extra steam

Textile

Synthetic fibres

(e.g. acetate, acryl,

viscose, polyamide

(nylon),

polyester.

Silk

Wool

Cotton

Linen

Temperature

control

MIN

MAX

• The iron heats up quicker than it cools down. Therefore, start ironing

the articles requiring the lowest temperature such as those made of

synthetic fibres.

• If the fabric consists of various kinds of fibres, you must always select

the lowest ironing temperature of the composition of those fibres.

(E.g. an article consisting of "60% polyester and 40% cotton" should be

ironed at the temperature indicated for polyester (1) and without

steam.)

If you do not know what kind(s) of fabric(s) the article has been made

of, find a spot which will be invisible when wearing or using the article.

Try out the ironing temperature which is most suitable there. (Start at a

relatively low temperature.)

• Pure woollen fabrics (100% wool) may be pressed with the iron set to a

steam position. Preferably set the steam control to maximum position

and use a dry pressing cloth.

When steam-ironing woollen fabrics, shining of the fabric may occur.

This can be prevented by turning the article inside out and ironing the

reverse side.

• Velvet and other textures which rapidly acquire shiny spots should be

ironed in one direction only (with the nap) applying light pressure.

Always keep the iron moving.

• Iron the reverse side of synthetic materials and silk to prevent shining

spots. Do not use the spray to prevent stains.

Setting the temperature

- Stand the iron on its end.

- Set the temperature control to the correct ironing temperature as

indicated in the ironing instructions or in the table. (See fig. 3.)

- Insert the mains plug into the wall socket.

- After the amber temperature pilot light has gone out and come on again

you may start ironing. The pilot light will go out from time to time during

ironing.

If you set the temperature control to a lower setting after ironing at a

high temperature, do not begin again before the pilot light comes on.

Spraying

At any temperature by pushing on the spray button T(C) a couple of

times the laundry can be damped down (fig. 4).

Ensure that there is enough water in the water reservoir.

Shot of Steam

By pressing button s(D) an intense "shot" of steam is emitted from the

soleplate (fig. 5).

This can be very useful e.g. when removing stubborn creases.

The "shot" of steam facility can be used only while ironing with high

ironing temperature (positions ranging from 2to 3).

You can apply max. five sequential shots of steam (with steam of good

quality).

Vertical position

“Shot of steam” can also be applied when holding the iron in a vertical

position. This is useful for removing creases from hanging clothes,

curtains, etc.

- Ensure that the water reservoir is filled-up completely.

- Set the temperature control to position 3 MAX.

- Wait a little while for the amber temperature pilot light to go out and to

come on again.

- Direct the soleplate towards the hanging clothes, curtains, etc. and

press button s(D).

• As soon as the steam output decreases, hold your iron horizontally and

wait a few seconds before using “Shot of steam” again.

Steam-ironing

• As indicated on the temperature control (A) and the table, steam-

ironing is only possible at higher ironing temperatures:

2or 3for moderate steam

3for maximum steam.

• With conventional steam irons, water may leak from the soleplate if a

too low temperature has been selected. This will then cause stains.

Your new steam iron (types HI 282, HI 284, HI 292 and HI 294 only)

has the "Drip Stop" feature. If a too low temperature has been

selected, your iron will automatically stop steaming to prevent water

leaking from the sole plate.

When this happens, you can hear "Click". Set the temperature control

to the advised position. Steaming will recommence as soon as the

appropriate temperature has been reached.

• Ensure that there is enough water in the water reservoir.

- Stand the iron on its rear side.

- Set the temperature control at the required position within the "steam

area" (2or 3) (fig. 6).

- Insert the mains plug into the wall socket.

- Wait a little while for the amber temperature pilot light to go out and to

come on again.

- Set the steam control to the required position (fig. 3).

Ironing without steam

For ironing without steam proceed as described for steam-ironing.

However, the steam control should remain in position O (= no steam).

“Auto stop” (automatic safety shut-off)

(types HI 292 and HI 294 only)

If the iron is left in a motionless horizontal position for more than

30 seconds, or in a vertical position for more than 8 minutes, the red

“Auto Stop” pilot light (N) will start blinking and the heating element will

switch off automatically.

When picking up the iron again, the red light will go out and the amber

temperature pilot light (I) will come on. This indicates that the iron has

begun heating up again.

When the amber indicator light has gone out you can recommence

ironing.

Maintenance

• It is important to apply "self-cleaning" at least every two weeks to

remove scale etc.

The harder the water, the more the iron should be self- cleaned.

- Fill the water reservoir half-full with water.

- Stand the iron in upright position.

- Set the temperature control to MAX.

- Insert the mains plug into the wall socket.

- Allow the iron to heat up until the amber temperature pilot light first

goes out and then comes on again.

- Remove the plug from the wall socket.

- Hold the iron horizontally over the sink.

- Set the steam control to position 1SELF CLEAN. Turn the steam

control far enough, so that the dot 1on the steam control meets the

mark ▲on the iron. The steam control will then spring up slightly.

- Pull the steam control up until it stops (fig. 7).

- Boiling water and steam will now come out of the holes in the soleplate.

Impurities and scale (if any) are washed away with it (fig. 8).

- Move the iron forwards and backwards while this happens.

- You can pull the steam control further upwards to remove the steam

control needle (fig. 9). It is then possible to remove any scale from the

needle. For this purpose you may use vinegar.

However, avoid bending or damaging the steam control needle!

- Replace the steam control needle. Insert the point of the needle exactly

in the centre of the aperture and fit the small notch at the side into the

spacing (fig. 10).

- Depress the steam control (fig. 11).

- Set the steam control to position O.

- Stand the iron upright on its end.

- Set the temperature control to MAX.

- Insert the mains plug into the wall socket and let the iron heat up again.

- Move the iron over a (preferably) old piece of cloth.

The remainder of the water inside the steam chamber will now vaporize

and leave the iron through the soleplate.

Do not put vinegar or other descaling agents into the water

reservoir.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Philips Fer

Philips

Philips Perfect Care Performer GC8723 Manuel utilisateur

Philips

Philips EasyCare GC3260 Manuel utilisateur

Philips

Philips Azur Performer GC3800 Series Manuel utilisateur

Philips

Philips Azur 4200 GC4218 Manuel utilisateur

Philips

Philips PerfectCare Expert GC9500 Series Manuel utilisateur

Philips

Philips GC9500 Series Manuel utilisateur

Philips

Philips PerfectCare Elite GC9600 Series Manuel utilisateur

Philips

Philips GC9642 Manuel utilisateur

Philips

Philips GC7035/26 Manuel utilisateur

Philips

Philips Azur Advanced GC4930 Series Manuel utilisateur

Philips

Philips GC363 Manuel utilisateur

Philips

Philips GC4880 series Manuel utilisateur

Philips

Philips GC4516 Manuel utilisateur

Philips

Philips PerfectCare Elite Plus GC9681/81 Manuel utilisateur

Philips

Philips GC8030/08 Manuel utilisateur

Philips

Philips GC3388 Manuel utilisateur

Philips

Philips GC9600 PerfectCare Elite Plus Manuel utilisateur

Philips

Philips GC9410 Manuel utilisateur

Philips

Philips EasyCare GC8350 Manuel utilisateur

Philips

Philips Diva GC149 Manuel utilisateur

Philips

Philips GC1900 Manuel utilisateur

Philips

Philips GC9642 Manuel utilisateur

Philips

Philips SpeedCare GC6605/20 Manuel utilisateur

Philips

Philips EasySpeed Plus GC2078 series Manuel utilisateur

Manuels Fer populaires d'autres marques

Clatronic

Clatronic DB 3703 Manuel utilisateur

TEFAL

TEFAL FV4093Z0 Manuel utilisateur

Gorenje

Gorenje SIH 2200 BS Manuel utilisateur

Bosch

Bosch 2 Series Manuel utilisateur

Riffel

Riffel Catena KB-819 Manuel utilisateur

Texi

Texi Hestia Manuel utilisateur

Maxwell

Maxwell MW-3010 Manuel utilisateur

TREVIDEA

TREVIDEA Girmi ST60 Manuel utilisateur

Primula

Primula Vapormat Manuel utilisateur

Magio

Magio MG-541 Manuel utilisateur

Scarlett

Scarlett SC-1334S Manuel utilisateur

Bosch

Bosch Sensixx B22L Manuel utilisateur

Vitek

Vitek VT-1247 VT Manuel utilisateur

Cleanmaxx

Cleanmaxx 3397 Manuel utilisateur

dyras

dyras ESI-2400AC Manuel utilisateur

GE 169061 Manuel utilisateur

Gorenje

Gorenje SIH 2200 GC Manuel utilisateur

AEG

AEG DBS 5591 Manuel utilisateur
