Philips RQ1087/21 Manuel utilisateur

1 2 3 4

67 8 9

10 11 12 13

14 15 16 17

18 19 20 21

RQ1095, RQ1087, RQ1085, RQ1077, RQ1075

ENGLISH 6

 22

 40

 56

 71

 87

 103

 121

 137

 152

 168

 185

 203

 219

 234

 250

Introduction

Thank you for buying this Philips shaver. Please read this user manual, as it

contains information about the wonderful features of this shaver as well

as some tips to make shaving easier and more enjoyable.

Important

Read this user manual carefully before you use the shaver, the Jet Clean

System and the Power Pod. Save the user manual for future reference.

Danger

Make sure the adapter does not get wet (Fig. 1).

Warning

Be careful with hot water. Always check if the water is not too hot, to

prevent your hands from getting burnt.

The adapter contains a transformer. Do not cut off the adapter to

replace it with another plug, as this causes a hazardous situation.

These appliances are not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliances by a

person responsible for their safety.

Children should be supervised to ensure that they do not play with

the appliances.

Caution

Do not use the shaver, the Jet Clean System, the Power Pod or the

adapter if it is damaged.

Charge and store the shaver at a temperature between 5°C and

35°C.

Always put the protection cap on the shaver to protect the shaving

heads when you are travelling.

Never use scouring pads, abrasive cleaning agents or aggressive liquids

such as petrol or acetone to clean the appliance.

Only use the adapter supplied.

If the adapter is damaged, always have it replaced with one of the

original type in order to avoid a hazard.

ENGLISH6

Only use the Jet Clean System with the original HQ200 cleaning uid.

Never immerse the Jet Clean System in water nor rinse it under the

tap. (Fig. 2)

Use and store the Jet Clean System at a temperature between 5°C

and 35°C.

Always place the Jet Clean System on a stable, level and horizontal

surface to prevent leakage.

Empty the cleaning chamber and clean it thoroughly by rinsing it with

hot tap water every 15 days.

Always place the Jet Clean System on a uid-resistant surface.

The Jet Clean System thoroughly cleans but does not disinfect your

shaver, therefore do not share the shaver with others.

The cleaning chamber of the Jet Clean System is not dishwasher-

proof.

When the Jet Clean System is ready for use, do not move it to

prevent leakage of cleaning uid.

Never immerse the Power Pod in water, nor rinse it under the

tap (Fig. 3).

Compliance with standards

The shaver complies with the internationally approved IEC safety

regulations and can be safely cleaned under the tap (Fig. 4).

These Philips appliances comply with all standards regarding

electromagnetic elds (EMF). If handled properly and according to the

instructions in this user manual, the appliances are safe to use based

on scientic evidence available today.

General

The adapter transforms 100-240 volts to a safe low voltage of less

than 24 volts.

Noiselevel: Lc= 64 dB(A)

Overview (Fig. 5)

AProtection cap

BShaving unit

CTrimmer

DTrimmer on/off slide

ENGLISH 7

EShaver (RQ1090/RQ1062/RQ1060/RQ1052/RQ1050)

FShaver on/off button

GDisplay

HShaver holder

IJet Clean System (RQ1005/RQ1000)

JJet Clean System on/off button

KCleaning symbol

LDrying symbol

M’Cleaning chamber empty’ symbol

NCleaning chamber

OPower Pod

PCleaning brush

QAdapter

RSmall plug



Before you use the shaver for the rst time, remove the protective foil

from the display.

The ve shaver types (RQ1090, RQ1062, RQ1060, RQ1052 and

RQ1050) have different displays, which are shown in the gures below.

RQ1090 (Fig. 6)

RQ1062/RQ1060 (Fig. 7)

RQ1052/RQ1050 (Fig. 8)

Charging

Charging takes approx. 1 hour.

When you place the shaver in the Jet Clean System or in the Power

Pod, the display automatically switches off after approx. 5 hours.

RQ1090

When the shaver is charging, the minutes indication and the plug

symbol ash (Fig. 9).

The shaving minutes increase until the shaver is fully charged.

RQ1062/RQ1060

When the shaver is charging, the plug symbol ashes. (Fig. 10)

ENGLISH8

First the arrowheads of the bottom charge level ash, then the

arrowheads of the second level ash, and so on until the shaver is

fully charged.

RQ1052/RQ1050

When the shaver is charging, the battery symbol ashes

blue. (Fig. 11)



RQ1090

When the battery is fully charged, the minutes indication is visible on

the display and the plug symbol disappears from the display. (Fig. 12)

RQ1062/RQ1060

When the battery is fully charged, all arrowheads and all charge level

lights light up blue continuously and the plug symbol disappears from

the display (Fig. 13).

When you remove the shaver from the Jet Clean System or the

Power Pod, the arrowheads of the top charge level light up blue to

indicate that the battery is full (Fig. 14).

RQ1052/RQ1050

When the battery is fully charged, the battery symbol lights up blue c

ontinuously. (Fig. 15)



RQ1090

When the battery is almost empty (when there are only 5 or fewer

shaving minutes left), the minutes indication and the plug symbol start

to ash (Fig. 9).

When you switch off the shaver, the shaving minutes and the plug

symbol continue to ash for a few more seconds. You hear a beep

when there are no minutes left.

RQ1062/RQ1060

When the battery is almost empty (when there are only 5 or fewer

shaving minutes left), the battery symbol ashes red and the

arrowheads of the bottom charge level ash blue. (Fig. 16)

ENGLISH 9

When you switch off the shaver, the battery symbol and the

arrowheads of the bottom charge level continue to ash for a few

seconds.

RQ1052/RQ1050

When the battery is almost empty (when there are only 5 or fewer

shaving minutes left), the battery symbol lights up red. (Fig. 11)

When you switch off the shaver, the battery symbol starts to ash for

a few seconds.



RQ1090

The remaining battery capacity is indicated by the number of shaving

minutes shown on the display. (Fig. 12)

RQ1062/RQ1060

The remaining battery capacity is indicated by the ashing

arrowheads of a particular charge level (Fig. 14)

Clean shaver

For optimal shaving performance, we advise you to clean the shaver after

every use.

The tap symbol ashes to remind you to clean the shaver (Fig. 17).

Note:The displays of types RQ1062, RQ1060, RQ1052 and RQ1050 look

different but show the same indication.

Replace shaving unit

For maximum shaving performance, we advise you to replace the shaving

unit every two years.

To remind you to replace the shaving unit, the shaving unit symbol

ashes (all types) and you hear a beep when you switch off the

shaver (RQ1090 only).This happens at the end of 7 successive shaves

to remind you to replace the shaving unit. (Fig. 18)

Note:The displays of types RQ1062, RQ1060, RQ1052 and RQ1050 look

different but show the same indication.

ENGLISH10



You can lock the shaver when you are going to travel. The travel lock

prevents the shaver from being switched on by accident.



1 Press the on/off button for 3 seconds to enter the travel lock

mode (Fig. 19).

The lock symbol appears on the display (all types) and you hear a

beep (RQ1090 only) to indicate that the travel lock has been

activated.

Note:The displays of types RQ1062, RQ1060, RQ1052 and RQ1050 look

different but show the same indication.



1 Press the on/off button for 3 seconds.

The motor starts running to indicate that the travel lock has been

deactivated.

The shaver is now ready for use again.

Note:When you place the shaver in the plugged-in Power Pod or Jet Clean

System, the travel lock is automatically deactivated.



If the shaving heads are blocked, the shaving unit symbol and the tap

symbol with exclamation mark ash. In this case, the motor cannot

run because the shaving heads are soiled or damaged. (Fig. 20)

Note:The displays of types RQ1062, RQ1060, RQ1052 and RQ1050 look

different but show the same indication.

When this happens, you have to clean the shaving unit or replace it.

The shaving unit symbol and the tap symbol with exclamation mark

continue to ash until you unblock the shaving heads.

Charging

Charging takes approx. 1 hour.

ENGLISH 11

A fully charged shaver has a shaving time of up to 65 minutes, which is

enough for approx. 21 shaves.

The actual shaving time is calculated by the shaver. If you have a heavy

beard, the shaving time may be less than 65 minutes.The shaving time

may also vary over time, depending on your shaving behaviour and beard

type.



After the shaver has charged for 5 minutes, it contains enough energy for

one shave.

Charging in the Power Pod

1 Put the small plug in the Power Pod (Fig. 21).

2 Put the adapter in the wall socket.

3 Pull at the top of the lid (1) and remove it (2) (Fig. 22).

4 First insert the top of the shaver into the Power Pod (1) and then

press the bottom part into the Power Pod (2) (Fig. 23).

Note:The shaver cannot be placed in the Power Pod when the protection cap

is on the shaving unit.

The display shows that the shaver is charging (see chapter ‘The

display’).



1 Put the small plug in the Jet Clean System.

2 Put the adapter in the wall socket.

3 Place the shaver upside down in the holder with the display

pointing towards the front of the Jet Clean System (Fig. 24).

Note: RQ1090,RQ1062,RQ1060 only: when you turn the shaver upside

down, the indications on the display are also turned upside down so you can

still see the remaining battery capacity.

4 Press the shaver tightly into the holder to lock it into place (Fig. 25).

ENGLISH12

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Philips Rasoir électrique

Philips

Philips S9041/12 Manuel utilisateur

Philips

Philips 6955XL/18 Manuel utilisateur

Philips

Philips SP9860/14 Manuel utilisateur

Philips

Philips MG1100 Manuel utilisateur

Philips

Philips NORELCO S7371 Manuel utilisateur

Philips

Philips RQ1100 Series Manuel utilisateur

Philips

Philips QP2526 Manuel utilisateur

Philips

Philips HQ6423/16 Manuel utilisateur

Philips

Philips HQ8850/18 Manuel utilisateur

Philips

Philips HQ5802/16 Manuel utilisateur

Philips

Philips HQ663 Manuel utilisateur

Philips

Philips Philishave HQ 6715 Manuel utilisateur

Philips

Philips Norelco Arcitec 1050X Manuel utilisateur

Philips

Philips PT919 Manuel utilisateur

Philips

Philips Ladyshave softselect HP6328/01 Manuel utilisateur

Philips

Philips HQ55 Manuel utilisateur

Philips

Philips HQ5620/99 Manuel utilisateur

Philips

Philips SENSOTEC HQ8893 Manuel utilisateur

Philips

Philips AXE XA513 Manuel de la liste des pièces

Philips

Philips S3520 Manuel utilisateur

Philips

Philips Luxury A6 BW Manuel utilisateur

Philips

Philips HQ7820/16 Manuel utilisateur

Philips

Philips NORELCO BT7225 Manuel utilisateur

Philips

Philips RQ1061 Manuel utilisateur

Manuels Rasoir électrique populaires d'autres marques

Norelco

Norelco Quadra 7610X Manuel utilisateur

Braun

Braun WaterFlex WF2s Manuel utilisateur

Daga

Daga MT-400 Manuel

Remington

Remington BHT100 Manuel utilisateur

Kompernass

Kompernass KH 5537 Manuel utilisateur

Remington

Remington BHT6100 Manuel utilisateur

MIA

MIA Aqua Body Manuel utilisateur

Matheo

Matheo MLR 15 Manuel utilisateur

CTC Union

CTC Union Clatronic HSM 3441 NE Manuel utilisateur

Remington

Remington XR7000 Manuel utilisateur

Eldom

Eldom G47 Manuel utilisateur

Braun

Braun silk-epil 5 Manuel utilisateur

SEVERIN

SEVERIN SÉRIE E700 0533 Guide de l'utilisateur

Remington

Remington PR1355 Manuel utilisateur

Aurora

Aurora AU 3543 Manuel utilisateur

Braun

Braun InterFace 3614 Manuel utilisateur

Wahl

Wahl 8061 5-STAR Manuel utilisateur

Norelco

Norelco 4404LC Manuel utilisateur
