Philips QuadraAction 7864XL Manuel utilisateur

Rechargeable

Cord/Cordless Razor

7866XL

7865XL

7864XL

ENGLISH 4

ESPAÑOL 20

IMPORTANT SAFETY

INSTRUCTIONS

When using an electric razor,basic precautions should

always be followed,including the following:

Read all instructions before using this appliance.

DANGER

To reduce the risk of electric shock:

1 Do not reach for a razor that has fallen into water.

Unplug immediately.

2 Do not use razor corded while bathing or in a

shower.

3 Do not place or store razor while plugged in where it

can fall or be pulled into a tub or sink.Do not place

or drop into water or other liquid while plugged in.

4 Always unplug this razor from the electrical outlet

immediately after use, except when razor is

(re)charging.

5 Unplug this razor before cleaning.

6 When discarding razor, unplug razor and remove

rechargeable batteries.See Battery Removal

instructions.

WARNING

To reduce the risk of burns, fire, electric shock, or

injury to persons:

1 Close supervision is necessary when this razor is used

by, on,or near children or invalids.

2 Use this razor for its intended household use as

described in this manual.Do not use attachments not

recommended by Philips Electronics North America

Corporation.

3 Never operate this razor if it has a damaged cord or

charging plug,if it is not working properly,if it has

been dropped or damaged,or dropped into water

while plugged in.Return the razor to an Authorized

Norelco Service Location for examination and repair.

4 Keep the cord and charging plug away from heated

surfaces.

5 Never drop or insert any object into any opening.

6 Do not charge or plug in razor outdoors or operate

where aerosol (spray) products are being used or

where oxygen is being administered.

7 Do not use this razor with a damaged or broken

comb,as facial injury may occur.

8 Always attach plug to razor first, then to outlet.Be

certain that plug is inserted firmly into razor,up to

mark indicated on plug.To disconnect,turn razor off

then remove charging plug from outlet.

9 Never put the razor in direct sunlight or store in a

pouch at a temperature above 140ºF.

10 Razor can be rinsed under running tap water.Do not

submerge razor in water.

11 To prevent possible damage to the cord, do not wrap

cord around the razor.

SAVETHESE

INSTRUCTIONS

IMPORTANT

Your razor contains NICKEL-CADMIUM

RECHARGEABLE BATTERIES. See Battery Removal

instruction sheet for battery disposal information.

60 - DAY MONEY-BACK GUARANTEE

To enjoy the closest and most comfortable shave from your new Norelco Men’s

Razor, the razor should be used exclusivelyfor 3 weeks.This allows your hair

and skin enough time to adapt to the Norelco Shaving System. If, after that

period of time, you are not fully satisfied with your Norelco Men’s Razor, send

the product back and we’ll refund you the full purchase price.

The razor must be shipped prepaid by insured mail, insurance prepaid,

and have the sales slip, indicating purchase price and the date of

purchase, enclosed. The razor must be postmarked no later than 60 days

after the date of purchase. Norelco reserves the right to verify the purchase

price of the razor and limit refunds not to exceed suggested retail price.

Send dated sales slip, your complete name and address as indicated

below, and the razor, prepaid to:

Norelco Consumer Products Company

A Division of Philips Electronics North America Corporation

450 North Medinah Rd., Dock 16

Roselle, IL 60172-2329

Please allow 4-6 weeks for delivery of check. (Please Print)

Name_________________________________________________________

Address________________________________________________________

City__________________________________________________________

State_____Zip__________________________________________________

Daytime Telephone No. (____)____________________________________

Email Address __________________________________________________

REASON FOR RETURNING:______________________________________

______________________________________________________________

AREA CODE

TABLE OF CONTENTS

FEATURES 8-9

LED BATTERY CHARGE METER 10

CHARGING 10-11

PUT ITTOTHETEST &

SHAVINGTIPS 11-12

HOWTO SHAVEWITH AN

ELECTRIC RAZOR 12

TRIMMING 12-13

CLEANING 13-16

ASSISTANCE 17

ACCESSORIES 17

BATTERY REMOVAL 17

WARRANTY 18

100

FEATURES

QuadraAction

Shaving System

Razor HeadAssembly

Protective Razor Head Cap

Individually Floating Heads

Razor Head Release Button

• Hair Chamber captures

shaven hair

Electronic ON/OFF Button

LED Battery Charge Meter

• Indicates the amount

of charge remaining

in batteries

Pop-UpTrimmer

Automatic

WorldwideVoltage

100V to 240VAC

Cleaning Brush

Deluxe Pouch

Rechargeable - Initial 4 hour

Full Charge for up to

45 minutes of cordless

shave time

1-Hour Quick Charge

Cord/Cordless -To shave

with or without a cord

Full 2-YearWarranty

60-Day Money-Back

Guarantee

How the Norelco Lift and Cut®Patented

Shaving System Makes Close Comfortable:

Groove channels beard

closer to cutting system Lifter raises hair Slots to cut long hairs Holes to cut short hairs

even closer

100

LED BATTERY CHARGE METER

The Meter provides the following information:

LED Battery Charge Meter

The number (percentage) on the display indicates

approximately how much power is left in the batteries.

Low Battery Indicator

If the batteries run low,the“20” Section on the display

lights up red.When you turn the razor OFF,the red light

will blink for approximately 4 seconds.

Charging Indicator

When you charge razor, the “20” Section on the display

turns red.After approximately 3 minutes,it will then turn

green and blink. As charging continues,more and more

sections of the display meter will briefly blink green and

light up to indicate what level (percentage) of the

batteries have been charged.

Full Charge Indicator

When the batteries have been fully charged,all the

“blocks” on the display will light up green.

CHARGING

Battery performance is best if you recharge only when

the batteries are (almost) completely empty.

Charging or recharging at temperatures below 40ºF or

higher than 95ºF adversely affects lifetime of batteries.

Continuously recharging or continuously using as a

corded razor will reduce life of batteries.

You may also shave using the charging plug provided.This

razor will not recharge while being used corded.

Recharge only when block“20” lights up red.
