Philips MG5730 Manuel utilisateur

MG5720

MG5730

MG5735

MG5740

MG5730

MG5735

MG5740

3-7MM

1MM 2MM

MG5730

MG5735

MG5740 MG5740

3MM 5MM

12MM 16MM

9MM

4 5 6

7 8 9

10 11 12

13 14

empty page before TOC

English 6

Bahasa Indonesia 20

Bahasa Melayu 35

Português do Brasil 50

Tiếng Việt 65

ภาษาไทย 78

简体中文 93

繁體中文 105

한국어 117

ﺔﻴﺑﺮﻌﻟﺍ 130

ﯽﺳرﺎﻓ 143

English

Introduction

Congratulations on your purchase and welcome to

Philips! To fully benefit from the support that

Philips offers, register your product at

www.philips.com/welcome.

General description (Fig. 1)

1 Full-size hair trimmer

2 On/off slide

3 Socket for small plug

4 Precision trimmer

5 Precision shaver (MG5740, MG5735, MG5730

only)

6 Nose trimmer

7 Hair comb 3/8in. (9mm)

8 Hair comb 15/32in. (12mm)

9 Hair comb 21/32in. (16mm)

10 Stubble comb 3/64in. (1mm)

11 Stubble comb 5/64in. (2mm)

12 Adjustable comb (3-7mm)

13 Body comb 1/8in. (3mm) (MG5740, MG5735,

MG5730 only)

14 Body comb 3/16in. (5mm) (MG5740 only)

15 Supply unit

16 Small plug

17 Cleaning brush

18 Pouch

Note: The accessories supplied may vary for

different products. The box shows the accessories

that have been supplied with your appliance.

Important safety information

Read this important information carefully before

you use the appliance and its accessories and save

it for future reference. The accessories supplied

may vary for different products.

6English

Danger

- Keep the supply unit dry.

Warning

- To charge the battery, only use the detachable

supply unit (A00390) provided with the

appliance.

- The supply unit contains a transformer. Do not

cut off the supply unit to replace it with another

plug, as this causes a hazardous situation.

- This appliance can be used by children aged

from 8 years and above and persons with

reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they

have been given supervision or instruction

concerning use of the appliance in a safe way

and understand the hazards involved. Children

shall not play with the appliance. Cleaning and

user maintenance shall not be made by

children without supervision.

- Always unplug the appliance before you clean it

under the tap.

- Always check the appliance before you use it.

Do not use the appliance if it is damaged, as

this may cause injury. Always replace a

damaged part with one of the original type.

- Do not open the appliance to replace the

rechargeable battery.

English

Caution

- Never immerse the charging stand in water and

do not rinse it under the tap.

- Never immerse the appliance in water. Do not

use the appliance in the bath or shower.

- Never use water hotter than 60°C to rinse the

appliance.

- Only use this appliance for its intended purpose

as shown in the user manual.

- For hygienic reasons, the appliance should only

be used by one person.

- Do not use the supply unit in or near wall

sockets that contain an electric air freshener to

prevent irreparable damage to the supply unit.

- Never use compressed air, scouring pads,

abrasive cleaning agents or aggressive liquids

such as petrol or acetone to clean the

appliance.

Electromagnetic fields (EMF)

This Philips appliance complies with all applicable

standards and regulations regarding exposure to

electromagnetic fields.

General

- This appliance can be safely cleaned under the

tap.

- The supply unit is suitable for mains voltages

ranging from 100 to 240 volts.

- The supply unit transforms 100-240 volts to a

safe low voltage of less than 24 volts.

8English

Charging

Charging with the supply unit

When the appliance has charged for 16 hours, it

has a cordless operating time of up to 80 minutes.

1Make sure the appliance is switched off.

2Insert the small plug into the appliance and put

the supply unit in the wall socket.

3After charging, remove the supply unit from the

wall outlet and pull the small plug out of the

appliance.

Using the appliance

Note: This appliance can only be used without

cord.

Note: Switch off and clean the appliance after each

use.

Detaching and attaching cutting elements

1To detach a cutting element, push upwards

against the teeth of the cutting element and

take it off the handle.

2To attach a cutting element, insert the lug of the

cutting element into the guiding slot at the front

and push the back of the cutting element onto

the appliance ('click').

English

Detaching the precision shaver and nose

trimmer

1Place your finger on the arrow at the back of

the attachment and push it off the handle in the

direction of the arrow.

Attaching and detaching combs

1To attach any type of guard onto a cutting

element, slide the front part of the guard onto

the teeth of the cutting element. Then push

down the center of the guard with your fingers

or the palm of your hand ('click').

2To detach any type of comb from the cutting

element, carefully pull its back part off the

appliance and then slide it off the cutting

element.

Note: When trimming for the first time, start by

using the comb with the maximum trimming

length setting to familiarize yourself with the

appliance.

Switching the appliance on and off

- To switch on the appliance, push the on/off

slide upwards.

- To switch off the appliance, push the on/off

slide downwards.

Attachments for use on beard

Full-size hair trimmer

Use the full-size hair trimmer without a comb to

trim hair close to the skin (to a length of 1/32in

10 English
