Philips MG3710 Manuel utilisateur

MG3710

MG3711

MG3712

MG3720

MG3721

MG3722

MG3730

MG3731

MG3740

MG3747

MG3748

MG3757

MG3758

9MM 12MM 16MM

3-7MM

1MM 2MM 3MM 5MM

BODY 3MM

6 7 8

10 11 12

empty page before TOC

English 6

Bahasa Indonesia 19

Bahasa Melayu 33

Português do Brasil 47

Tiếng Việt 61

ภาษาไทย 74

简体中文 86

繁體中文 101

한국어 112

ﺔﻴﺑﺮﻌﻟﺍ 125

ﯽﺳرﺎﻓ 137

English

Introduction

Congratulations on your purchase and welcome to

Philips! To fully benefit from the support that

Philips offers, register your product at

www.philips.com/welcome.

General description (Fig. 1)

1 Nose trimmer (MG3710, MG3711, MG3712,

MG3721, MG3720, MG3730, MG3731, MG3740,

MG3747, MG3748, MG3757 only)

2 Precision trimmer (MG3740, MG3757 only)

3 Full-size hair trimmer

4 On/off slide

5 Socket for small plug

6 Hair comb (9mm) (MG3720, MG3721, MG3730,

MG3731, MG3740, MG3747, MG3748, MG3757

only)

7 Hair comb (12mm) (MG3730, MG3740, MG3747,

MG3757, MG3731, MG3748 only)

8 Hair comb (16mm) (MG3730, MG3740, MG3747,

MG3757, MG3731, MG3748 only)

9 Stubble comb (1mm) (MG3710, MG3711, MG3712,

MG3720, MG3721, MG3730, MG3731, MG3740,

MG3747, MG3748, MG3757 only)

10 Stubble comb (2mm) (MG3710, MG3711,

MG3720, MG3721, MG3730, MG3731, MG3740,

MG3747, MG3748, MG3757 only)

11 Stubble comb 3mm (MG3710, MG3711, MG3712,

MG3720, MG3721 only)

12 Stubble comb 5mm (MG3710, MG3711, MG3712,

MG3720, MG3721 only)

13 Adjustable comb (3-7mm) (MG3730, MG3731,

MG3740, MG3747, MG3748, MG3757 only)

14 Body comb (3mm) (MG3747, MG3748 only)

15 Supply unit

16 Small plug

17 Storage display (MG3711, MG3712, MG3721,

MG3731, MG3748 only)

6English

18 Cleaning brush

The accessories supplied may vary for different

products. The box shows the accessories that have

been supplied with your appliance.

Important safety information

Read this important information carefully before

you use the appliance and its accessories and save

it for future reference. The accessories supplied

may vary for different products.

Danger

- Keep the supply unit dry.

Warning

- To charge the battery, only use the detachable

supply unit (A00390) provided with the

appliance.

- The supply unit contains a transformer. Do not

cut off the supply unit to replace it with another

plug, as this causes a hazardous situation.

- This appliance can be used by children aged

from 8 years and above and persons with

reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they

have been given supervision or instruction

concerning use of the appliance in a safe way

and understand the hazards involved. Children

shall not play with the appliance. Cleaning and

user maintenance shall not be made by

children without supervision.

English

- Always check the appliance before you use it.

Do not use the appliance if it is damaged, as

this may cause injury. Always replace a

damaged part with one of the original type.

- Do not open the appliance to replace the

rechargeable battery.

Caution

- This appliance is not washable.Never immerse

the appliance in water and do not rinse it under

the tap.

- Only use this appliance for its intended purpose

as shown in the user manual.

- For hygienic reasons, the appliance should only

be used by one person.

- Never use compressed air, scouring pads,

abrasive cleaning agents or aggressive liquids

such as petrol or acetone to clean the

appliance.

- Do not use the supply unit in or near wall

sockets that contain an electric air freshener to

prevent irreparable damage to the supply unit.

Electromagnetic fields (EMF)

This Philips appliance complies with all applicable

standards and regulations regarding exposure to

electromagnetic fields.

General

- The supply unit is suitable for mains voltages

ranging from 100 to 240 volts.

8English

- The supply unit transforms 100-240 volts to a

safe low voltage of less than 24 volts.

Charging

When the appliance has charged for 16 hour, it has

a cordless operating time of up to 60 minutes

(MG3710, MG3711, MG3712, MG3720, MG3721,

MG3730, MG3731, MG3740) or 70 minutes (MG3757,

MG3748, MG3747).

1Make sure the appliance is switched off.

2Insert the small plug into the appliance and put

the supply unit in the wall socket.

3After charging, remove the supply unit from the

wall outlet and pull the small plug out of the

appliance.

Using the appliance

Note: Switch off and clean the appliance after each

use.

Detaching and attaching cutting elements

1To detach a cutting element, push upwards

against the teeth of the cutting element and

take it off the handle.

2To attach a cutting element, insert the lug of the

cutting element into the guiding slot at the front

and push the back of the cutting element onto

the appliance ('click').

English

Detaching the nose trimmer

1Place your finger on the arrow at the back of

the attachment and push it off the handle in the

direction of the arrow.

Attaching and detaching combs

1To attach any type of guard onto a cutting

element, slide the front part of the guard onto

the teeth of the cutting element. Then push

down the center of the guard with your fingers

or the palm of your hand ('click').

2To detach any type of comb from the cutting

element, carefully pull its back part off the

appliance and then slide it off the cutting

element.

Note: When trimming for the first time, start by

using the comb with the maximum trimming

length setting to familiarize yourself with the

appliance.

Switching the appliance on and off

To switch on the appliance, slide the on/off button

up.

To switch off the appliance, slide the on/off button

down.

Attachments for use on beard

Full-size hair trimmer

Use the full-size hair trimmer without a comb to

trim hair close to the skin (to a length of 1/32in

10 English
