Philips HQT863/00 Manuel utilisateur

Turbovac

HQT863

ENGLISH 6

DEUTSCH 13

NORSK 20

SVENSKA 27

SUOMI 34

DANSK 41

HQT863

Introduction

Dear customer, you have made the right choice!

Your new maintenance-free Philips vacuum beard trimmer combines

innovative technology and outstanding comfort of use.

The integrated vacuum mechanism absorbs cut-off hairs during use and

guarantees a clean washbasin after use.

The contour-following comb, the self-sharpening cutting element and

the adjustment ring for selecting hair lengths of 1.5 to 18 mm ensure

excellent cutting results and time-saving operation.The ergonomic

shape of the appliance allows pleasant and comfortable handling.

Your new Philips vacuum beard trimmer is excellently suited for cutting

and contouring your beard and sideburns.

General description (fig. 1)

Acomb attachment

Bdetachable cutting unit

Cflexible hair guide

Dhair-collection chamber

Efilter

Fadjustment ring (Precision Zoom Lock`)

Gon/off switch

Hcharging pilot light

Isocket for appliance plug

Jpowerplug

Kcleaning brush

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Make sure that the appliance, the powerplug and the cord do not

get wet.

◗Check if the voltage indicated on the powerplug corresponds to

the local mains voltage before you connect the appliance.

◗Only use the cord supplied with the appliance.

ENGLISH6

◗Keep the appliance out of the reach of children.

◗Charge, use and store the appliance at a temperature between

15cC and 35cC.

◗This appliance is only designed for trimming the human beard. Do

not use the appliance for any other purpose.

◗Do not use the appliance when the cutting unit is damaged or

broken, as this may cause injury.

◗If the powerplug is damaged, always have it replaced by one of the

original type in order to avoid a hazard.

Charging

This appliance does not run from the mains!

Charge the appliance fully before you start using it for the first time or

after a long period of disuse.

1Make sure the appliance is switched off before you start charging

it.

2Insert the appliance plug into the appliance and put the

powerplug in the wall socket.

◗The green pilot light goes on to indicate that the appliance is

charging (fig. 2).

◗It will take approx. 10 hours to fully charge the battery.

◗A fully charged appliance has a cordless trimming time of up to

40 minutes.

BWhen the appliance has been charged for the first time, we advise you

to use it until the battery is completely empty.

BFor a single trimming session the appliance must be charged for at

least 90 minutes.

Optimising the lifetime of the rechargeable battery

- After the appliance has been charged for the first time, use it until

the battery is completely empty.

- Do not charge the appliance for more than 24 hours.

ENGLISH 7

- Do not keep the powerplug plugged into the wall socket all the

time.

- Do not recharge the appliance between the trimming sessions.

- Discharge the battery completely twice a year by letting the motor

run until it stops.Then fully recharge the battery.

- If the appliance has not been used for a long period of time, it must

be fully recharged.

Preparing for use

Always comb your beard or moustache with a fine comb before you

start trimming.

Using the appliance

Absorbing cut hairs

The suction system is activated automatically as soon as you switch the

appliance on. It absorbs cut hairs during every kind of use, i.e. trimming

with and without comb attachment and contouring.The flexible hair

guide follows the contours of the face and directs cut hairs towards the

nozzle of the vacuum mechanism.

We advise you to empty the hair-collection chamber after each

trimming session.When trimming long, dense beards it may also be

necessary to empty the hair-collection chamber during the trimming

session in order to maintain optimal suction performance (also see

chapter 'Cleaning', section 'Hair-collection chamber').

BTo ensure optimal functioning of the vacuum system, do not cut off

more than approx. 7mm of your overall beard length at a time. If you

want to cut your beard shorter, repeat the process one or more times.

Trimming with comb attachment

1Turn the adjustment ring (Precision Zoom Lock`) to the desired

trimming length setting (see table) (fig. 3).

◗The setting will appear in the window below the adjustment ring

(Precision Zoom Lock`).

ENGLISH8

If you are trimming for the first time, start with the maximum

trimming length setting (9).

2To trim in the most effective way, move the trimmer against the

direction of hair growth. Do not move the trimmer too fast.

Make smooth and gentle movements and make sure the surface

of the comb always stays in contact with the skin (fig. 4).

Trimming at the unique 'stubble look' setting

◗Use the trimmer with the comb attachment set to length setting

1.This allows you to create a 'stubble look' (fig. 5).

Trimming without comb attachment

Full beards and single hairs.

1Remove the comb attachment (fig. 6).

BNever pull at the flexible top of the comb attachment.Always pull at

the bottom part.

2Make well-controlled movements and touch the hair lightly with

the trimmer (fig. 7).

ENGLISH 9

Resulting hair length

1.5 mm

2.5 mm

4 mm

5.5 mm

7.5 mm

9.5 mm

12 mm

15 mm

18 mm

Setting

Trimming length settings

Cleaning

The appliance may only be cleaned dry.

Do not use abrasives, scourers or liquids such as alcohol, petrol or

acetone to clean the appliance.

Never use sharp or hard objects to clean the filter to avoid damaging

it.

Hair-collection chamber

1Switch the appliance off.

2Remove the hair-collection chamber and remove the hairs by

shaking or brushing them out (fig. 8).

3For extra thorough cleaning and to maintain optimal suction

performance, detach the filter.. (fig. 9).

4...and carefully clean the hair-collection chamber and the filter

with the brush supplied (fig. 10).

Appliance

1Remove the comb attachment.

2Remove the cutting unit (fig. 11).

3Clean the cutting unit and the inside of the appliance with the

brush supplied (fig. 12).

4Reattach the cutting unit and the comb attachment to the

appliance (fig. 13).

Replacement

Worn or damaged cutting units and filters should only be replaced with

original Philishave replacement parts which are available at your dealer

or at authorised Philips service centres.

ENGLISH10
