Philips HQ6889/01 Manuel utilisateur

ENGLISH 4

BAHASA MELAYU 13

BAHASA INDONESIA 23

Ti’ng ViŸt 60

HQ6889,HQ6888,HQ6885

Important

◗Only use the HQ8000/6000 powerplug

supplied to charge the appliance.

◗The powerplug transforms 110-240 volts to

12 volts.

C◗Make sure the HQ8000/6000 powerplug and

the charging stand do not get wet.

C◗The shaver runs at a safe low voltage of

12 volts.It is watertight and can be cleaned

under the tap.Do not rinse with water hotter

than 80cC.

The display

The display provides the following information:

C◗Charging

As soon as you connect the cord,the light in the

display goes on,the plug symbol appears and the

minute indication starts blinking.

C◗Batteries fully charged

When the batteries have been fully charged,the

word 'FULL' runs across the display and the light

in the display starts blinking.

C◗Remaining shaving time

The number on the display shows the remaining

shaving time in minutes.The segments indicate

how much energy there is still left in the batteries.

The shaving time of a fully charged shaver will

range from 35 to 45 minutes,depending on your

ENGLISH4

type of beard and your shaving behaviour,and is

calculated by the built-in computer.

C◗Cleaning reminder

The blinking tap symbol reminds you that the

appliance is due to be cleaned,which will be

approx.once a week in case of normal use.

C◗Batteries running low

When the batteries are running low,the plug

symbol will start blinking after you have switched

the shaver off.

When you switch the shaver on or off,the light in

the display goes on for approx.10 seconds.

The appliance has a 1-minute demonstration

program.

Press the on/off button a few seconds until all

symbols appear on the display.You can interrupt

the demonstration by pressing the on/off button.

Charging

Recharge and keep the appliance at a

temperature between 5cC and 35cC.

The powerplug is suitable for mains voltages

ranging from 110 to 240V.

You can also shave without charging by

connecting the shaver to the mains.

To extend the lifetime of the batteries,remove

the powerplug from the wall socket and pull the

appliance plug out of the shaver when the

batteries have been fully charged.

ENGLISH 5

C1Insert the appliance plug into the shaver as

far as the line on the plug.

2Put the powerplug in the wall socket.

Do not recharge the shaver in a closed pouch.

3When charging for the first time or after a

long period of disuse:leave the shaver to

charge continuously for 4 hours.

Charging normally takes approx.1 hour.

4Remove the powerplug from the socket

and pull the appliance plug out of the

shaver when the batteries have been fully

charged.

With the special Philishave Car Cord (HQ6010),

you can also charge the appliance at 12 volts (e.g.

in a car).This cord is available from your Philishave

dealer.

Shaving

1Switch the appliance on by pressing the

on/off button once.

C2Move the shaving heads quickly over your

skin,making both straight and circular

movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philishave system.

3Switch the shaver off.

ENGLISH6

C4Put the protection cap on the shaver to

prevent damage.

Replace the shaving heads (type HQ6 Quadra

Action) every 2 years for optimal shaving results.

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

Cleaning

Regular cleaning guarantees better shaving

performance.

The easiest and most hygienic way to clean the

appliance is to rinse the shaving unit every week

with hot water (60c-80cC).

When you clean the appliance,it is not necessary

to take the shaving heads (cutters and guards)

apart.If you want to take them apart,be sure not

to mix up the cutters and guards,since grinding of

the cutters in the guards only guarantees optimal

performance for each matching set.If you

accidentally mix up the sets,it could take several

weeks before optimal shaving performance is

restored.

ENGLISH 7

Every week:shaving unit

1Switch the shaver off,remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Press the release button and open the

shaving unit.

C3Clean the shaving unit and the hair

chamber by rinsing them under a hot tap

for some time.

C4Leave the shaving unit open to let the

appliance dry completely.

You can also clean the hair chamber without

water by using the brush supplied.

Every six months:trimmer

1Switch the shaver off,remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Clean the trimmer with the brush.

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

ENGLISH8

Replacing the shaving heads

Replace the shaving heads every two years for

optimal shaving results.

1Switch the shaver off,remove the

powerplug from the socket and pull the

appliance plug out of the shaver.

C2Press the release button to open the

shaving unit.

C3Turn the wheel anti-clockwise and remove

the retaining frame.

C4Remove the shaving heads and place the

new ones in the shaving unit in such a way

that the parts with the small holes point

towards the centre of the shaving unit.

Make sure that the projections of the shaving

heads fit exactly into the recesses.

C5Reassemble the shaving unit by replacing

the retaining frame.Press the wheel and

turn it clockwise.

If the shaving heads have been properly inserted,

a shiny circle is visible on top of the shaving unit.

Replace damaged or worn shaving heads with

Philishave HQ6 Quadra Action shaving heads

only.

ENGLISH 9

Storage

C◗Put the protective cap on the shaver to

prevent damage.

C◗Store the appliance in the luxury pouch or in

the stand.The stand can be used standing on a

surface or attached to the wall.

To attach the stand to the wall:

1Remove the base from the holder by

turning and pulling the holder.

C2Attach the base tot the wall.

3Click the holder into the base.

Disposal of batteries

Remove the batteries when you discard the

shaver.Do not throw the batteries away with the

normal household waste,but hand them in at an

official collection point.You can also take the

batteries to a Philips Service Centre,which will

dispose of them in an environmentally safe way.

Only remove the batteries if they are completely

empty.

ENGLISH10

1Remove the powerplug from the socket

and pull the appliance plug out of the

shaver.

C2Let the shaver run until it stops,undo the

screws and open the shaver.

3Remove the batteries.

Do not connect the shaver to the mains again

after the batteries have been removed.

Troubleshooting

1Reduced shaving performance

BCause 1:the shaving heads are dirty.

BThe shaver has not been rinsed long enough or

the water used was not hot enough.

◗Clean the shaver thoroughly before you

continue shaving (see 'Cleaning').

BCause 2:long hairs are obstructing the shaving

heads.

C◗Remove the retaining frame.

◗Remove the hairs with the brush supplied.

C◗Clean the cutters and guards.

Do not clean more than one cutter and guard at

a time,since they are all matching sets.If you

accidentally mix up the cutters and guards,it may

take several weeks before optimal shaving

performance is restored.

ENGLISH 11

◗Put the retaining plate back onto the shaving

unit.

BCause 3:shaving heads are damaged or worn.

◗Remove the retaining frame.

◗Remove the old shaving heads from the

shaving unit and replace them with new ones

Damaged or worn shaving heads (cutters and

guards) must only be replaced with the original

Philishave HQ6 Quadra Action shaving heads.

◗Put the retaining plate back onto the shaving

unit.

2The shaver does not work when the

ON/OFF button is pressed.

BCause:the batteries are empty

◗Recharge the batteries.

Guarantee & service

If you need information or if you have a problem,

please visit the PhilipsWeb site at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will find its

phone number in the worldwide guarantee

leaflet).If there is no Customer Care Centre in

your country,turn to your local Philips dealer or

contact the Service Department of Philips

Domestic Appliances and Personal Care BV.

ENGLISH12
