Philips HQ6870 Manuel utilisateur

ENGLISH 4
RUSSKIJ 12
âESKY 21
SLOVENSKY 29
MAGYAR 37
УКРАЇНСЬКА 45
HRVATSKI 53
SLOVEN[^INA 61
ROMÂNIA 69
EESTI 77
LATVISKI 85
LIETUVIÿKAI 93
POLSKI 101
INDEX 3
HQ 6870

Important

◗Use only the supplied HQ 6000 powerplug to

charge the appliance.

◗The powerplug transforms 110-240Volts to

12Volts.

C◗Make sure the HQ 6000 powerplug does not get

wet.

C◗The shaver runs at a safe low voltage of 12Volts.

It is watertight and can be cleaned under the

tap. Do not rinse with water hotter than 80°C.

The display

The display provides the following information:

C◗Charging

As soon as you start charging the empty shaver, the

red light lights up.When there is sufficient power for

1 shave, the green light starts blinking.As charging

continues, more and more lights will become green

to indicate to what level the batteries have been

charged.

C◗Batteries fully charged

When the batteries have been fully charged, all lights

will become green.

C◗Remaining capacity

The number of lights indicate how much power

there is approx. left in the batteries: the more lights

are burning, the more power.A fully charged shaver

4ENGLISH

ENGLISH 5

has a cordless shaving time up to approx. 70

minutes.

◗Batteries running low

If the batteries are running low, the lower light

becomes red.When you have switched off the

shaver, the red light will blink for 4 seconds.

Charging

Recharge and keep the appliance at a temperature

between 5º and 35ºC.

The powerplug is suitable for mains voltages ranging

from 100 to 240V.

You can also shave without charging by connecting

the shaver to the mains.

Do not leave the shaver connected to the mains

continuously.

C1Put the appliance plug into the shaver as far

as the line on the plug.

2Plug the powerplug into the socket.

Do not recharge the shaver in a closed pouch.

3When charging for the first time or after a

long period of disuse: leave the shaver to

charge continuously for 4 hours.

Charging normally takes approx. 1 hour.

4Remove the powerplug from the socket and

disconnect the appliance plug from the

shaver as soon as the batteries have been

fully charged.

6ENGLISH

With the special Philishave Car Cord (HQ 6010),

you can also charge the appliance at 12 Volts (e.g. in

a car).This cord is available from your Philishave

dealer.

Shaving

1Switch the appliance on by pressing the

on/off button once.

C2Move the shaving heads quickly over the skin.

Make both straight and circular movements.

A dry skin gives the best shaving results.

Your skin may need 2 - 3 weeks to get accustomed

to this Philishave system.

3Switch the appliance off by pressing the

on/off button once.

C4Put the protection cap on the shaver to

prevent damage.

Replace the shaving heads (type HQ6 Quadra

Action) every 2 years for optimal shaving results.

Trimmer

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

ENGLISH 7

Cleaning

Regular cleaning guarantees better shaving results.

The easiest and most hygienic way to clean the

appliance is to rinse the shaving unit every week

with hot water (60° - 80°C).

When you clean the appliance, it is not necessary to

take the shaving heads (cutters and guards) apart. If

you want to take them apart, be sure not to mix up

the cutters and guards, since grinding of the cutters

in the guards only guarantees optimal performance

for each matching set. If you accidentally mix up the

sets, it could take several weeks before optimal

shaving performance is restored.

Every week: shaving unit

1Switch the appliance off, remove the

powerplug from the socket and disconnect

the appliance plug from the shaver.

C2Press the release button and open the

shaving unit.

C3Clean the shaving unit and the hair chamber

by rinsing them under a hot tap (60°-80°C)

for some time.

C4Leave the shaving unit open to let the

appliance dry up completely.

You can also clean the hair chamber without water

by using the supplied brush.

Every six months: trimmer

1Switch the appliance off, remove the

powerplug from the socket and disconnect

the appliance plug from the shaver.

C2Clean the trimmer with the brush.

C3Lubricate the trimmer teeth with a drop of

sewing machine oil every six months.

Replacing the shaving heads

Replace the shaving heads every two years for

optimal shaving results.

1Switch the appliance off, remove the

powerplug from the socket and disconnect

the appliance plug from the shaver.

C2Press the release button and open the

shaving unit.

C3Turn the wheel anticlockwise and remove

the retaining frame.

C4Remove the shaving heads and place the new

ones in the shaving unit in such a way that

the sides with the little holes point to the

middle of the shaving unit.

8ENGLISH

Make sure that the projections of the shaving heads

fit exactly into the recesses.

C5Reassemble the shaving unit by pressing the

wheel and turning it clockwise.

If the shaving heads have been properly inserted, a

shiny circle is visible on top of the shaving unit.

Replace damaged or worn shaving heads with

Philishave HQ6 Quadra Action shaving heads only.

Storage

C◗Put the protection cap on the shaver to prevent

damage.

◗Store the appliance in the luxury pouch.

Disposal of batteries

Remove the batteries when you discard the

appliance. Do not throw the batteries away with the

normal household waste, but hand them in at an

official collection point.You can also take the

batteries to a Philips Service Centre, which will

dispose of them in an environmentally safe way.

Only remove the batteries if they are completely

empty.

1Remove the powerplug from the socket and

disconnect the appliance plug from the

shaver.

C2Let the shaver run until it stops, undo the

screws and open the shaver.

ENGLISH 9

10 ENGLISH

3Remove the batteries.

The shaver may not be connected to the mains

again after the batteries have been removed.

Troubleshooting

Reduced shaving performance:

Cause 1:The shaving heads are dirty.The shaver has not

been rinsed hot enough or long enough.

1Clean the shaver thoroughly before you

continue shaving. (See ‘Cleaning’)

Cause 2: Long hairs are obstructing the shaving heads.

C1Remove the retaining plate.

2Clean the cutters and guards.

Do not clean more than one cutter and guard at a

time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it could

take several weeks before optimal shaving

performance is restored.

3Remove the hairs.

4Put the retaining plate back onto the shaving

unit.

Cause 3: Shaving heads are damaged or worn.

1Remove the retaining plate.

2Remove the old shaving heads from the

shaving unit and replace them with new ones.

ENGLISH 11

Damaged or worn shaving heads (cutters and

guards) must only be replaced by the original

Philipshave HQ6 Quadra Action shaving heads!

3Put the retaining plate back onto the shaving

unit.

Shaver does not work when the on/off button is

pressed:

Cause:The batteries is empty

1Recharge the batteries.

For telephone numbers of the Philips Helpdesk, see the

worldwide guarantee leaflet.

12 RUSSKIJ

Vnimanie

◗Dlä zarädki britvy pol´zujtes´ tol´ko

setevym adapterom HQ6000, vxodäwim v

komplekt postavki.

◗Qtot adapter preobrazuet napräΩenie 110

240 V v napräΩenie 12 V.

C◗Izbegajte popadaniä vody na setevoj

adapter HQ6000.

C◗Britva funkcioniruet pri nizkom

bezopasnom napräΩenii 12 V. Ona

vodonepronicaema, i ee moΩno promyvat´

protohnoj vodoj. Ne promyvajte britvu

vodoj, temperatura kotoroj vyπe 80 °S.

Displej

Na displee otobraΩaetsä sleduüwaä informaciä:

C◗Zarädka

Kak tol´ko nahinaetsä zarädka britvy, zagoraetsä

krasnyj indikator. Kogda v akkumulätorax

nakaplivaetsä qnergiä, dostatohnaä dlä togo,

htoby pobrit´sä odin raz, nahinaet migat´

zelenyj indikator. Po mere prodolΩeniä

processa zarädki vse bol´πe indikatorov

stanovätsä zelenymi, xarakterizuä uroven´

zarädki akkumulätorov.

C◗Polnaä zarädka akkumulätorov

Kak tol´ko akkumulätory polnost´ü zarädätsä, vse

indikatory stanovätsä zelenymi.
