Philips HQ6863/16 Manuel utilisateur

ENGLISH 4

DEUTSCH 16

FRANÇAIS 28

NEDERLANDS 40

ESPAÑOL 52

ITALIANO 64

PORTUGUÊS 76

TÜRKÇE 88

HQ6863

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the mains cord supplied.

◗Do not use a damaged mains cord.

◗If the mains cord is damaged, always have it

replaced by one of the original type in order

to avoid a hazard.

◗The appliance is equipped with an automatic

voltage selector and is suitable for mains

voltages ranging from 100 to 240 volts.

◗Charge, store and use the appliance at a

temperature between 5cC and 35cC.

◗Do not recharge the shaver in a closed pouch.

C◗Keep the appliance and the mains cord dry.

Charging

Make sure the appliance is switched off before

you start charging it.

When you charge the shaver for the first time or

after a long period of disuse, let it charge

continuously for 4 hours. Charging normally takes

approx. 1 hour.

You can also shave without charging by

connecting the shaver to the mains.

Do not leave the appliance connected to the

mains for more than 24 hours.

ENGLISH4

Charge indications

Charging

C◗When you start charging the empty shaver,

the bottom pilot light starts burning green.

When there is enough power for one shave,

this pilot light starts blinking green.

◗As charging continues, more and more green

pilot lights go on to indicate to what level the

batteries have been charged.The blinking pilot

light indicates the amount of power available.

Batteries fully charged

C◗When the batteries have been fully charged,

all green pilot lights are on.

Remaining battery capacity

◗During shaving, the pilot lights go out one by

one to indicate how much power has already

been consumed.When the bottom pilot light

turns red, there is just enough power left to

finish your shave.

ENGLISH 5

100

Batteries running low

C◗When the batteries are running low, the

bottom pilot light turns red.When you

switch the shaver off, this pilot light blinks

red for 4 seconds.

Charging the appliance

Charge the appliance when the bottom pilot light

blinks red.

Do not recharge the shaver in a closed pouch.

C1Put the appliance plug in the shaver.

2Put the mains plug in the wall socket.

3Remove the mains plug from the wall

socket and pull the appliance plug out of

the shaver when the batteries have been

fully charged.

Cordless shaving time

A fully charged shaver has a cordless shaving time

of up to 45 minutes.

ENGLISH6

Using the appliance

Shaving

1Switch the shaver on by pressing the on/off

button once.

C2Move the shaving heads quickly over your

skin, making both straight and circular

movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philips system.

3Switch the shaver off by pressing the on/off

button once.

C4Put the protection cap on the shaver every

time you have used it, to prevent damage.

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

ENGLISH 7

C◗For easy and optimal cleaning, the Philips

Action Clean (shaving head cleaner, type

HQ100) is available.Ask your Philips dealer

for information.

BThe Philips Action Clean may not be available in

all countries. Contact the Customer Care Centre in

your country about the availability of this

accessory.

You can also clean the shaver in the following

way:

Every week: shaving unit and hair chamber

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the top of the appliance first, using

the brush supplied.

C3Press the release button (1) and remove

the shaving unit (2).

C4Clean the inside of the shaving unit and the

hair chamber with the brush.

ENGLISH8

C5Put the shaving unit back onto the shaver.

Every two months: shaving heads

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Press the release button (1) and remove

the shaving unit (2).

C3Turn the wheel anticlockwise (1) and

remove the retaining frame (2).

C4Remove and clean the shaving heads

(cutters and guards) one by one.

Do not mix up the cutters and the guards.

This is essential since each cutter has been

ground with its corresponding guard for optimal

performance. If you accidentally mix the sets up, it

could take several weeks before optimal shaving

performance is restored.

C5Clean the cutter with the short-bristled

side of the brush.

Brush carefully in the direction of the arrow.

ENGLISH 9

C6Brush the guard.

C7Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit (1) and turn the wheel

clockwise (2).

8Put the shaving unit back onto the shaver.

For extra thorough cleaning, clean the shaving

heads by putting them in a degreasing liquid (e.g.

alcohol) every six months.To remove the shaving

heads, follow steps 1 to 4 described above. After

cleaning, lubricate the central point on the inside

of the guards with a drop of sewing machine oil

to prevent wear of the shaving heads.

Trimmer

Clean the trimmer every time you have used it.

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the trimmer with the brush

supplied.

ENGLISH10

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

Storage

C◗Put the protection cap on the shaver to

prevent damage.

◗The appliance can be stored in the pouch

supplied.

Replacement

Replace the shaving heads every two years for

optimal shaving results.

Replace damaged or worn shaving heads with

HQ55 Philips Super Reflex shaving heads only.

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Press the release button (1) and remove

the shaving unit (2).

C3Turn the wheel anticlockwise (1) and

remove the retaining frame (2).

ENGLISH 11

C4Remove the shaving heads and place new

ones in the shaving unit.

C5Put the retaining frame back into the

shaving unit (1) and turn the wheel

clockwise (2).

6Put the shaving unit back onto the shaver.

Accessories

The following accessories are available:

- HQ55 Philips Super Reflex shaving heads.

- HQ100 Philips Action Clean (shaving head

cleaner).

- HQ101 Philips Action Clean refill (shaving head

cleaning liquid).

- HQ110 Philips shaving head cleaner (shaving

head cleaning spray).

Environment

C◗Do not throw the appliance away with the

normal household waste at the end of its life,

but hand it in at an official collection point for

recycling. By doing this you will help to

preserve the environment.

The built-in rechargeable battery contains

substances that may pollute the environment.

Always remove the battery before discarding the

ENGLISH12
