Philips HQ5823 Manuel utilisateur

ENGLISH 4

DEUTSCH 14

FRANÇAIS 25

NEDERLANDS 36

ESPAÑOL 47

ITALIANO 58

PORTUGUÊS 69

TÜRKÇE 79

HQ5823, HQ5813, HQ5812

á«Hô©dG

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the mains cord supplied.

◗Do not use a damaged mains cord.

◗If the mains cord is damaged, always have it

replaced by one of the original type in order

to avoid a hazard.

◗The appliance is equipped with an automatic

voltage selector and is suitable for mains

voltages ranging from 100 to 240 volts.

◗Charge, store and use the appliance at a

temperature between 5cC and 35cC.

◗Do not recharge the shaver in a closed pouch.

C◗Make sure the appliance and the mains cord

do not get wet.

Charging

Make sure the appliance is switched off before

you start charging it.

When charging for the first time or after a long

period of disuse: leave the shaver to charge

continuously for 12 hours.

Charging normally takes approx. 8 hours.

Do not leave the appliance connected to the

mains for more than 24 hours.

You can also shave without charging by

connecting the shaver to the mains.

ENGLISH4

Charging the appliance

Charge the appliance when the motor stops or

starts running slower.

Do not recharge the shaver in a closed pouch.

C1Put the appliance plug in the shaver.

2Put the mains plug in the wall socket.

C◗As soon as you start charging the empty

shaver, the green pilot light goes on.

To extend the lifetime of the battery, remove the

mains plug from the wall socket and pull the

appliance plug out of the shaver when the battery

has been fully charged.

Cordless shaving time

A fully charged shaver has a cordless shaving time

of up to 30 minutes.

Using the appliance

Shaving

1Switch the shaver on by pushing the on/off

slide upwards.

C2Move the shaving heads quickly over your

skin, making both straight and circular

movements.

ENGLISH 5

CHARGE

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philishave system.

3Switch the shaver off by pushing the on/off

slide downwards.

C4Put the protection cap on the shaver every

time you have used it, to prevent damage.

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

C◗For easy and optimal cleaning, the Philishave

Action Clean (shaving head cleaner, type

HQ100) is available.Ask your Philishave dealer

for information.

BThe Philishave Action Clean may not be available

in all countries. Contact the Customer Care

Centrein your country about the availability of this

accessory.

ENGLISH6

You can also clean the shaver in the following

way:

Every week: shaving unit

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the top of the appliance first, using

the brush supplied.

C3Press the release button and remove the

shaving unit.

C4Clean the inside of the shaving unit and the

hair chamber with the brush.

C5Put the shaving unit back onto the shaver.

ENGLISH 7

Every two months: shaving heads

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Press the release button and remove the

shaving unit.

C3Turn the wheel anticlockwise and remove

the retaining frame.

C4Remove and clean the shaving heads

(cutters and guards) one by one.

Do not mix up the cutters and the guards.

This is essential since each cutter has been

ground with its corresponding guard for optimal

performance. If you accidentally mix the sets up, it

could take several weeks before optimal shaving

performance is restored.

C5Clean the cutter with the short-bristled

side of the brush.

Brush carefully in the direction of the arrow.

C6Brush the guard.

ENGLISH8

C7Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit, press the wheel and turn it

clockwise.

8Put the shaving unit back onto the shaver.

BYou can also clean the shaving heads with a

degreasing liquid (e.g. alcohol). If you do, lubricate

the central point of the guards with a drop of

sewing machine oil after cleaning.This prevents

wear of the shaving heads.

Trimmer

Clean the trimmer every time you have used it.

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the trimmer with the brush

supplied.

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

ENGLISH 9

Storage

C◗Put the protection cap on the shaver to

prevent damage.

◗The appliance can be stored in the pouch

supplied.

Replacement

Replace the shaving heads every 2 years for

optimal shaving results.

Replace damaged or worn shaving heads with

HQ4«Philishave shaving heads only.

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Press the release button and remove the

shaving unit.

C3Turn the wheel anticlockwise and remove

the retaining frame.

C4Remove the shaving heads and place new

ones in the shaving unit.

ENGLISH10

C5Put the retaining frame back into the

shaving unit, press the wheel and turn it

clockwise.

Accessories

The following accessories are available:

- HQ100 Philishave Action Clean

(shaving head cleaner).

- HQ101 Philishave Action Clean refill

(shaving head cleaning liquid).

- HQ110 Philishave shaving head cleaner

(shaving head cleaning spray).

- HQ4«Philishave shaving heads.

Environment

The built-in rechargeable battery contains

substances that may pollute the environment.

Disposal of the battery

Remove the battery when you discard the

appliance. Do not throw the battery away with

the normal household waste, but hand it in at an

official collection point.You can also take the

appliance to a Philips service centre, which will

remove the battery for you and will dispose of it

in an environmentally safe way.

Only remove the battery if it is completely empty.

ENGLISH 11

1Remove the mains plug from the wall

socket and pull the appliance plug out of

the shaver.

C2Let the shaver run until it stops, undo the

two screws and open the shaver.

3Remove the battery.

Do not connect the shaver to the mains again

after the battery has been removed.

Guarantee & service

If you need information or if you have a problem,

please visit the Philips Web site at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will find its

phone number in the worldwide guarantee

leaflet). If there is no Customer Care Centre in

your country, turn to your local Philips dealer or

contact the Service Department of Philips

Domestic Appliances and Personal Care BV.

Troubleshooting

1Reduced shaving performance

BCause 1: the shaving heads are dirty.

BThe shaver has not been cleaned well enough or

has not been cleaned for a long time.

◗Clean the shaver thoroughly before you

continue shaving (see chapter 'Cleaning and

maintenance').
