Philips HQ5413 Manuel utilisateur
Important
Read these instructions for use carefully before
using the appliance and save them for future
reference.
◗Only use the mains cord supplied.
◗Do not use a damaged mains cord.
◗If the mains cord is damaged, always have it
replaced by one of the original type in order
to avoid a hazard.
◗The appliance is equipped with an automatic
voltage selector and is suitable for mains
voltages ranging from 100 to 240 volts.
◗Store and use the appliance at a temperature
between 5cC and 35cC.
C◗Keep the appliance and the mains cord dry.
◗Noise level: Lc= 62 dB [A]
Using the appliance
Shaving
C1Put the appliance plug in the shaver.
2Put the mains plug in the wall socket.
3Switch the shaver on by pushing the on/off
slide to position I.
C4Move the shaving heads quickly over your
skin, making both straight and circular
movements.
Shaving on a dry face gives the best results.
ENGLISH4
Your skin may need 2 or 3 weeks to get
accustomed to the Philips system.
5Switch the shaver off by pushing the on/off
slide to position 0.
C6Put the protection cap on the shaver every
time you have used it, to prevent damage.
Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.
Cleaning and maintenance
Regular cleaning guarantees better shaving
performance.
Every week: shaving unit and hair chamber
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Clean the top of the appliance first, using
the brush supplied.
ENGLISH 5
C3Press the release button (1) and remove
the shaving unit (2).
C4Clean the inside of the shaving unit and the
hair chamber with the brush.
C5Put the shaving unit back onto the shaver.
Every two months: shaving heads
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Press the release button (1) and remove
the shaving unit (2).
C3Turn the wheel anticlockwise (1) and
remove the retaining frame (2).
ENGLISH6
2
1
2
1
1
2
C4Remove and clean the shaving heads
(cutters and guards) one by one.
Do not mix up the cutters and the guards.
This is essential since each cutter has been
ground with its corresponding guard for optimal
performance. If you accidentally mix the sets up, it
could take several weeks before optimal shaving
performance is restored.
C5Clean the cutter with the short-bristled
side of the brush.
Brush carefully in the direction of the arrow.
C6Brush the guard.
C7Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit (1) and turn the wheel
clockwise (2).
8Put the shaving unit back onto the shaver.
BFor extra thorough cleaning, clean the shaving
heads by putting them in a degreasing liquid (e.g.
alcohol) every six months.To remove the shaving
heads, follow steps 1 to 4 described above. After
cleaning, lubricate the central point on the inside
of the guards with a drop of sewing machine oil to
prevent wear of the shaving heads.
ENGLISH 7
1
2
Trimmer
Clean the trimmer every time you have used it.
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Clean the trimmer with the brush
supplied.
C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Storage
C◗Put the protection cap on the shaver to
prevent damage.
◗The appliance can be stored in the pouch
supplied.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with
HQ4«Philips shaving heads only.
ENGLISH8
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Press the release button (1) and remove
the shaving unit (2).
C3Turn the wheel anticlockwise (1) and
remove the retaining frame (2).
C4Remove the shaving heads and place new
ones in the shaving unit.
C5Put the retaining frame back into the
shaving unit (1) and turn the wheel
clockwise (2).
6Put the shaving unit back onto the shaver.
Accessories
The following accessories are available:
- HQ4«Philips shaving heads.
- HQ110 Philips shaving head cleaner (shaving
head cleaning spray).
ENGLISH 9
2
1
1
2
1
2
Environment
C◗Do not throw the appliance away with the
normal household waste at the end of its life,
but hand it in at an official collection point for
recycling. By doing this you will help to
preserve the environment.
Guarantee & service
If you need information or if you have a
problem, please visit the Philips Web site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet). If there is no Customer Care Centre in
your country, turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
Troubleshooting
1Reduced shaving performance
BCause 1: the shaving heads are dirty.
BThe shaver has not been cleaned well enough or
has not been cleaned for a long time.
◗Clean the shaver thoroughly before you
continue shaving. See chapter 'Cleaning and
maintenance'.
BCause 2: long hairs are obstructing the shaving
heads.
ENGLISH10
◗Clean the cutters and guards with the brush
supplied. See chapter 'Cleaning and
maintenance', section 'Every two months:
shaving heads'.
BCause 3: the shaving heads are damaged or worn.
◗Replace the shaving heads. See chapter
'Replacement'.
2The shaver does not work when the on/off
slide is pushed to position I.
BCause: the shaver is not connected to the mains.
◗Put the mains plug in the wall socket.
ENGLISH 11
Ważne
Przeczytaj instrukcję zanim zaczniesz używać
golarkę i zachowaj ja w przyszłości na wszelki
wypadek.
◗Używaj wyłącznie przewodu zasilającego, w
który zostało wyposażone urządzenie.
◗Nie używaj uszkodzonego przewodu
zasilającego.
◗Jeśli uszkodzony jest przewód zasilający,
wówczas dla zapewnienia bezpiecze stwa
należy zastąpić go wyłącznie przewodem
oryginalnym.
◗Urządzenie dysponuje automatycznym
przełącznikiem napięcia i przystosowane jest
do napięcia zasilania od 100 V do 240 V.
◗Przechowuj urządzenie w temperaturze
pomiędzy 5cC oraz 35cC.
C◗Utrzymuj urządzenie i przewód zasilający w
stanie suchym.
◗Poziom hałasu: Lc= 62 dB [A]
Sposób uż wania
Golenie
C1Włóż małą wtyczkę przewodu zasilającego
do golarki.
2Wetknij wtyczkę do gniazdka ściennego.
3Włącz golarkę, przesuwając przełącznik
on/off do pozycji I.
POLSKI12
