Philips 775 Manuel utilisateur

English page 3

Français page 10

Deutsch Seite 17

Nederlands pagina 24

Italiano pagina 31

Español página 38

Português página 45

1Do not allow the shaver to become wet.

2Do not leave the appliance in a position

where it can become damaged by direct

sunlight or other heat source.

• Please bear in mind that your skin may

need two to four weeks to become fully

accustomed to the Philishave shaving

system.

920

■■■ Important English

■■■ Shaving

3Insert the small plug into

the shaver. Ensure that the

plug is pushed fully home.

(Note the indication mark.)

Insert the mains plug into a

wall socket. Mains voltages:

ranging from 100 to 240 Volts. (The shaver

adjusts automatically.)

4Switching on: Slide the

switch upwards.

Switching off: Slide the switch

downwards.

5The comfort control can be

adjusted to suit skin

sensitivity.

Start with the control set to

position 1 (for sensitive skin)

and then try other positions to

find the one that suits you

best.

6Move the shaving unit

quickly over the skin and

especially against the

direction of the hair growth,

stretching the skin with your

free hand to bring the hairs

into an upright position.

• Best results are obtained if the skin is dry.

Preferably shave before or some time after

washing.

• If required apply a pre-shave lotion. This can be

particularly helpful if the climate is warm and

humid.

1 2 3 4 5 6 7 8 9

■■■ Trimmer

The trimmer can be engaged whilst the motor is

running.

7To engage the trimmer push

the slide upwards.

To disengage move the slide

downwards.

Brush the trimmer clean after

each use.

8The trimmer has been

especially designed for

grooming sideburns,

moustache and beard.

The trimmer is not required for

long hairs in the neck area;

these hairs can easily be

shaved off with the shaving

unit.

9Maintenance (every six

months)

Apply two drops of light

machine oil to the teeth of the

trimmer.

OIL

■■■ Cleaning

• Always ensure that the shaver is switched off and

the mains cord is disconnected before carrying

out maintenance or cleaning.

• Handle the shaving heads carefully to avoid

causing damage.

•Advice: Clean the shaver regularly.

10 - 13 Every week:

shaving head slots and hair chamber

- (Fig. 10) Use the short bristled

brush to clean the shaving

head slots.

- (Fig. 11) To remove the

shaving unit depress the

retaining button (1) and lift the

shaving unit from the shaver (2).

- (Fig. 12 - 13) Remove hairs

from the chamber and shaving

unit using the long bristled

brush.

12 13

14 - 25 Every 3 months:

shaving head slots, the hair chamber and

shaving unit (guards and cutters)

(If your skin is of an oily type or if you have been

using a pre-shave lotion: 1x per month.)

- First clean the shaver head slots and hair

chamber as previously described.

(See figs. 10 - 13.)

Then proceed with figs. 14 - 25 for cleaning the

shaving unit.

- (Fig. 14 - 15) Release and

remove the retaining plate.

The shaving heads remain in

the shaving unit.

- (Fig. 16) Remove only one

shaving head (guard and

cutter) at a time for cleaning

to ensure that the cutters

and guards

do not

become

mixed.

Each cutter

has been

ground

together

with the guard. If the guards

and cutters are mixed, it may

take some weeks before

optimal shaving performance

is restored.

15 16

- (Fig. 18) Clean the cutter

by brushing only in the

direction of the arrow

using the short bristled

brush.

- (Fig. 20 & 25) If you have a

very dry skin, or if

degreasing liquid (e.g. alcohol)

has been used to clean the

shaving heads, lubricate the

shaving heads with one drop

of light machine oil.

As an alternative to using light

machine oil

for

lubrication

you may

use the

specially

formulated

Philishave

cleaner /

lubricant

type 389

SHC/1

available

from

Authorised

Philips

Service

OIL

24 25

OIL

Dealers.

■■■ Replacement shaving

heads

26 Use only Philishave

replacement heads type

HP 1915 R when replacing

worn or damaged shaving

heads.

■■■ Accessories

The following accessories for your shaver are

available from Philips retailers or Authorised Service

Dealers as optional extras:

Type number: Accessory:

HP 1928 Travelling pouch, gives

protection and enables

compact storage for shaver and

mains cord.

HP 1926 Stand/wall holder for space

saving storage.

1Evitez tout contact de l'appareil avec l'eau.

2Ne laissez pas l'appareil exposéàde fortes

chaleurs ou aux rayons directs du soleil.

•Lorsque vous utilisez le système de

rasage Philishave pour la première fois, il

est important de savoir qu'une période

d'adaptation de la barbe de 2 à4

semaines est nécessaire pour obtenir

l'efficacitéoptimale du rasage.

920

■■■ Important Français

■■■ Rasage

3Branchez d'abord le cordon

sur le connecteur en

l'enfonçant jusqu'àla ligne

repère. Tensions

d'utilisation : 100 - 240 V.

(Le rasoir s'adapte

automatiquement à la tension

d'utilisation).
